EXZ2610DL
OWNER'S MANUAL
CONVERTIBLE
BRUSHCUTTER
EXZ2610DL
848JPY93A0 (806)
GB-1
G
G
B
B

Advertisement

Table of Contents
loading

Related Manuals for Zenoah EXZ2610DL

Summary of Contents for Zenoah EXZ2610DL

  • Page 1 EXZ2610DL 848JPY93A0 (806) OWNER’S MANUAL CONVERTIBLE BRUSHCUTTER EXZ2610DL GB-1...
  • Page 2 EXZ2610DL EXPLANATION OF SYMBOLS AND SAFETY WARNINGS MODEL Line head 25.4 cm APPROVAL NUMBER OF CE EXHAUST EMISSION REGULATION GB-2 WARNING!!! RISK OF DAMAGING HEARING Wear head, eye and ear protection. SOUND LEVEL ISO 22868 ISO 10884 LpAav guaranteed 114 dB(A)

  • Page 3: Table Of Contents

    This mark indicates instructions, which must be followed, or it leads to mechanical failure, breakdown, or damage. NOTE This mark indicates hints or directions useful in the use of the product. Husqvarna Zenoah Co., Ltd. 80100101 and up 1st January 2008 Contents 1. Parts location ... 4 2.

  • Page 4: Parts Location

    EXZ2610DL 1. Parts location EXZ2610DL-PUO BC-EX LRT-EX PS-EX HE-EX GB-4 11. Loop handle 12. Suspension point 13. Stop switch 14. Throttle cable 15. Throttle trigger 16. Throttle set button 17. Shaft tube 18. Knob bolt 19. Spark arrester 10. Stater knob 11.

  • Page 5: Specifications

    Transmission ... Centrifugal clutch, rigid drive shaft, Bevel gears (Angle: 90 deg.) Reduction ratio ... 2.538 (33.13) Blade length ... 200 mm Specifications are subject to change without notice. (when using ZENOAH genuine oil) 322 mm 258 mm 258 mm 1.07 mm...

  • Page 6: Warning Labels On The Machine

    EXZ2610DL 3. Warning labels on the machine (1) Read owner’s manual before operating this machine. (2) Wear head, eye and ear protection. (3) Wear foot protection. (4) Wear gloves. (5) Beware of thrown objects. (6) Warning / Attention (7) Keep all children, bystanders and helpers 15 meters away from the machine.

  • Page 7: For Safe Operation

    2. Never use the product, a. when the ground is slippery or when you can’t maintain a steady posture. EXZ2610DL b. At night, at times of heavy fog, or at any other times when your field of vision might be...
  • Page 8 If it continues to rotate even after the throttle has been moved fully back, turn off the engine and take the unit to your authorized ZENOAH servic- ing dealer for repair. USING THE PRODUCT IMPORTANT Cut only materials recommended by the manufacturer.
  • Page 9 HANDLING FUEL 1. The engine of the ZENOAH prod- uct is designed to run on a mixed fuel, which contains highly flam- mable gasoline. Never store cans...
  • Page 10 EXZ2610DL 5. For safe operation (PS-EX only) 1. When you finish cutting in one loca- tion and wish to continue work in an- other spot, turn off the engine, lift up the unit and carry it paying attention to the blade.

  • Page 11: Set Up

    • Install the J-shaped handle to the shaft tube and clamp at a position best for your job. JOINT ATTACHMENT SUSPENSION POINT • Insert the attachment to the main shaft. arrow mark • Tighten the knob bolt securely. EXZ2610DL About 19 inches (48 cm) Knob bolt GB-11...
  • Page 12 EXZ2610DL 6. Set up (BC-EX only) INSTALLING CUTTING ATTACHMENT GUARD • Put the cutting attachment guard on the gearbox, at- tach it with the 4 screws and hardware provided. (1) Cutting attachment guard (2) Plate (3) Screw INSTALLING CUTTING HEAD 1.
  • Page 13 Pay attention to the correct direction of the saw chain. 3. Fit the chain tensioner nut into the lower hole of the guide bar, then install the chain cover, and fasten the mounting nut to finger tightness. (1) Hole (2) Moving direction (3) Chain tensioner nut EXZ2610DL GB-13...
  • Page 14 EXZ2610DL 6. Set up (PS-EX only) 4. Adjust the chain tension by turning the tensioner screw until the tie straps just touch the bottom side of the bar rail. (1) Chain tension adjusting screw (a) Loosen (b) Tighten 5. Tighten the mounting nut securely with the bar tip held up (TORQUE: 8.9 ~ 11.7 N.m./90 ~ 120 kg-cm).

  • Page 15: Fuel And Chain Oil

    • The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added quality oil expressly labeled for air-cooled 2-cycle en- gine use (JASO FC GRADE OIL or ISO EGC GRADE).

