- Page 1 EXZ2600DL 115 39 30-26 (007) OWNER’S MANUAL CONVERTIBLE BRUSHCUTTER EXZ2600DL GB-1...
- Page 2 EXZ2600DL EXPLANATION OF SYMBOLS AND SAFETY WARNINGS WARNING!!! RISK OF DAMAGING HEARING Wear head, eye and ear protection. MODEL SOUND LEVEL VIBRATION LEVEL ISO 7916 EN 27917 ISO 10884 idling racing measured guaranteed 4.3 m/s 25.4 cm 93 dB(A) 113 dB(A) 114 dB(A) 8.1 m/s...
-
Page 3: Table Of Contents
EXZ2600DL SAFETY FIRST Contents Instructions contained in warnings within this manual marked with a symbol concern critical points which must be taken 1. Parts location ..........4 into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions 2. -
Page 4: Parts Location
EXZ2600DL 1. Parts location EXZ2600DL-PUO 1. Loop handle 2. Shoulder strap hanger BC-EX 3. Ignition switch 4. Throttle cable 5. Throttle lever 6. Throttle set button 7. Drive shaft housing 8. Knob bolt 9. Spark arrester 10. Starter knob 11. Fuel tank 12. -
Page 5: Specifications
Max. output ..........1.2 Hp (0.9 kW) at 7500/min-1 (rpm) Idle speed ................3000 ±200/min-1 (rpm) Fuel ................Mixture (Gasoline 50 : Oil 1) (when using ZENOAH genuine oil) Carburetor ................ Walbro Diaphragm type Spark plug ..................NGK CMR7A Fuel tank capacity ....................0.65 L... -
Page 6: Warning Labels On The Machine
EXZ2600DL 3. Warning labels on the machine (1) Read owner’s manual before operating this machine. (2) Wear head, eye and ear protection. (3) Wear foot protection. (4) Wear gloves. (5) Beware of thrown objects. (6) Warning / Attention (7) Keep all children, bystanders and helpers 15 meters away from the machine. -
Page 7: For Safe Operation
EXZ2600DL 5. For safe operation 1. Read this manual carefully until b. At night, at times of heavy fog, you completely understand and or at any other times when follow all safety and operating your field of vision might be instructions. - Page 8 ZENOAH servic- 2. Check the condition of working ing dealer for repair. area to avoid any accident by hit-...
- Page 9 5. For safe operation • IF SOMEONE COMES HANDLING FUEL 1. Guard against hazardous situa- 1. The engine of the ZENOAH prod- tions at all times. Warn adults to uct is designed to run on a mixed keep pets and children away from fuel, which contains highly flam- the area.
-
Page 10: Set Up
EXZ2600DL 6. Set up MOUNTING ENGINE (PS-EX only) 1. Push the drive shaft housing toward the clutch hous- ing and rotate it by hand to check that the drive shaft is engaged with the gears. • Insert the grip to the shaft tube. - Page 11 EXZ2600DL 6. Set up 6. Set up (BC-EX only) (LRT-EX only) INSTALLING DEBRIS GUARD ATTACHING THE TRIMMING MECHANISM • Put the debris guard on the gearbox, attach it with the 4 screws and hardware provided. (1) Debris guard (1) Main pipe...
- Page 12 EXZ2600DL 6. Set up (PS-EX only) ATTACHING THE PRUNING MECHANISM WARNING The saw chain has very sharp edges. Use protec- tive gloves for safety. 1. Loosen a nut and remove the chain cover. 2. Mount the guide bar then fit the saw chain around the bar and sprocket.
- Page 13 EXZ2600DL 6. Set up 6. Set up (PS-EX only) (HE-EX only) 4. Adjust the chain tension by turning the tensioner screw 1. Insert the drive shaft into the clutch drum, then attach until the tie straps just touch the bottom side of the the gearbox to the shaft tube as aligning the position- bar rail.
-
Page 14: Fuel And Chain Oil
• The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added quality oil expressly labeled for air-cooled 2-cycle en- gine use (JASO FC GRADE OIL or ISO EGC GRADE). -
Page 15: Operation
As some oils may be difficult to (HE-EX only) agitate depending on oil ingredients, sufficient agi- The ZENOAH stick edger is designed for edging lawn in tation is necessary for the engine to last long. Be gardens, parks, roadsides and so on. - Page 16 EXZ2600DL 8. Operation WARNING 5. Set the ignition switch (a) to the “I” position. Set the throttle lever to the start position (1 → 2 → 3). The cutting head will start rotating upon the engine Place the unit on a flat, firm place.
- Page 17 EXZ2600DL 8. Operation 7. Move the choke lever downward to open the choke. ADJUSTING THROTTLE CABLE And restart engine. • The normal play is 1 or 2 mm when measured at the carburetor side end. Readjust with the cable adjuster as required.
