1. ControlSpace

AMS-8 LIvE Installer Software

™

1.4.2. Paging level offsets

(upper) to select a 1 of the 40 Presets or 1 of the 80 Paging Buttons/Zones or 1 of the 40 GPIO

Contacts, shown in the info field. The function of this button depends on the selected function of

this software module (see above buttons)

(lower) in Room Combining mode: select a 'master' room, shown in the info field. In GPIO mode:

select the function of the contact input (message activation, preset activation or room standby/ off).

This button is not used to setup the paging buttons/zones

move a selected room from 'available outputs' to 'selected outputs'

move a selected room from 'selected outputs' back to 'available rooms'

NoTe 1: To select all rooms at once, double click in the field 'Available outputs' and press the 'right arrow'

button to move these to the 'Selected outputs' field

NoTe 2: GPIO contacts used to activate a message from the Message Storage Card are already

pre-programmed. Contact nr. 1 is used to start message nr. 1, contact nr. 2 are used to start

message 2, up to contact 40 which is used to start message 40.

Press the ❑ button to open below module to set up to 3 additional paging levels. These levels are linked

to 3 optional 'Push to Talk' buttons (beside the main Push to Talk Button) in the Privileged User Software.

Activation of 1, 2 or 3 of these optional buttons can only be done in the 'Settings panel' of the Privileged

User Software itself.
