Ez Touchpad Indicators - ADT EZ Using Manual

The green READY light shows the status of the zones in your system:
ON indicates that all zones are secure and the system is ready to be armed.
FLASHING indicates that at least one zone is open. To determine the open zone, count the
number of flashes and refer to the zone list on your security panel.
OFF indicates that the optional second deadbolt is not locked. If there are two deadbolts in
the system, the other dead bolt must be locked before the system can be armed.
The red ARMED light ON indicates that the system is armed.
BLINKING with the siren sounding indicates that the system is in alarm.
BLINKING with no siren indicates Alarm Memory (the alarm has been silenced or timed
out). To determine the zone in alarm, count the number of flashes and refer to the zone list
on your security panel. Press SILENCE to clear the alarm memory. (see page 13)
The yellow STAY light ON indicates that the system is armed in the STAY mode, allowing
free movement throughout the premises, while maintaining perimeter protection.
The red FIRE light will flash to indicate that the system is in a Fire Alarm Condition*. If a fire
is in progress, evacuate the premises immediately!
*
Note: This feature may not apply to your system. Consult your installer to determine if your system includes fire protection.
The yellow trouble TBL light will light and the Touch Pad sounder will pulse to indicate that a
system trouble is present. If zone(s) have been bypassed, TBL will light steadily. (See
SYSTEM TROUBLE ERROR CODES, Page 17).
The green AC Light ON indicates that AC Power is present.
4
E Z T O U C H P A D I N D I C AT O R S
READY
ARMED
STAY
FIRE
TBL