- Page 18 EXZ2600DL 8. Operation (BC-EX only) CUTTING WORK (LINE HEAD USAGE) ADJUSTING THE LINE LENGTH • Your brush cutters are equipped with a semi- auto WARNING type nylon line head that allows the operator to ad- vance the line without stopping the engine. When the 1.
- Page 19 Change the debris guard, which is suitable for the metal blade. • When replacing blade always be sure to use prod- ucts, which have been certified by ZENOAH. WARNING When sharpening, removing, or reattaching the blade, be sure to wear thick, sturdy gloves and use only proper tools and equipment to prevent injury.
- Page 20 EXZ2600DL 8. Operation (Optional blade usage BC-EX only) STARTING THE ENGINE OPERATION Please refer to 5. For safe operation (P. 7 ~ 9), 8. Ope- 1. Check the bolt to fasten the blade and be sure the ration (P. 15 ~ 17).
- Page 21 EXZ2600DL 8. Operation (Optional blade usage BC-EX only) WARNING MAINTENANCE BLADE Make sure to use shoulder strap and debris guard. If • Check the blade and the fasteners for looseness, not, it is very dangerous when you slip or lose your cracking, or bending.
- Page 22 EXZ2600DL 8. Operation (LRT-EX only) WARNING Adjusting the angle of the cutting blades This product is equipped with extremely sharp blades, Tighten and when used improperly these blades can be ex- tremely dangerous and improper handling can cause accidents, which may in turn lead to serious injury or death.
- Page 23 EXZ2600DL 8. Operation (PS-EX only) Checking oil supply Adjust the pump as follows: After starting the engine, run the chain at medium speed 1. Stop the engine and make sure the stop switch is in and see if chain oil has scattered off, as shown in the the OFF position.
- Page 24 3. When starting to edge, run the engine at full throttle, and slowly have the blade cut into the edge groove. BLADE ROTATION NOTE • Do not use the HE-EX to make a new groove into the ground. Such usage will not be covered by ZENOAH Warranty. GB-24...
-
Page 25: Maintenance
EXZ2600DL 9. Maintenance Every Every Every Before System/components Procedure Note hours hours hours after after after ✔ fuel leaks, fuel spillage wipe out ✔ ✔ fuel tank, air filter, fuel filter inspect/clean replace, if necessary see adjusting replace carburetor ✔... - Page 26 EXZ2600DL 9. Maintenance SPARK PLUG SPARK ARRESTER • Starting failure and misfiring are often caused by a • The muffler is equipped with a spark arrester to pre- fouled spark plug. Clean the spark plug and check vent red hot carbon from flying out of the exhaust out- that the plug gap is in the correct range.
- Page 27 EXZ2600DL 9. Maintenance 9. Maintenance (BC-EX only) IMPORTANT REFILLING TRIMMING LINE 1. For replacement line, use a diameter of .095 in • If waste gets stuck and causes blockage around the (2.4 mm). The spool is capable for a line upto 27 ft intake air cooling vent or between the cylinder fins, it (8 m) on the 4"...
- Page 28 If the blades become so worn down that it is no longer possible to eliminate the gap between them, you should contact the au- thorized ZENOAH servicing dealer from which you purchased your ZENOAH trimmer to have the blades resharpened or re- placed. • The reduction gears are lubricated by multipurpose, GEAR CASE lithium-based grease in the gear case.
- Page 29 EXZ2600DL 9. Maintenance (PS-EX only) OILING PORT SPROCKET Dismount the guide bar and check the oiling port for Check for extensive wear, and replace it when the teeth clogging. are worn over 0.3 mm. 0.3 mm (1) Oiling port (1) Sprocket GUIDE BAR Remove sawdust in the bar groove and the oiling port.
- Page 30 EXZ2600DL 9. Maintenance (PS-EX only) Place your file on the cutter and push straightforward. Make sure every cutter has the same length and edge Keep the file position as illustrated. angles as illustrated. (4) Cutter length (5) Filing angle (6) Side plate angle...
-
Page 31: Storage
→ wipe away air cleaner → clogged with dust → wash cylinder fin, fan cover → clogged with dust → clean When your unit seems to need further service, please consult with our ZENOAH service shop in your area. GB-31... -
Page 32: Limited Warranty
WHICH HAVE BEEN DAMAGED BY NEGLIGENCE OF THE PURCHASER SHALL BEAR COSTS OF TRANS- INSTRUCTION LISTED IN THE OWNER/OPERATOR PORTING THE UNIT TO AND FROM THE ZENOAH MANUAL FOR PROPER USE AND MAINTENANCE OF DEALER. THE UNITS ACCIDENT MISHANDLING, ALTERATION,...
