Summary of Contents for Samsung DVD-V4700
- Page 1 Instruction Manual Mode d’emploi DVD-V4700 www.samsung.ca INPUT SEL. AUDIO F.ADV/SKIP...
-
Page 2: Remote Control Overview
Remote Control Overview INPUT SEL. AUDIO F.ADV/SKIP... -
Page 3: Important Safety Instructions
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. -
Page 4: Table Of Contents
Digital Output ......17 DTS ....... 18 Dynamic Compression . -
Page 5: Feature Summary
Both the DVD player and the discs are coded by region. These regional codes must match in order for the disc to play. If the codes do not match, the disc will not play. The Region Number for this player is described on the rear panel of the player. -
Page 6: Unpack
AUDIO-CD Audio * It may not be to play CD-R,CD-RW and DVD-R in all cases due to the type of disc or condition of the recording. Unpack When you unpack the DVD-VCR, please check the following list of items is included in the packing case. -
Page 7: Front Panel Overview
FRONT PANEL DISPLAY CHANNEL DVD-VCR SELECT PROGRESSIVE COMPOSITE VIDEO JACK LEFT AUDIO JACK RIGHT AUDIO JACK LINE IN 1 LINE OUT TO TV (COMPOSITE) RF ANTENNA INPUT RF OUT TO TV (RF THROUGH ONLY) ENG-6 14 15 16 17 18... -
Page 8: Front Panel Display
• Slide the cover back onto remote. Basic Connections/Auto Setup You will need to connect the DVD-VCR to a TV and run Auto Setup. The Auto Setup will automatically search for channels and then set your DVD-VCR's internal clock. -
Page 9: Stereo Connections
Be sure to adjust the volume on your stereo receiver or TV. Audio will be heard through your stereo speakers • If there is no stereo sound even after you have inserted a Hi-Fi stereo videotape, press the AUDIO button until “Hi-Fi” appears on the on-screen display. -
Page 10: Monitor Tv Connections
1 Connect Device to DVD-VCR Connect RCA cables from the Audio and Video Line Outputs of your external device to the Audio and Video Line Inputs on the front or rear panel of the DVD-VCR. Audio/Video Outputs of External Device... -
Page 11: A/V Receiver Connections
• Most discs will start to playback as soon as the tray closes. • If a DVD has a MENU, the menu may pop up on TV screen. 5 Additional DVD Options •... -
Page 12: Basic Vcr Operation
Basic VCR Operation To play a standard VHS videotape, just insert it into the VCR deck and press the PLAY button. You can turn on the Auto Play to enable the VCR deck to play automatically when you insert a videotape that is missing the Record Safety Tab. -
Page 13: Menu Language
Use the LEFT/RIGHT buttons to select each of the following options, then use the UP/DOWN buttons to set each option: • Hour – Set the hour • Minute – Set the minute. • Day – Set the day. Manual Clock 2004 THU 6 Confirm Settings Press the RETURN button to confirm your clock settings and to return to the Clock Set/Adjust. -
Page 14: Tuner Band Setting
Antenna 6 Change “TV Channel” A message will appear on your TV. When the message disappears, change your TV to channel 3 or 4 to match the RF output channel of the player. ENG-13 : English : Auto : Off... -
Page 15: Auto Channel Memory
6 Select “Channel Add/Delete” Press RIGHT button to add or press left button to delete the channel from your channel list. • Repeat steps 4 and 5 to add or delete additional channels. CHANNEL ADD/DELETE Select channel :... -
Page 16: Front Panel Dimmer
Front Panel Dimmer You can set the Front Panel Display to be bright all the time, dim all the time, dim during power off. 1 Open “ MENU” With the DVD in Stop or Play mode, press the MENU button. -
Page 17: Disc Menu Language
Disc Menu Language To set the Disc Menu Language to your preferred language, follow these steps. If your preferred language is available on a DVD, your Disc Menu Language will automatically be set to the language you choose. 1 Open “MENU”... -
Page 18: Subtitle Language
DVD, your Subtitle Language will automatically be set to the language you choose. 1 Open “MENU” Press the MENU button while the DVD is in Stop mode. 2 Select “DVD” Use the UP/DOWN buttons to highlight “DVD”... -
Page 19: Dts
Highlight “DTS” then press the RIGHT button to select one of the following options: • Off – To use your DVD/TV with an A/V receiver NOT equipped with a DTS decoder. • On – To use your DVD/TV with an A/V receiver... -
Page 20: Pcm Down Sampling
Highlight “PCM Down Sampling”, then press the RIGHT button to select one of the following options: • On – When a 96K audio disc is played, 96K will be downsampled to 48K and outputted. • Off – When a 96K disc is played, 96K will be outputted. -
Page 21: Black Level
Display Setup Alt Video Out The “Alt Video Out” option must be set in the on-screen menu if you have connected your DVD-VCR to a TV using the S-VIDEO OUT or COMPONENT VIDEO OUT jacks. • Use the S-Video or Component Video connection method only for the DVD player. -