  • Page 16: Operation

    8. Operation STARTING ENGINE (HE-EX only) The ZENOAH stick edger is designed for edging lawn in gardens, parks, roadsides and so on. Before starting the engine, take the operating position and adjust the handle position and the wheel height as necessary.
  • Page 17 2. Shift the stop switch to the STOP position. IMPORTANT • Except for an emergency, avoid stopping the engine while pulling the throttle lever. IMPORTANT • When it doesn’t stop at the stop switch, move the choke level to the closed position. (1) Choke lever EXZ2610DL GB-17...
  • Page 18 EXZ2610DL 8. Operation ADJUSTING THROTTLE CABLE • The normal play is 1 or 2 mm when measured at the carburetor side end. Readjust with the cable adjuster as required. 1 ~ 2 mm (1) Cable adjuster ADJUSTING IDLING SPEED (1) Idle adjusting screw 1.
  • Page 19 • Each time the head is bumped, the line advances about 1 inch (25.4 mm). For better effect, tap the head on bear ground or hard soil. Avoid bumping in thick, tall grass as the engine may stall by overload. EXZ2610DL GB-19...
  • Page 20 Choose a suitable recommended cutting attachment according to the object to be cut. • When replacing blade always be sure to use prod- ucts, which have been certified by ZENOAH. WARNING When sharpening, removing, or reattaching the blade, be sure to wear thick, sturdy gloves and use only proper tools and equipment to prevent injury.
  • Page 21 • If you find any error to the blade, discard it and replace with a new one, which is certified by ZENOAH. By using the shoulder strap, hang the unit on your right side. Adjust the strap length so that the cutting head may become parallel to the ground. EXZ2610DL GB-21...
  • Page 22 EXZ2610DL 8. Operation (Optional blade usage BC-EX only) WARNING Make sure to use shoulder strap and cutting attach- ment guard. If not, it is very dangerous when you slip or lose your balance. WARNING CONTROLLING BLADE BOUNCE Blade thrust can cause serious personal injury. Care- fully study this section.
  • Page 23 A temporary increase in oil flow is often desirable when cutting things like hard- wood or wood with a lot of pitch. EXZ2610DL GB-23...
  • Page 24 3. When starting to edge, run the engine at full throttle, and slowly have the blade cut into the edge groove. NOTE • Do not use the HE-EX to make a new groove into the ground. Such usage will not be covered by ZENOAH Warranty. BLADE ROTATION...

  • Page 25: Maintenance

    ✔ inspect/sharp FUEL FILTER • When the engine runs short of fuel supply, check the fuel cap and the fuel filter for blockage. EXZ2610DL Note after after replace, if necessary replace carburetor if necessary GAP: .025 in (0.6 ~ 0.7 mm) ✔...
  • Page 26 EXZ2610DL 9. Maintenance SPARK PLUG • Starting failure and misfiring are often caused by a fouled spark plug. Clean the spark plug and check that the plug gap is in the correct range. For a re- placement plug, use the correct type specified by ZENOAH.
  • Page 27 6. While holding the spool against the housing, pull the line ends to release them from the slot. 7. Line up the slot on the bottom cap with the hook on the housing, press the cap against the housing until it clicks. EXZ2610DL (BC-EX only) GB-27...
  • Page 28 If the blades become so worn down that it is no longer possible to eliminate the gap between them, you should contact the au- thorized ZENOAH servicing dealer from which you purchased your ZENOAH trimmer to have the blades resharpened or re- placed. TRANSMISSION The reduction gears are lubricated by multipurpose, lithium-based grease in the transmission.
  • Page 29 Make sure the saw chain is held securely. • Make sure the engine is stopped. • Use a round file of proper size for your chain. Chain type : 90SG File size EXZ2610DL 0.3 mm : 5/32 in (4.0 mm) GB-29...
  • Page 30 EXZ2610DL 9. Maintenance Place your file on the cutter and push straightforward. Keep the file position as illustrated. After every cutter has been set, check the depth gauge and file it to the proper level as illustrated. .025" (0.65 mm)

  • Page 31: Storage

    (exhaust port) → carbon is built-up air cleaner cylinder fin, fan cover When your unit seems to need further service, please consult with our ZENOAH service shop in your area. 10. Storage (HE-EX only) Aged fuel is one of major causes of engine starting fail- ure.

  • Page 32: Limited Warranty

    30 days if used for rental purpose) from the date of initial purchase. THE PURCHASER SHALL BEAR COSTS OF TRANS- PORTING THE UNIT TO AND FROM THE ZENOAH DEALER. THE PURCHASER SHALL NOT BE CHARGED FOR DI- AGNOSTIC LABOR WHICH LEADS TO THE DETERMI-...
