USER GUIDE
TB-4162
Screw Terminal Block for the PXIe-4162
This document explains how to install and use the TB-4162 terminal block with a PXIe-4162
source measure unit (SMU) and includes TB-4162 specifications.
The TB-4162 terminal block is used for screw terminal connections with the PXIe-4162 SMU.
Read this document and the documents listed in the additional resources section about
installation, configuration, and operation of this equipment before you install, configure,
operate, or maintain this product. Users are required to familiarize themselves with installation
and wiring instructions in addition to requirements of all applicable codes, laws, and standards.
Caution
the model in a manner not specified can damage the model and compromise the
built-in safety protection. Return damaged models to NI for repair.
Attention
documentation utilisateur. L'utilisation d'un modèle de toute autre façon que celle
spécifiée risque de l'endommager et de compromettre la protection de sécurité
intégrée. Renvoyez les modèles endommagés à NI pour réparation.
Notice
This device is intended for use only with the PXIe-4162 SMU. For more
information about the PXIe-4162, refer to ni.com/manuals.
Contents
Icons.......................................................................................................................................... 2
Getting Started with the TB-4162............................................................................................. 2
Kit Contents and Other Equipment................................................................................... 2
Installing the TB-4162...................................................................................................... 2
TB-4162 Specifications.............................................................................................................8
Definitions.........................................................................................................................8
Screw Terminal Wiring..................................................................................................... 9
Physical............................................................................................................................. 9
Environmental Guidelines.................................................................................................9
Compliance and Standards......................................................................................................10
Environmental Management........................................................................................... 10
CE Compliance .............................................................................................................. 10
Export Compliance......................................................................................................... 10
Product Certifications and Declarations..........................................................................11
Observe all instructions and cautions in the user documentation. Using
Suivez toutes les instructions et respectez toutes les mises en garde de la
