Model No. WESY19541
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (Under Seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satis-
faction through direct assis-
tance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge.
CUSTOMER HOT LINE:
1-877-992-5999
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.weiderfitness.com
new products, prizes,
fitness tips, and much more!
Patent Pending

Advertisement

Table of Contents
loading

Related Manuals for Weider WESY19541

Summary of Contents for Weider WESY19541

  • Page 1 Model No. WESY19541 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (Under Seat) QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Keep hands and fingers clear of this area. Decal 1 Decal 2 WEIDER is a registered trademark of ICON IP, Inc. Decal 1 Decal 2 Decal 1—This decal is placed on both sides...

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the weight system. 1. Read all instructions in this manual before using the weight system. Use the weight sys- tem only as described in this manual. 2.

  • Page 4: Before You Begin

    (excluding holidays). To help us assist you, please note the product model number and serial number before calling. The model number is WESY19541. The serial number can be found on a decal attached to the weight system (see the front cover of this manual).

  • Page 5: Assembly

    ASSEMBLY Make Assembly Easier for Yourself Everything in this manual is designed to ensure that the weight system can be assem- bled successfully by anyone. Before begin- ning assembly, make sure to read the information on this page. This brief intro- duction will save you much more time than it takes to read it.

  • Page 6: Frame Assembly

    Frame Assembly Before beginning assembly, make sure you understand the information in the box on page 5. Refer to the PART IDENTIFICATION CHART in the center of this manual for help identifying small parts. Insert four M8 x 63mm Carriage Bolts (87) up through the Base (1).
  • Page 7 3. Attach the Front Leg (7) to the Base (1) with the two M8 x 63mm Carriage Bolts (87) and two M8 Nylon Locknuts (58). Do not tighten the Locknut yet. Attach the Leg Bumper (60) to the Front Leg (7) with an M4 x 20mm Self-tapping Screw (69) and an M4 Washer (33).
  • Page 8 6. Attach the Top Frame (4) to the Upright (3) with two M8 x 65mm Bolts (68), two M8 Washers (59), and two M8 Nylon Locknuts (58). Do not tighten the Locknuts yet. Attach the Top Frame (4) between the Weight Guides (21) with an M10 x 155mm Bolt (74), two M10 Washers (57), two 19mm Spacers (76), and an M10 Nylon Locknut (56).

  • Page 9: Arm Assembly

    8. Attach the Shroud (17) to the Top Frame (4) with two M6 x 16mm Screws (62) and two M6 Washers (82). Do not tighten the Screws yet. Attach the Shroud (17) to the brackets on the Stabilizer (2) with two M6 x 16mm Screws (62) and two M6 Washers (82).

  • Page 10: Cable Assembly

    11. Grease an M10 x 51mm Bolt (66). Attach a Cable Pivot (39) to the Left Arm (10) with the Bolt and an M10 Nylon Locknut (56). Do not overtighten the Locknut; the Cable Pivot must be able to pivot easily. Wet the inside of a Large Foam Pad (42) with soapy water.
  • Page 11 14. Route the Arm Cable (54) over a “V”-pulley (46). Attach the “V”-pulley, a Large Cable Trap (50), two Full Finger Guards (41), and an M10 Washer (57) to the Upright (3) with an M10 x 63mm Bolt (75) and an M10 Nylon Locknut (56). Make sure the Cable Trap is oriented to hold the Cable in the groove of the “V”-pulley.
  • Page 12 18. Locate the Low Cable (53). Route the Cable through the Leg Lever (8) and the Front Leg (7). Attach a 90mm Pulley (48) inside of the Leg Lever (8), over the Low Cable (53), with an M10 x 67mm Bolt (71), two M10 Washers (57), two 12mm Spacers (52), and an M10 Nylon Locknut (56).
  • Page 13 22. Route the Low Cable (53) under a 90mm Pulley (48). Attach the Pulley and two Half Finger Guards (43) to the Base (1) with an M10 x 46mm Bolt (81) and an M10 Nylon Locknut (56). Make sure the Finger Guards are on the outside of the bracket as shown.
  • Page 14 26. Wrap the High Cable (55) under a 90mm Pulley (48). Attach the Pulley, a Cable Trap (51), and two Half Finger Guards (43) at the upper hole in the “U”-bracket (45) with an M10 x 51mm Bolt (66) and an M10 Nylon Locknut. Make sure the Cable Trap is oriented to hold the Cable in the groove of the Pulley and that the Finger Guards are on the outside of the “U”-bracket.

