Shutdown IPCs in the
SITOP PSU8600
Buffer Mode
TIA Portal V13 SP1, SITOP PSU8600, SIMATIC IPC,
SIMATIC S7-1500 Software Controller
https://support.industry.siemens.com/cs/ww/en/view/109737962
Siemens
Industry
Online
Support

Advertisement

Table of Contents
loading

Related Manuals for Siemens SITOP PSU8600

Summary of Contents for Siemens SITOP PSU8600

  • Page 1 Shutdown IPCs in the SITOP PSU8600 Buffer Mode TIA Portal V13 SP1, SITOP PSU8600, SIMATIC IPC, Siemens SIMATIC S7-1500 Software Controller Industry Online https://support.industry.siemens.com/cs/ww/en/view/109737962 Support...

  • Page 2: Warranty And Liability

    (and to maintain continuously) a holistic, state-of-the-art Industrial Security concept. With this in mind, Siemens’ products and solutions are only part of such a concept. It is the client’s responsibility to prevent unauthorized access to his plants, systems, ma- chines and networks.

  • Page 3: Table Of Contents

    Program details .................. 17 Configuration and Settings................19 Configuring the IPC ................19 Configuring the SITOP PSU8600 with BUF8600 ....... 19 Configuring the hardware in the TIA Portal ........19 Configuring the program for SIMATIC S7-1507 Software Controller .................... 22 Configuring the software for the visualization with WinCC RT Advanced ...................

  • Page 4: Task

    Only a limited buffer time is available via the buffer module due to its capacity. This is why the state of the SITOP PSU8600 needs to be monitored. If there is a power failure, the IPC and the controller have to be terminated in a controlled way in order to prevent damages.

  • Page 5: Scenarios

    Scenarios If there is a voltage drop on the input of the SITOP PSU8600, the buffer module takes on the power supply without interruption. There are different scenarios of power failure.

  • Page 6: Scenario 1 - First-Time Power Failure

    1 Task Scenario 1 – first-time power failure 1.2.1 The input voltage on the SITOP PSU8600 has failed or dropped. The IPC is now supplied by the buffer module. If the critical time (t ) has been reached, meaning wait...

  • Page 7: Scenario 2 - Repeated Power Failure After Completion Of Scenario 1

    1.2.2 After the first power failure the IPC was shutdown correctly and the input voltage is available again on the SITOP PSU8600. The output is provided with voltage again and the panel PC starts the startup t (a brief voltage interruption on output t...

  • Page 8: Solution

    PROFINET communication Configuration For the application example the basic device SITOP PSU8600 40 A/4 x 10 A, and the SITOP BUF8600 10 s/40 A buffer module and an IPC477D 15" Touch PB is used as an example. The IPC is connected to the power supply on the output 1 of the basic device.

  • Page 9: Description Of The Core Functionality

    Figure 2-2 Through the handle on the right side of the screen, you can open the context menu. From there you can get an overview of the state of the SITOP PSU8600 and its additional modules. To do this, log on to SITOP PSU8600 own web server or use the visualization via the faceplate.

  • Page 10: Hardware And Software Components

    SIMATIC S7-1507 Software Controller with FW 1.8 or higher  SITOP modules PSU8600 and BUF8600 firmware V1.1 and higher  IPCs with at least 2 cores and compatibility with SIMATIC S7-1507 Software Controller Shutdown IPCs in the SITOP PSU8600 Buffer Mode Entry ID: 109737962, V1.2, 10/2017...

  • Page 11: Components Used

    V1.8, there is the option to use Software Controller other SIMATIC S7-1500 Software Controller. Library with faceplate Download in entry ID and communication 102379345. blocks for SITOP PSU8600 Shutdown IPCs in the SITOP PSU8600 Buffer Mode Entry ID: 109737962, V1.2, 10/2017...
  • Page 12 Download page of the STIOP PSU8600 library – faceplate and Link to entry ID communication blocks for the TIA Portal 102379345 Shutdown IPCs in the SITOP PSU8600 Buffer Mode Entry ID: 109737962, V1.2, 10/2017...

