YASKAWA AC Drive-Option
24 V Power Supply
Installation Manual
Type PS-A10L, PS-A10H
To properly use the product, read this manual thoroughly and retain
for easy reference, inspection, and maintenance. Ensure the end user
receives this manual.
安川インバータ オプション
24 V
取扱説明書
形式
PS-A10L, PS-A10H
製品を安全にお使い頂くために，この取扱説明書を必ずお読みください。
また，本書をお手元に保管していただくとともに，最終的に本製品をご使用になる
ユーザー様のお手元に確実に届けられるよう，お取り計らい願います。
MANUAL NO. TOBP C730600 48B
制御電源ユニット
Advertisement
Related Manuals for YASKAWA PS-A10L
Summary of Contents for YASKAWA PS-A10L
- Page 1 YASKAWA AC Drive-Option 24 V Power Supply Installation Manual Type PS-A10L, PS-A10H To properly use the product, read this manual thoroughly and retain for easy reference, inspection, and maintenance. Ensure the end user receives this manual. 安川インバータ オプション 制御電源ユニット 24 V 取扱説明書...
- Page 2 This Page Intentionally Blank...
-
Page 3: Table Of Contents
8 SPECIFICATIONS ....... . . 36 YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual... - Page 4 Yaskawa. No patent liability is assumed with respect to the use of the information contained herein. Moreover, because Yaskawa is constantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice.
-
Page 5: Preface And Safety
The selection and application of Yaskawa products remain the responsibility of the equipment manufacturer or end user. Yaskawa accepts no responsibility for the way its products are incorporated into the final system design. Under no circumstances should any Yaskawa product be incorporated into any product or design as the exclusive or sole safety control. - Page 6 Indicates a hazardous situation, which, if not avoided, could result in death or serious injury. CAUTION Indicates a hazardous situation, which, if not avoided, could result in minor or moderate injury. NOTICE Indicates an equipment damage message. YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 7 • When ordering a new copy of the manual due to damage or loss, contact your Yaskawa representative or the nearest Yaskawa sales office and provide the manual number shown on the front cover.
- Page 8 けが．感電のおそれがあります。 Lire le manuel avant l'installation. Attendre 5 minutes après 据え付け、 運転の前には必ず la coupure de l'alimentation, 取扱説明書を読むこと。 pour permettre la décharge 通電中および電源遮断後5分以内は des condensateurs. 本体内部，コネクタに触れないこと。 YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
-
Page 9: Product Overview
Table 1 24 V Power Supply Options and Applicable Drive Models 24 V Power Supply Model Compatible Drive Model PS-A10L Three-Phase 200 V Class CIMR-A 2A PS-A10H Three-Phase 400 V Class CIMR-A 4A YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual... -
Page 10: Receiving
: 140V / 0.2A Lot Number : GW3050-2-100 Serial Number : J0065F575310100 FILE NO :E131457 PASS YASKAWA ELECTRIC CORPORATION MADE IN JAPAN Figure 1 Nameplate for PS-A10L YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual... - Page 11 • Straight-edge screwdriver (refer to Figure Figure 2 Blade depth of 0.6 mm or less Blade width of 2.5 mm or less Figure 2 Required Screwdriver Dimensions YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
-
Page 12: Power Supply Option Components
D – Model number Figure 3 24 V Power Supply Option ◆ Power Supply Plug Table 3 Plug Connector Terminals Terminal Description Designation +24 V Ground Plug Connector YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual... -
Page 13: Installation Procedure
Tighten all terminal screws to the specified tightening torque. Loose electrical connections could result in death or serious injury by fire due to overheating of electrical connections. YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual... - Page 14 Figure 4 Correct Installation Spacing Note: IP00/NEMA Type 1 and IP00/Open-Chassis models require the same amount of space above and below the drive for installation. YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 15 2. This product must be used in areas with an environment rating no greater than Pollution Degree 2 according to UL standards. External Power Supply ■ Use a Class 2 power supply as defined by UL standards. YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 16 4A0011 2A0021 4A0018 2A0030 4A0023 2A0040 4A0031 2A0056 4A0038 2A0069 4A0044 2A0081 4A0058 2A0110 4A0072 2A0138 4A0088 Installation Method B 2A0169 4A0103 2A0211 4A0139 4A0165 YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 17 Note: Once the 24 V Power Supply Option is installed, the connector cover is no longer needed. Figure 6 Push on the connector tab and slide the cover in the direction indicated by the arrow Figure 6 Removing the Connector Cover YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 18 Figure 7 Pulling Out