Page 16
Apple iPad iPhone Apple Inc. は、 のサービスマークです。 App Store Apple Inc. ※ は の商標です。 および ロゴは の商標です。 Android Google Inc. Google Play Google Play Google Inc. ※ のワー ドマークおよびロゴは が所有する登録商標であり、 Bluetooth® Bluetooth SIG, Inc. Koninklijke またはその関連会社は、 これらのマークをライセンスに基づいて使用しています。 Philips N.V. その他の商標や商品名はそれぞれの所有者に帰属します。...
Page 33
English Introduction Congratulations on your purchase and welcome to Philips! To fully benefit from the support that Philips offers, register your product easily via the GroomTribe app or at http://www.philips.com/s7000-support. Download the GroomTribe app to create your Personal Shaving Plan today. It will provide you ongoing guidance on how to tackle your skin issue.
Page 34
English This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 35
English - If your shaver comes with a cleaning system, always use the original Philips cleaning fluid (cartridge or bottle, depending on the type of cleaning system). - Always place the cleaning system on a stable, level and horizontal surface to prevent leakage.
Page 36
Article 10(10) as it has no restrictions on putting into service in all EU member states. Hereby Philips declares that this appliance is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The declaration of conformity may be consulted at www.philips.com/support.
Page 37
10 Battery charge indicator 11 Socket for small plug 12 Supply unit 13 Cleaning brush 14 Small plug 15 Cap of SmartClean system 16 SmartClean system (S7970/26 only) 17 On/off button 18 Replacement symbol 19 Rinsing symbol 20 Ready symbol 21 Battery symbol...
Page 38
If you need further support, visit http://www.philips.com/s7000-support. Sensitive shave settings The shaver has a feature that allows you to personalize your shave settings. Choose between three settings depending on your personal shaving needs: extra sensitive(xs), sensitive (s) and normal.
Page 39
English 'Unplug for use' reminder The ‘unplug for use’ reminder flashes to remind you to disconnect the shaver from the wall socket before you can switch it on. Note: This shaver is waterproof. It is suitable for use in the bath or shower and for cleaning under the tap.
Page 40
English Battery low When the battery is almost empty, the battery charge indicator flashes orange. At this point there is enough energy left for one shave. Bluetooth® connection The shaver is equipped with Bluetooth ® 4.1 to connect your shaver to the app. Bluetooth is automatically activated when you switch on the shaver for the first time.
Page 41
Note: When the battery is full, the display switches off automatically after 30 minutes. Charging in the SmartClean system (S7970/26 Only) 1 Put the small plug in the back of the SmartClean system. 2 Put the supply unit in the wall socket.
Page 42
Pair the shaver and smartphone The GroomTribe app is compatible with a wide range of iPhone and Android™ smartphones. More information is available at: http://www.philips.com/s7000-support. 1 Download the GroomTribe App from your app store. 2 Make sure Bluetooth on the smartphone is switched on.
Page 43
English 2 Unpair your smartphone: go to ‚Settings‘ on your smartphone and select Bluetooth. Then select ‚ Shaver S79xx‘ and press ‚forget‘ or ‚unpair‘. Note: The unpairing procedure may vary per smartphone. Please check your smartphone manual for more information. Using the shaver Always check the shaver and all accessories before use.
Page 44
English Note: Make sure you have a good Bluetooth and Internet connection to fully benefit from the app. 4 Set your sensitive shave settings. 5 Keep the smartphone and shaver close to each other in order to stay connected and synchronize your shaves.
Page 45
English Follow the advice provided by the app and shave regularly (at least 3 times a week) with this shaver for a period of 3-4 weeks to allow your skin to adapt to the new shaver. Shaving tips - For the best results on skin comfort, pre-trim your beard if you have not shaved for 3 days or longer.
Page 46
English 1 Apply some water to your skin. 2 Apply shaving gel to your skin. 3 Rinse the shaving unit with lukewarm water to ensure that the shaving unit glides smoothly over your skin. 4 Switch on the shaver. 5 Move the shaving heads over your skin in circular movements to catch all hairs growing in different directions.
Page 47
English 2 Pull the attachment straight off the shaver. Note: Do not twist the attachment while you pull it off the shaver. 3 Attach the precision trimmer attachment to the shaver ('click'). 4 Switch on the shaver. 5 Hold the trimmer perpendicular to the skin and move the shaver downwards while you exert gentle pressure.
Page 48
English Cleaning the shaver with SmartClean Preparing the SmartClean system for use Caution: Do not tilt the SmartClean system to prevent leakage. Note: Hold the SmartClean system while you prepare it for use. Note: If you clean the shaver in the SmartClean system once a week, the SmartClean cartridge lasts approximately three months.