  • Page 13: Basics

    Basics SITOP PSU8600 power supply To start off with, the SITOP PSU8600 consists of the basic device. It is available with one or four outputs. If the number of outputs of the basic device is not enough, up to four additional expansion modules CNX8600 can be connected.
  • Page 14 (HSP file). You can find it, together with the installa- tion manual, in the entry with entry ID 102254062. In addition, the SITOP PSU8600 offers a web server that can be enabled via the "WEN” DIP switch (for basic devices with product state (PS) 1 and firmware update 1.1.0 "FUNC”).

  • Page 15: Mode Of Operation

    ~400 PROFINET PROFINET PROFINET PROFINET Program overview of software controller Figure 4-2 Main [OB1] Reading and writing of data from SITOP PSU8600 main and buffer module SITOP_PSU8600_DB [DB2] write PSU_global_access_DB [DB1] SITOP_PSU8600 [FB1] write PSU_global_access_DB [DB1] SITOP_BUF8600_S_DB [DB3] SITOP_BUF8600_S [FB9]...

  • Page 16: Program Part 1 - Reading Data From Basic Device Psu8600 And Buffer Module Buf8600

    4.2.2 Program details The data of module SITOP PSU8600 40 A/4 x 10 A is read out with the help of function block FB1 "SITOP_PSU8600”. The data of the buffer module BUF8600 10 s/40 A is read out with the help of function block FB9 "SITOP_PSU8600_S”.

  • Page 17: Program Part 2 - Shutting Down The Ipcs And Software Controllers In The Event Of Buffer Mode

    The 2nd program part contains the shutdown process of the IPC and of the control- ler, when the SITOP PSU8600 is in buffer mode. By monitoring the device status of the SITOP PSU8600 and the charging state of the buffer module, it is decided through comparative operators whether a shutdown is required.
  • Page 18 Portal help which is located in the menu item help in "Show help”. Enter the name of the system function as search term. An application example on saving data via shutdown can be found in entry ID 109479727. Shutdown IPCs in the SITOP PSU8600 Buffer Mode Entry ID: 109737962, V1.2, 10/2017...

  • Page 19: Configuration And Settings

    Note: For models with production state 2 and firmware 1.1.0 the name is "WEN” (web server enable). Connect the 400 V voltage supply to the SITOP PSU8600 and make sure that the voltage supply is not yet switched active. Configuring the hardware in the TIA Portal...
  • Page 20 "Power Supplies > SITOP PSU > PSU8600”, using drag-and-drop. Select the SITOP PSU8600 and go to the device view by double-clicking with the left mouse button. Move the "BUF8600 10 s/40 A” buffer module with V1.1.0 to the slot 1 via the hardware catalog "Power Supplies >...
  • Page 21 Duration for short-time interruption: 1000 ms Mode of Operation If the SITOP PSU8600 is in buffer mode, after 1s (dead time for alarm in buffer mode) a "buffering alarm” is triggered. The SITOP PSU8600 then waits 100s (also when the input voltage returns), until the brief interruption occurs on output 1 for 1 s (duration until brief interruption).

