Description
The System Sensor 1400 dual-chamber ionization smoke
detector is specifically designed to meet the performance
requirements of fire detection/alarm systems. This detec-
tor uses a state-of-the-art unipolar sensing chamber. The
detector is designed to provide open area detection and is
compatible with FCI fire alarm control panels. The detec-
tor operation and sensitivity can be tested in place.
The detector has an LED which flashes every ten seconds
indicating that power is being applied to the detector. The
LED lights steadily when the detector is in alarm. A re-
mote LED annunciator is available as an optional acces-
sory.
The 1400 detector includes a tamper-resistant feature
that, when used, prevents removal of the detector without
the use of a tool.
Sensitivity testing is performed by inserting a tool into the
recessed test switch opening.
Field metering of detector sensitivity may be performed
with the aid of a voltmeter and test kit MOD 400R.
Specifications
Nominal sensitivity 1.5%/ft. obscuration
Operating voltage 8.5 - 35 VDC (24 VDC nominal)
Standby current 100 µA maximum
Operating
temperature
32° to 120° F (0° to 49° C)
Operating humidity 10 % - 93 % relative humidity
Air velocity 1,200 ft. per minute maximum
Altitude 10,000 feet
Construction Off-white flame retardant plastic
5.5 inches (14 cm)
Diameter
3.12 inches (8.0 cm)
Height
0.7 lb (310 gm)
Weight
Note: Alarm current is limited by the control panel initiating
device circuit.
Ordering Information
Part Number
Description
1400 Ionization detector
Specifications are for information only, are not intended for installation purposes, and are subject to change without notice. No responsibility is assumed by Gamewell-FCI for their use.
©2006 Gamewell-FCI. All rights reserved.
12 Clintonville Road, Northford, CT 06472 - Tel: (203) 484-7161 - Fax: (203) 484-7118
www.gamewell-fci.com
Features
• Unique dual unipolar sensor provides exceptional
stability.
• Built-in tamper-resistant feature.
• Built-in test switch.
• Built-in visual alarm indicator.
• Remote LED option.
• Compatible with FCI control panels.
• Field metering of detector sensitivity.
• Removable insect screen and cover for field
cleaning.
• Sealed against dirt, insects, and back pressure.
• Insect-resistant screening (.020"/.508mm
openings).
• Convenient terminal strip wiring.
An ISO 9001-2000 Company
GAMEWELL-FCI
1400
System Sensor
Ionization Smoke Detector
1400
9020-0586 Rev. B page 1 of 2
