Format Window
Field
Tone Period(Sec)
Notone Timer(Sec)
Tone Length(Sec)
User Tone Window
Field
Encode (Hz)
Decode Low (Hz)
Decode High (Hz)
22
Description
Controls the length of each individual tone sent by the radio.
Can be set from 0 to 0.255 seconds.
This is the maximum amount of time in between the
transmission of each tone.
The maximum amount of time the radio will wait to decode each
tone on an incoming 5 tone signal.
Description
Allows the user to define the frequencies for a custom 5 tone
format.
Sets the low end of the decodable frequency range for the
frequency defined in the Encode field.
Set the high end of the decodable frequency range for the
frequency defined in the Encode field.
