- Page 1 TECHNICAL MANUAL Visto ViP WiFi Art. VS8111...
-
Page 2: Table Of Contents
• The Comelit application is available on App Store and Google Play and is supported by devices with iOS 10 (or later) and by the most common Android devices with Android version 4.4 or higher, however some functionalities may be limited depending on the model and the version. -
Page 3: Visto Vip Wifi
Visto ViP WiFi is a Wi-Fi external video entry unit for use in Comelit ViP systems. Depending on the system configuration, Visto ViP WiFi makes it possible to receive video entry calls on ViP monitors or directly on smartphones and tablets, via the Comelit app. -
Page 4: Description
Adjustable supports of Visto ViP WiFi (available to purchase separately) Installation Warning We recommend installing Visto ViP WiFi near the router. Always check the quality of the Wi-Fi signal before final installation of the product. A Wi-Fi signal that is too weak may compromise its operation. -
Page 5: Surface Mounting
Surface mounting Guide to LED readings Start In communication Wi-Fi not available Door opening No Wi-Fi configuration Standby confirmation available Awaiting configuration Weak Wi-Fi signal Call in progress QR code Maximum connection distances POWER SUPPLY max. 24 VDC 100 m UTP5 cat. -
Page 6: Adapter 3522
Adapter 3522 Adapter 3522 is only required in systems where a power supply unit with 12 - 20 VAC output is already installed, and if you want to make use of a mechanical or electronic bell already fitted in the system. 12 - 20 VAC power supply input from transformer Power supply output for Visto ViP Wi-Fi 3. -
Page 7: Wiring Diagrams
Case 1 Visto ViP WiFi, connected to the Wi-Fi network for the building and used as a secondary external station in an existing ViP system, transmits video entry calls to the monitor or other devices in the ViP system for the apartment. - Page 8 Visto ViP WiFi, connected to the Wi-Fi network for the apartment and used as a secondary external station in an existing ViP system, transmits video entry calls to the Wi-Fi monitor or other devices in the ViP system for the apartment that in turn forward the call to the Comelit app.
- Page 9 (B) Using art. VS8111 to transmit calls to the Comelit app Visto ViP WiFi, connected to the Wi-Fi network for the apartment, is used as an independent solution and forwards video entry calls directly to the Comelit app. Configuration procedure via Comelit app on page 12...
- Page 10 Variant with power supplied by art. 3534 Variant with power supplied by art. 3522 3534 3534 110/230 VAC 110/230 VAC 110/230 VAC 3534 110/230 VAC 12-20 VAC 12-20 VAC 3522 3522 1595 3522 VS8111 VS8111 VS8111 VS8111 VS8111 VS8111 VS8111 NO C NO C NO C...
-
Page 11: Comelit App
Comelit App Once the download from the relevant store has been completed and installed, the COMELIT app allows you to connect art. VS8111 to the ViP system or configure it to transmit calls directly to smartphones and tablets. Depending on your system, you need to carry out one of the 2 procedures detailed below (A or B):... - Page 12 (B) Configuration procedure for transmitting calls to the Comelit app Applies to systems on page 9 NO C Create a new system then continue with configuration. Further information can be found in the Comelit app manual, available on the website pro.comelitgroup.com...
-
Page 13: Reset Procedures
Reset procedures Reset Wi-Fi parameters 5 sec. WHITE / VIOLET New Wi-Fi parameters The procedure varies depending on the type of configuration carried out previously for VS8111. Depending on your system, you need to carry out one of the 2 procedures detailed below (A or B): Case A It will be necessary to repeat Continue with the... -
Page 14: Restore Factory Parameters
Restore factory parameters 5 sec. WHITE / VIOLET C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
