S EALE D B UR NE R R AN GE TO P S
Planning Information
The platform to support the sealed burner rangetop must
include a cut-out for electrical and gas supply connections.
Refer to the chart below for minimum base support.
When installing against a combustible surface, a minimum
254 mm riser is required for 91 cm and 122 cm sealed
burner rangetops with a charbroiler or griddle. Follow all
minimum clearances to combustible surfaces shown in the
illustration on the following page.
A Wolf pro ventilation hood is recommended with the sealed
burner rangetop.
A downdraft can be used with model ICBSRT304. An acces-
sory trim kit is necessary for this installation. Contact an
authorized Wolf dealer for details.
INSTALL AT IO N REQUIREMEN T S
PLATFORM
Thickness
BASE SUP PORT
76 cm Rangetop
91 cm Rangetop
122 cm Rangetop
|
5 English
E L EC TR IC AL
Installation must comply with all applicable electrical codes
and be properly grounded (earthed).
Locate the electrical supply within the shaded area shown
in the illustration on the following page. A separate circuit,
servicing only this appliance is required.
E L E CTRIC AL RE QU IREME N TS
Electrical Supply
Service
Receptacle
Power Cord
GA S S U P PLY
Installation must conform with all applicable gas codes.
19 mm
A gas supply line of 19 mm rigid pipe
MI N
91 kg
provided to the rangetop. If local codes permit, a
113 kg
certified, .9 m long, 13 mm or 19 mm ID flexible appliance
136 kg
connector is recommended to connect the units ISO 7/1-14
female inlet to the gas supply line.
Wolf natural gas rangetops will function up to 3124 m in
altitude without adjustment and LP gas ranges will function
up to 2621 m. If the installation exceeds these elevations,
contact an authorized Wolf dealer for a high altitude
conver-sion kit.
GA S RE QUI RE ME NT S
N ATURAL GAS
Supply Pressure
L P GAS
Supply Pressure
grounded, 220-240 VAC; 50/60 Hz
0.2 A
3-prong grounding-type
2 m
is advisable to be
1 Kpa
2.75 Kpa
