Model No. WEBE06920
Serial No.
Write the serial number in the
space above for future reference.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through
direct assistance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.weiderfitness.com
new products, prizes,
fitness tips, and much more!
Advertisement
Related Manuals for Weider 140
Summary of Contents for Weider 140
- Page 1 Model No. WEBE06920 Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, we will guarantee complete satisfaction through direct assistance from our factory.
-
Page 2: Table Of Contents
Note: A PART IDENTIFICATION CHART and a PART LIST/EXPLODED DRAWING are attached in the center of this manual. Remove the PART IDENTIFICATION CHART and PART LIST/EXPLODED DRAWING before begin- ning assembly. WEIDER is a registered trademark of ICON Health & Fitness, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the weight bench. 1. Read all instructions in this manual before using the weight bench. Use the weight bench only as described in this manual. 2. -
Page 4: Before You Begin
WEIDER ® 140 weight bench will help you to achieve the specific results you want. For your benefit, read this manual carefully before using the weight bench. If you have questions after... -
Page 5: Assembly
ASSEMBLY Make Things Easier for Yourself This manual is designed to ensure that the weight bench can be assembled successfully by anyone. Most people find that by setting aside plenty of time, assembly will go smoothly. Before beginning assembly, carefully read the following information and instructions: •... - Page 6 3. Attach the Front Leg (8) to the Frame (2) with two M8 x 40mm Bolts (39), four M8 Washers (16), and two M8 Nylon Locknuts (17). Note: Do not tighten the Nylon Locknuts yet. 4. Attach the Frame (2) to the Crossbar (3) with two M8 x 55mm Bolts (18), the Support Plate (40), and two M8 Nylon Locknuts (17).
- Page 7 7. Tap two 19mm Round Inner Caps (9) into each Long Pad Tube (10). Slide the Pad Tubes through the holes in the Leg Lever (4). Slide two Long Foam Pads (23) onto each Pad Tube. 8. Tap two 25mm Square Inner Caps (35) into each of the two Backrest Tubes (5).
- Page 8 11. Tap a 30mm Square Inner Cap (22) into each end of a Fly Arm (25). Push a 25mm Round Inner Cap (24) into the end of the weight tube. Slide a Weight Stop (28) onto the weight tube. Assemble the other Fly Arm (not shown) in the same manner.
-
Page 9: Adjustments
ADJUSTMENTS The weight bench is designed to be used with your own weight set (not included). The steps below explain how the weight bench can be adjusted. Refer to the accompanying exercise guide to see the correct form for several exercises. - Page 10 ATTACHING THE CURL PAD For some exercises, the Curl Pad (37) needs to be attached to the weight bench. To do this, remove the 30mm Square Inner Cap (22) from the Front Leg (8). Insert the Curl Post (38) into the Front Leg and align an adjustment hole in the Curl Post with the adjust- ment hole in the Front Leg.
- Page 11 NOTES...
-
Page 12: Ordering Replacement Parts
• The MODEL NUMBER of the product (WEBE06920) • The NAME of the product (WEIDER • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST in the center of this manual) LIMITED WARRANTY ICON Health &... - Page 13 REMOVE THIS PART IDENTIFICATION CHART PART LIST/EXPLODED DRAWING SAVE THIS PART IDENTIFICATION CHART PART LIST/EXPLODED DRAWING FOR FUTURE REFERENCE...
-
Page 14: Part Identification Chart
PART IDENTIFICATION CHART This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below each part refers to the key number of the part from the PART LIST in the center of this manual. Important: Some parts may have been pre-assembled for shipping purposes. - Page 15 PART LIST—Model No. WEBE06920 Key No. Qty. Description Upright Frame Crossbar Leg Lever Backrest Tube Backrest Support Rod Front Leg 19mm Round Inner Cap Long Pad Tube Seat Short Pad Tube Butterfly Knob Plastic Bushing Fly Arm Stop M8 Washer M8 Nylon Locknut M8 x 55mm Bolt M10 x 115mm Bolt...
- Page 16 EXPLODED DRAWING—Model No. WEBE06920 R0602B...
