Firmware History

Firmware Revision 7.12 (includes all features of revisions 6.14 and 6.12)
Firmware Enhancements and Features
1. A new IF bandwidth filter setting of 6000 Hz can now be selected in addition to the
previously available settings of 10, 30, 100, 300, 1000, 3000, and 3700 Hz.
2.
Swept list mode, a new list frequency sweep mode, takes data while sweeping through the
defined frequency points, increasing throughput by up to 6 times over a stepped sweep. In
addition, this mode allows the test port power and IF bandwidth to be set independently for
each segment that is defined.
3.
New HP-IB commands:
HP-IB Cmd
SEGIFBW[D]
SEGPOWER[D]
Firmware Revision 6.14 (includes all features of revision 6.12)
Firmware Revision 6.14 is the revised code for both the HP 8753D (including Option 011) and
the HP 8719D/8720D/8722D
Firmware Enhancements and Features
1.
A major improvement has been made in disk writes for the CITIfile and S2P (Touchstone)
ASCII formats.
2. Error numbers (error table) are now synchronized with all revisions.
3. Data files with S2P now have suffixes dependent on the channel number (Sl or S2).
4. In operating parameters pages, the specific model number has been replaced with the word
ANALYZER.
5. Calibration kit labels under the SELECT CAL KIT menu now include the HP calibration kit
most commonly associated with that connector geometry.
6. Single parameter, linear magnitude marker display format now shows in engineering units
(autoscales to U, mu, pU, etc.). HP 8753D (including Option 011) only.
7. Changed the list table default frequency from MHz to GHz. HP 8719D/8720D/8722D only.
8. Updated the 7mm calibration constants based on the HP 85050 series calibration kits.
HP 8719D/8720D/8722D only.
16
Description
Enables/disables the IFBW setting for a list-frequency table in swept
list mode.
Enables/disables the power setting for a list-frequency table in
swept list mode.
with a list-frequency table.
Sets the IFBW for the active segment of a list-frequency table in
swept list mode.
Sets the power for the active segment of a list-frequency table in
swept list mode.
Network Analyzers.
Installation Note 08720-90372
