Introduction
See the Important Safety and Product Information guide in the
product box for product warnings and other important
information.
Device Overview
Press to open the menu and scroll through menu
options.
Press to turn on the device.
Press to open the menu and scroll through menu
options.
Hold to turn off the device.
View tournament mode status.
Tournament
mode LED
Press to range with the laser. While playing golf, the
flag finder feature starts automatically.
Press to select menu options.
Rotate the eyepiece to focus the screen.
Adjustable diopter
View device and battery status.
Status LED
Pull up to access the micro-USB power and data
port.
Weather cap
Connect a compatible USB cable to charge the
Micro-USB power
device or transfer data using your computer.
and data port
(under weather
cap)
View manufacturer's identification and certification.
Device label
Status LEDs
LED Activity
Solid blue (for 5 seconds after turning
on)
Alternating red and blue (for 5 seconds
after turning on)
Off
Slow flashing blue
Introduction
WARNING
Status
The device is turned on.
The battery is low.
The device is in active mode.
The device is in standby mode.
LED Activity
Solid red (after holding the power
button)
Rapid flashing red (connected to a
power source)
Solid blue and flashing red (connected
to a power source)
Solid red (connected to a power
source)
Slow flashing red
Charging the Device
This product contains a lithium-ion battery. To prevent the
possibility of personal injury or product damage caused by
battery exposure to extreme heat, store the device out of direct
sunlight.
To prevent corrosion, thoroughly dry the USB port, the weather
cap, and the surrounding area before charging or connecting to
a computer.
The device is powered by a built-in lithium-ion battery that you
can charge using a standard wall outlet or a USB port on your
computer.
NOTE: The device will not charge when outside the approved
temperature range
(Specifications, page
1
Pull up the weather cap from the USB port.
2
Plug the small end of the USB cable into the USB port on the
device.
3
Plug the large end of the USB cable into an external power
source, such as an AC adapter or a USB port on your
computer.
4
Charge the device completely.
TIP: You can turn off the device to charge it faster.
Turning On the Device
The first time you turn on the device, you are prompted to
choose a language, select a unit of measure, and set your driver
distance.
1
Press
.
2
Follow the on-screen instructions.
Standby Mode
To conserve battery life, the device goes into standby mode
when not in use. The device wakes up when you hold it with
your thumb in the groove on the bottom of the device or push
any button.
Status
The device is turned off.
The device is charging in
energy-saving mode.
The device is charging.
Charging is complete.
A software update is in
progress.
WARNING
NOTICE
4).