the Connection Cable Firmly plug the connector into the matching port inside the drive. Figure 8 Connector tab should face outward Figure 8 Plugging in the Connector YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 19 NOTICE: Make sure the connector cable does not get caught or pinched between the drive and the 24 V Power Supply when installed. Failure to comply can damage the cable. Figure 9 Connector tabs Insertion tabs Figure 9 Location of Tabs YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 20 Figure 10 Figure 10 Installing the 24 V Power Supply Option Figure 11 Figure 11 24 V Power Supply Option Properly Installed YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 21 NOTICE: Do not use excessive force when uninstalling the 24 V Power Supply Option. Failure to comply can damage the cable and connector. Figure 12 Figure 12 Removing the 24 V Power Supply Option YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 22 The connector cover must be removed from the drive to install the 24 V Power Supply Option. Remove the screw holding the connector cover in place. Figure 13 Screw Connector cover Phillips screwdriver Figure 13 Removing the Connector Cover YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 23 Figure 15 Figure 15 Removing the Connector Cover NOTICE: Once the 24 V Power Supply Option is installed, the connector cover is no longer needed. YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 24 Figure 17 24 V Power Supply Option port Connector cable Figure 17 Plugging in the Connector (CIMR-A 2A0110) YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 25 24 V Power Supply Option to the drive in the three locations shown in Figure NOTICE: Use only the screws packaged with the 24 V Power Supply Option. Other screws may damage drive components. YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 26 For drive models CIMR-A 2A0110 to 2A0211 and CIMR-A 4A0058 to 4A0165, remove the three screws that fastened the 24 V Power Supply Option into place when it was installed. YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 27 24, 0, FE M2 (24 to 17) 0.75 (18) 0.5 (20) 0.25 (24 to 20) line, etc. Single wire, 0.25 to 1.5 (24 to 16) YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 28 Table 6 Wire Gauges for Multiple Drives Connection Recommended Gauges mm (AWG) 2 to 3 drives wired in parallel 0.5 (20) YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
-
Page 29: Verifying Operation
Power from 24 V Power Control Circuit Drive Operation Input Power Supply Supply Option Operation in Drive Possible Normal operation Possible Not possible Stop Not possible YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual... -
Page 30: Dimensions
Note: Weights and dimensions listed are for A1000 and the 24 V Power Supply Option together. Contact Yaskawa if you wish to use the 24 V Power Supply Option with another model drive. YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual... - Page 31 Note: Weights and dimensions listed are for A1000 and the 24 V Power Supply Option together. Contact Yaskawa if you wish to use the 24 V Power Supply Option with another model drive. YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 32 Note: Weights and dimensions listed are for A1000 and the 24 V Power Supply Option together. Contact Yaskawa if you wish to use the 24 V Power Supply Option with another model drive. YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 33 Note: Weights and dimensions listed are for A1000 and the 24 V Power Supply Option together. Contact Yaskawa if you wish to use the 24 V Power Supply Option with another model drive. YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 34 Note: Weights and dimensions listed are for A1000 and the 24 V Power Supply Option together. Contact Yaskawa if you wish to use the 24 V Power Supply Option with another model drive. YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
- Page 35 12.1 21.7 11.1 10.3 2.0 21.1 0.3 3.2 6.4 4.3 2.2 8.2 90.8 4A0165A 12.1 21.7 11.1 10.3 2.0 21.1 0.3 3.2 6.4 4.3 2.2 8.2 93.0 YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
-
Page 36: Specifications
WARNING! Electrical Shock Hazard. Use a battery or a double-reinforced power supply to provide power to the 24 V Power Supply Option. Using a different type of power supply may result in death or serious injury. YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual... - Page 37 − − Chapter 1 Revision: Option Label Warnings Chapter 3 Revision: Nameplate March 2009 Chapter 5 Revision: UL and CE compliance Chapter 8 Revision: Specifications YASKAWA ELECTRIC TOBP C730600 48B YASKAWA AC Drive Option 24 V Power Supply Installation Manual...
