SAFETY FIRST!
Before operating this equipment, read this
Owner's Manual and the separate manual
supplied by the engine manufacturer.
Model
52068 - 5HP Recoil Start
52069 - 6HP Electric Start
OWNER'S MANUAL
Trimmer/Mower
Safety
•
Assembly
•
Controls
•
Operation
•
Maintenance
•

Parts List

•
(Electric Start Model Shown)
GARDEN WAY INCORPORATED

Advertisement

Table of Contents
loading

Related Manuals for Bolens 52068 - 5HP

Summary of Contents for Bolens 52068 - 5HP

  • Page 1: Parts List

    SAFETY FIRST! Before operating this equipment, read this Owner's Manual and the separate manual supplied by the engine manufacturer. Model 52068 - 5HP Recoil Start 52069 - 6HP Electric Start OWNER’S MANUAL Trimmer/Mower Safety • Assembly • Controls • Operation •...

  • Page 2: Table Of Contents

    Dear Owner: You now own one of the finest trimmer/mowers available. It was designed to easily handle a wide variety of trimming, mowing and clearing chores. You will find the machine to be an invaluable tool in caring for your property.

  • Page 3: Section 1: Safety

    (Electric Start Model) Handlebar Height Adjuster 14. Wait until the trimmer head comes to a complete stop, shut the engine off, and disconnect the spark plug wire before installing or removing trimmer line. Be sure trimmer head is securely attached before operating equipment.

  • Page 4: Slope Operation

    Remove key on electric start models. 4. Keep all nuts and bolts tight, espe- cially the trimmer head attachment bolts, and keep equipment in good condition. Check mounting hardware on trimmer head every time you change trimmer line and prior to each use.

  • Page 5: Safety Decals

    .155" diameter trimmer line. Never use other lengths, diameters or material as trimmer line. 11. Trimmer line moves at high speed and can cut. Always stop the engine and let all moving parts stop before replacing the trimmer lines. Let the engine cool.

  • Page 6: Section 2: Assembly

    3. Compare the parts inside the carton with the following list: • Trimmer/Mower Assembly (A, Figure 2-1) • Extra Trimmer Line (B, Figure 2-1): six pieces of heavy-duty gauge .130" dia. line and six pieces of extra-heavy-duty gauge .155" dia. line.

  • Page 7: Step 3: Attach Throttle Control Lever

    5. Use two cable ties (F, Figure 2-2) to secure the trimmer head control cable (C) and the electrical wiring harness (O) to the handlebar at the locations shown. STEP 3: ATTACH THROTTLE CONTROL LEVER 1. One end of the Throttle Control Cable (H, Figure 2-3) is attached to the engine.

  • Page 8: Step 6: Connect And Charge Battery

    Section 2: Assembly STEP 6: CONNECT AND CHARGE BATTERY (ELECTRIC START MODELS) DANGER • Wet conditions can cause an electric shock hazard during battery recharging. Avoid wet conditions when charging battery. • Recharging the battery with improper equipment could cause a battery explo- sion.

  • Page 9: Section 3: Features And Controls

    TRIMMER HEAD CONTROL BAIL Pull the control bail (A, Figure 3-1) up against the handlebar (engage bail) to start rotation of the trimmer head. Let go of the control bail (disengage bail) to stop the trimmer head. CUTTING HEIGHT SETTINGS...

  • Page 10: Section 4: Operation

    (A, Figure 4-1) securing the trimmer head. 3. The cutting heights are marked on the side of the spindle head (Figure 4-2). Move the top of the trimmer head to the desired setting. 4. Tighten both trimmer head bolts securely (to 75 in/lbs.) and evenly.

  • Page 11: Use The Correct Diameter Trimmer Line

    Figure 4-2 USING THE TRIMMER HEAD CONTROL BAIL Before starting the engine, it is essential to know how to use the Trimmer Head Control Bail. 1. The Trimmer Head Control Bail (A, Figure 4-3) is used to start and stop trimmer head motion.

  • Page 12: Additional Operating Tips And Techniques

    5: Maintenance and in the separate Engine Owner’s Manual. DO NOT LET THE TRIMMER LINES BECOME TOO SHORT Once the trimmer lines are worn to less than 1/2 their original length, trimming jobs begin to take far longer than they should.

  • Page 13: Section 5: Maintenance

    (belt squealing may also be noticeable). If the tension is too tight, the trimmer head may rotate before the control bail is engaged, or when there is no free play in the control bail.

  • Page 14: Removing And Replacing The Trimmer Head

    Remove the ignition key on electric start models. 2. Two bolts (A, Figure 5-3) secure the trimmer head (B) to the spindle head (C). Loosen both bolts (not the nuts) just enough to open up the trimmer head and allow it to slide down the spindle head and past the two stops.
  • Page 15 10. Reattach the idler arm spring (R, Figure 5-6) in the hole in the idler arm (T). 11. A new belt may need to be adjusted by following the Adjusting Trimmer Head Engagement instructions in this Section. Section 5: Maintenance Figure 5-5...

  • Page 16: Cleaning And Debris Removal

    Failure to follow these instructions can result in serious personal injury or property damage. TRIMMER/MOWER CLEANING AND DEBRIS REMOVAL Thorough and regular cleaning of debris...

  • Page 17: Throttle Control Adjustment

    Engine Owner’s Manual for service information. OFF-SEASON STORAGE When storing the trimmer/mower for extended periods, follow these procedures to ensure that the unit will be in good con- dition for future use.

  • Page 18: Changing Trimming Lines

    Failure to follow these instructions can result in serious personal injury or property damage. CHANGING TRIMMER LINES The trimmer lines will wear with use and eventually require replacement. Also, you may wish to switch between the thinner and thicker gauge lines to handle dif- ferent mowing conditions.

  • Page 19: Troubleshooting

    Trimmer/Mower vibrates. 1. Trimming head mounting bolt loose. 2. Line lengths are substantially different. 3. Loose nuts or bolts. 4. Broken spindle head or trimmer head. Trimmer head does not Incorrect line installation for mowing conditions. retain line. Trimmer Head does not 1.

  • Page 20: Parts List

    Parts List Models 52068 & 52069 DRAWING NO. 1...
  • Page 21 Models 52068 & 52069 Ref. # Part # Description 1917765 Debris Guard ... 1 1918741 Decal-Logo ... 1 1918415 Push-in Fastener... 5 1917407001 Debris Guard Support... 1 1754128 Hex Flange Screw, 1/4-20 x 3/4 ... 8 9534 Spacer ... 2 Engine...
  • Page 22 V-Belt ... Spindle Head Adapter (Incl. Bearing) ... Spindle Shaft... Spindle Head Assembly (Incl. Bearing, Insert, and Refs. 16, 17, 18)... Trimmer Head Assembly (Incl. Ref. 27) . Wear Cup ... Square Washer... Self-Tap Screw, 5/16-18 x 3/4... Cable Bracket ...

  • Page 23: Accessories & Kits

    Hex Hd. Screw, 5/16-18 x 1-1/2 ... Handlebar Support ... Hex Lock Nut, 5/16-18 ... ACCESSORIES AND KITS Description Trimmer String Kit, .155" diameter line (24 pieces) ... N/I Trimmer String Kit, .130" diameter line (24 pieces) ... N/I Battery Charger (for electric start model) .

  • Page 24: Customer Service Information

    CUSTOMER SERVICE INFORMATION Owner Registration Card Please fill out and mail the enclosed owner registration card. The purpose of this card is to register each unit at the factory so that we can provide you with warranty benefits and informational bulletins. Warranty Service The warranty statement is included in the unit’s literature package.