  • Page 15: Seat Assembly

    Seat Assembly 30. Attach the Backrest (16) to the Upright (3) with two M6 x 63mm Screws (70) and two M6 Washers (82). 31. Attach the Seat (15) to the Seat Frame (6) with four M6 x 16mm Screws (62), as shown. 32.
  • Page 16 34. Orient the Curl Pad (14) so that the holes on the back are closer to the lower edge. Attach the Curl Pad to the Curl Post (13) with two M6 x 16mm Screws (62). 35. Make sure that all parts have been properly tightened. The use of the remaining parts will be explained in ADJUSTMENTS, beginning on the following page.

  • Page 17: Adjustments

    ADJUSTMENTS This section explains how to adjust the weight system. See the EXERCISE GUIDELINES on page 22 for impor- tant information about how to get the most benefit from your exercise program. Also, refer to the accompanying exercise guide to see the correct form for each exercise. Make sure all parts are properly tightened each time the weight system is used.
  • Page 18 ARM CONVERSION To use the Arms (9, 10) as butterfly arms, insert the Arm Pins (40) into the holes in the Upright (3) and the Pivot Frame (5) as shown. To use the Arms (9, 10) as press arms, insert the Arm Pins (40) into the holes in the Pivot Frame (5) and Arms.

  • Page 19: Weight Resistance Chart

    WEIGHT RESISTANCE CHART The chart below shows the approximate weight resistance at each exercise station. “Top” refers to the 6 lb. top weight. The other numbers refer to the 12.5 lb. weight plates. Weight resistance shown for the butterfly arm sta- tion is for each arm.

  • Page 20: Cable Diagrams

    CABLE DIAGRAMS The cable diagrams below show the proper routing of the Low Cable (53), the Arm Cable (54), and the High Cable (55). Use the diagrams to make sure that the cables, cable traps, and finger guards have been assem- bled correctly.

  • Page 21: Maintenance

    MAINTENANCE Make sure all parts are properly tightened each time the weight system is used. Replace any worn parts imme- diately. The weight system can be cleaned with a damp cloth and a mild, non-abrasive detergent. Do not use solvents. TIGHTENING THE CABLES Woven cable, the type of cable used on the weight system, can stretch slightly when it is first used.

  • Page 22: Exercise Guidelines

    EXERCISE GUIDELINES THE FOUR BASIC TYPES OF WORKOUTS Muscle Building To increase the size and strength of your muscles, push them close to their maximum capacity. Your mus- cles will continually adapt and grow as you progres- sively increase the intensity of your exercise. You can adjust the intensity level of an individual exercise in two ways: •...
  • Page 23 Rest for a short period of time after each set. The ideal resting periods are: • Rest for three minutes after each set for a muscle building workout. • Rest for one minute after each set for a toning work- out.

  • Page 24: Part Identification Chart

    PART IDENTIFICATION CHART Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw- ing is the key number of the part, from the PART LIST in the center of this manual. Note: Some small parts may have been pre-attached.
  • Page 25 PART LIST—Model No. WESY19541 Key No. Qty. Description Base Stabilizer Upright Top Frame Pivot Frame Seat Frame Front Leg Leg Lever Right Arm Left Arm Handle Square Plate Curl Post Curl Pad Seat Backrest Shroud Top Cap Left Cap Right Cap...
  • Page 26 EXPLODED DRAWING—Model No. WESY19541 56 57 R0904A...
  • Page 27 41 57 41 75...

  • Page 28: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information: 1. The MODEL NUMBER of the product (WESY19541) 2. The NAME of the product (WEIDER 3.