  • Page 22: Configuring The Program For Simatic S7-1507 Software Controller

    Table 5-4 Action Download the "102379345_SITOP_PSU8600_TIA_V13_SP1_FW1.1.0_LIB.zip” library for the faceplate and communication blocks of the SITOP PSU8600. You can find it in the entry with entry ID 102379345.Please note the firmware version of your SITOP PSU8600. Unzip the library into a folder of your choice.
  • Page 23 Copy the function blocks "SITOP_PSU8600” and "BUF8600_S” in "Copy tem- plates > PSU8600 Step7 > S7-1200/1500 > Function Blocks” from the library into the appropriate folder "Software PLC_1 > Program blocks” in the project view.  Shutdown IPCs in the SITOP PSU8600 Buffer Mode Entry ID: 109737962, V1.2, 10/2017...
  • Page 24 Disable the optimized block access via the properties of the created data block (remove tick). Open the OB1 in the project navigation via the "Software PLC1 > Program blocks” folder. Shutdown IPCs in the SITOP PSU8600 Buffer Mode Entry ID: 109737962, V1.2, 10/2017...
  • Page 25 5 Configuration and Settings Action Move FB1 and FB9 into the network area using via drag-and-drop. The appropriate data blocks (DB2 and DB3) are created automatically. Confirm it with "OK". Shutdown IPCs in the SITOP PSU8600 Buffer Mode Entry ID: 109737962, V1.2, 10/2017...
  • Page 26 "UDT_BUF8600_S_Out”. Connect the inputs of the blocks in the OB1 with the appropriate environment variables of the SITOP PSU8600, as well as DB1 and DB4. Create a new network via "Right click > Add network”. Shutdown IPCs in the SITOP PSU8600 Buffer Mode Entry ID: 109737962, V1.2,...
  • Page 27 Add the "SHUT_DOWN” block from the "Basic instructions > Program control operations” tab of the "Instructions” task card into the network. Open the "Default tag table” via "Software PLC1 > PLC tags” in the project navi- gation. Shutdown IPCs in the SITOP PSU8600 Buffer Mode Entry ID: 109737962, V1.2, 10/2017...
  • Page 28 Ret_Val = 80xy: Windows does not respond to the call of the instruction. Assign the "MODE” input with the value 1. Assign the "comment” tag to the "COMMENT” input, the "RET_VAL” output is assigned the "error” tag. Shutdown IPCs in the SITOP PSU8600 Buffer Mode Entry ID: 109737962, V1.2,...

  • Page 29: Configuring The Software For The Visualization With Wincc Rt Advanced

    This chapter shows the required connection of the PLC tags with the help of HMI tags. However, it will not discuss the commissioning of the SITOP PSU8600 faceplate. Information on this topic can be found in the documentation of the...
  • Page 30 Open the "Topic_001.0” screen in the "Screens > 001_Application” folder. Move the "Faceplate_PSU8600_1500” faceplate for the visualization of the SITOP PSU8600 parameters in "Types > PSU8600 WinCC > Screens > Face- plate_Comfort/Advanced”, from the library in chapter to the screen, using drag- and-drop.
  • Page 31 Click the "HTML browser” control and adjust the access address via the proper- ties tab "General > Address”. Replace the "<ip address>” by the IP address of the SITOP PSU8600. Shutdown IPCs in the SITOP PSU8600 Buffer Mode Entry ID: 109737962, V1.2,...

  • Page 32: Installation And Commissioning

    Connect the mains plug with an external voltage supply. Note: The switch can also be connected to one of the outputs of the SITOP PSU8600. However, first of all the hardware configuration has to be loaded. Connect the SITOP PSU8600, the network switch, the IPC447D, as well as the development computer via Profinet.

  • Page 33: Installing The Software (Download)

    Open the "Shutdown_IPC_PSU8600_in_Puffermode” example project. Click "Devices and network” in the project navigation to open the network view. Go to the device view of the SITOP PSU8600 and the IPC by double-clicking the left mouse button. Adjust the IP address of the controller (CPU 1507S), WinCC (WinCC RT Adv) and SITOP PSU8600 (psu_1) via the "Properties >Device interface >...

  • Page 34: Operating The Application

    The visualization and configuration of the data is also possible via the SITOP PSU8600-own web server. To do this, log on to the web server. Enabling and login are described in the appropriate manual. You can find it in chapter...

  • Page 35: Sitop Psu8600 Status Overview

    SITOP PSU8600 status overview Figure 7-2 In the status overview the data of the current SITOP PSU8600 configuration is dis- played via the faceplate from the library. In addition, the chronological sequence of the output currents can be viewed via the "Trends” menu. As an additional function, the internal alarm overview of the SITOP PSU8600 can be called via the "Alarms”...

  • Page 36: Sitop Psu8600 Web Server Login

    Figure 7-3 The login window of the web server of the SITOP PSU8600 is called via the "HTML Browser” control. After successful login, the data of the SITOP PSU8600 can be visualized and controlled in a clear and comprehensible way. Note...

  • Page 37: References

    \10\ Manual SITOP PSU8600 - basic device with one output https://support.industry.siemens.com/cs/ww/en/view/109482936 \11\ Download page for the Support Package of SITOP PSU8600 for TIA Portal https://support.industry.siemens.com/cs/ww/en/view/102254062 \12\ Application example "Using Recipe Functions for persistent Data with SIMATIC S7-1200 and S7-1500”...
