5. MKIV/Pro installation manual

5 - 4. Setting Up PRC100 Pocket Controller

The battery is minimum charged before shipping.
HINT!
It takes approx. 4 hours to be charged fully.
1) Remove the card slot protector, and
then insert the supplied CF wireless
LAN card into the CF card slot.
2) Set the battery replacement switch to
the [REPLACE BATTERY] position.
3) Put the rechargeable battery into the
battery compartment.
NORMAL OPERATION
REPLACE BATTERY
Charging starts and the charge indicator lights amber.
When the battery is fully charged, the indicator goes
out.
Rechargeable battery: EA-BL08
MHB23 MKIV/PRO DIOV1.05, SCV.1.01 PAGE.08
4) Set the battery replacement switch
back to the [NORMAL OPERATION]
position.
5) Remove the I/O port cover, and then
set the Pocket Controller on the cradle.