Page 22: Parental
DVDs based on their content. The system uses an eight level rating system. • If you try to play a DVD that exceeds the selected rating, an error message will appear. • Not all discs are rated. -
Page 23: Special Playback Features
• The picture will pause and the audio will mute. • To resume playback, press the button. • If the player is left in Pause mode for 5 minutes, it will stop automatically. 2 Frame Advance (Step) While in PAUSE mode, press the F.ADV/SKIP button on the remote control to advance one frame at a time. -
Page 24: Ez View
Displays the content of the DVD title in 16:9 aspect ratio. The picture will look horizontally stretched. • Screen Fit The top and bottom of the screen are cut off and the full screen appears. The picture will look vertically stretched. • Zoom Fit... -
Page 25: Title/Chapter/Time Selection
To access the desired title when there is more than Title one in the disc. For example, if there is more than one movie on a DVD, each movie will be identified. Most DVD discs are recorded in chapters so that Chapter you can quickly find a specific passage. -
Page 26: Angle View
Press the Angle button, you’ll see the Angle Icon when watching a DVD with multi Angles available. 2 View Angle Menu Options When the Angle Icon comes up on the screen press the ANGLE button to see the Angle menu. 3 Select an Angle option Press the UP/DOWN buttons to select a camera angle you wish to see. -
Page 27: A To B Repeat
A to B Repeat A to B Repeat feature enables you to repeat the designated section on a DVD or CD. To activate, mark where to start(A) and where to end(B) of the section you want to watch. 1 Select A-B Repeat Function Press the REPEAT button while in Play mode, then use the Left/Right buttons to select A-B Repeat. -
Page 28: Audio
• The selected placeholder will be highlighted. 3 Set the Bookmark Keep on playing the DVD up to the scene you want to bookmark, then press the ENTER button. The placeholder (-) will change to a number (1, 2 or 3). -
Page 29: Function (Dvd)
Bookmark Repeat EZ View Special VCR Playback Features While a videotape is playing, you can enjoy a variety of special playback features, including Still, Frame Advance, Skip, Repeat, and more. Press the Play button again to resume normal playback. 1 Pause... -
Page 30: Tracking
The TRK button will automatically align the recorded tracks with the playback heads to solve this problem. You may also set tracking manually. 1 Adjust Tracking Manually During playback, press the CH/TRK buttons to remove white lines from the picture. -
Page 31: S-Vhs Playback
VCR without VISS. If you want to index two programs in a row, set your VCR to stop, then start recording each program. 1 Go to [0:00:00] stop Use this feature when you want to search for the [0:00:00] counter position on a cassette. -
Page 32: Basic Recording
Use the 0–9 buttons or the Channel UP/DOWN arrow buttons to select the desired channel, or press the INPUT SEL. button to select Line 1 or 2 if recording from an external device connected to the front or rear Line inputs, respectively. -
Page 33: One Touch Recording (Otr)
Record Safety Tab intact. 1:30 With the Timer Recording function, you can program 4:00 up to 7 events at a time to record up to a month in advance. To Begin Setting the Timer Recording, • Turn on your DVD-VCR, and •... -
Page 34: How To Set A Timer Recording
Weekly [Sun’s~Sat’s]: Use this to record TV programs on the same channel at the same time every week. Daily [MO - FR] : Use this to record TV programs on the same channel at the same time every day Monday through Friday. -
Page 35: Technical Specifications
WOW & FLUTTER FREQ. RESPONSE DISC COMPATIBILITY FREQ. RESPONSE S/N RATIO DYNAMIC RANGE POWER REQUIREMENT 120V AC, 60 Hz, 25 watts ENVIRONMENT SYSTEM WEIGHT 2 Stereo audio inputs, RCA Connector, -8dbm, 47KΩ, front and rear 2 Composite video inputs, RCA Connector, 75Ω, 1Vp-p Antenna or CATV Input, F-Connector, 75Ω... - Page 36 SECA will repair or replace the product at its option. All warranty repairs must be performed by a SECA authorized service cen- tre. (The name and address of the location nearest you can be obtained by calling toll free 1-800-268-1620 or visiting our web site at www.samsung.ca)
- Page 37 SAMSUNG ELECTRONICS CANADA, INC. HEADQUARTERS SAMSUNG ELECTRONICS CANADA, INC. 7037 FINANCIAL DRIVE MISSISSAUGA, ONTARIO L5N 6R3 CANADA MADE IN KOREA TEL: 1-905-542-3535 www.samsung.ca CUSTOMER SERVICE 7037 Financial Drive Mississauga, Ontario L5N 6R3 Canada 1-800-SAMSUNG (1-800-726-7864) ELECTRONICS AK68-00369A(01)
