Installing Batteries In The Remote Control; Front Panel Controls - Zenith R40W46 Installation And Operating Manual

Remote Control Key Functions / TV Setup
26. REMOTE CONTROL SENSOR
27. LED (Light Emitting Diodes) Displays
LEDs light when source is selected or feature is present.
28. INDEX
Switches LED Display on or off.

Installing Batteries in the Remote Control

• Remove the battery compartment cover on the back side and insert the
batteries with correct polarity.
• Install two 1.5V, AA type batteries. Don't mix used and new batteries.

Front Panel Controls

This is a simplified representation of front panel.
* R40W46, R40W46F, R45W46, R45W46F
26
* R50W46, R57W46
26
15
tv/video
on/off
4 12 23 28
Stopper
on/off
15
menu enter index
CATV
Securing TV Position
• Position the TV and prevent it from being moved, by
placing the 4 stoppers under the roller casters on the
bottom of the TV.
• Casters (on TV bottom)
Use to turn and move the TV easily.
8
tv/video menu enter mute
4 12 23 20 25
V I D E O
25 27
vol ch
10
vol ch
10