Page 49
English 6 While holding the SmartClean system with one hand, gently push the top part of the SmartClean system back down (‘click’). Using SmartClean Note: If you use the shaver with shaving foam, shaving gel or pre-shave products, briefly rinse the shaver warm water before you clean it in SmartClean.
Page 50
English 4 Press the on/off button on SmartClean to start the cleaning program. During the cleaning phase, the cleaning symbol flashes. When the cleaning phase is done (after approx. 10 minutes), the cleaning symbol lights up continuously. Next, the ready symbol lights up continuously. 30 minutes after the cleaning program and charging are done, SmartClean switches off automatically.
Page 51
English 1 While holding SmartClean with one hand, press the button on the side of SmartClean and lift the top part of the SmartClean. 2 Remove the cleaning cartridge from SmartClean and pour out any remaining cleaning fluid. You can safely pour the cleaning fluid down the sink. 3 Discard the empty cleaning cartridge.
Page 52
English Cleaning the shaver under the tap Clean the shaver after every shave for optimal performance. Always check if the water is too hot, to prevent burning your hands. Never dry the shaving unit with a towel or tissue, as this may damage the shaving heads. While rinsing the shaving unit, water may drip out of the bottom of the shaver.
Page 53
English 6 Attach the shaving head holder to the bottom part of the shaving unit (‘click’). Thorough cleaning We advise you to clean the shaving heads thoroughly once a month or when the shaver does not shave as well as it used to. 1 Switch off the shaver.
Page 54
English 5 Remove the shaving heads from the shaving head holder. Each shaving head consists of a cutter and guard. Note: Do not clean more than one cutter and guard at a time, since they are all matching sets. If you accidentally put a cutter in the wrong shaving guard, it may take several weeks before optimal shaving performance is restored.
Page 55
English Cleaning the click-on attachments Cleaning the precision trimmer attachment Clean the trimmer attachment after each use. 1 Switch on the appliance with the precision trimmer attachment attached. 2 Rinse the attachment under a warm tap. 3 After cleaning, switch off the appliance. 4 Carefully shake off excess water and let the attachment air-dry completely.
Page 56
Replace damaged shaving heads immediately. Always replace the shaving heads with original Philips shaving heads (see ‚Ordering accessories‘). Replacement reminder The notification symbol lights up when there is an important message for you in the app.
Page 57
- Store the shaver in the pouch supplied. Ordering accessories To buy accessories or spare parts, visit www.philips.com/parts-and-accessories or go to your Philips dealer. You can also contact the Philips Consumer Care Center in your country (see the international warranty leaflet for contact details).
Page 58
Please take your product to an official collection point or a Philips service center to have a professional remove the rechargeable battery. Follow your country’s rules for the separate collection of electrical and electronic products and rechargeable batteries.
Page 59
English 3 Take out the power unit. 4 Bend the snap hooks aside and remove the transparent cover of the power unit. 5 Lift out out the battery holder and cut the wires with a pair of cutting pliers or scissors. 6 Bend the battery tags aside with a pair of cutting pliers or a screw driver.
Page 60
The shaving heads (cutters and guards) are not covered by the terms of the international warranty because they are subject to wear. Registration To fully benefit from the support that Philips offers, register your product easily via the GroomTribe or SkinAnalyst app or at http://www.philips.com/s7000-support.
Page 61
English Problem Possible cause Solution I cannot connect the You have not Download the shaver. downloaded the app. GroomTribe or SkinAnalyst app from your App store. Your shaver and Make sure the shaver smartphone are not and smartphone paired yet. are paired (see 'Preparing for use').
Page 62
English Problem Possible cause Solution I cannot change You can only change the sensitive shave your shaver settings settings on the via the app, so be shaver. sure to download it. Make sure there is a good connection between the shaver and your smartphone.
Page 63
English Problem Possible cause Solution Water is leaking from During cleaning, This is normal and the bottom of the water may collect not dangerous shaver. between the inner because all body and the outer electronics are shell of the shaver. enclosed in a sealed power unit inside the shaver.
Page 64
SmartClean to clean your shaver. The cleaning Replace the cleaning cartridge needs to cartridge. be replaced. You have used Only use the original Philips another cleaning Norelco cleaning cartridge. fluid than the original Philips Norelco cleaning cartridge. The hole of the...
Android is a trademark of Google Inc. Google Play and the Google Play logo are trademarks of Google Inc. The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Philips Personal Care is under license.
