D-ILA
PROJECTOR
DLA-VS2200ZG
DLA-VS2200G
For Customer use :
Enter below the serial No. which is
located on the side of the cabinet.
Retain this information for future
reference.
Model No.
DLA-VS2200ZG
DLA-VS2200G
Serial No.
Pour utilisation par le client :
Entrerci-dessous le N°de série qui
est situé sous le boîtier. Garder
cetteinformation comme référence
pour le futur.
N° de modèle
DLA-VS2200ZG
DLA-VS2200G
N° de série
ESPAÑOL/CASTELLANO
INSTRUCTIONS
Instrucción para el cliente :
Introduzca a continuación el nº de
serie que aparece en la parte
inferior lateral de la caja. Conserve
esta información como referencia
para uso ulterior.
Modelo Nº
DLA-VS2200ZG
DLA-VS2200G
Nº de serie
ENGLISH
FRANÇAIS
LCT2727-001B
Advertisement
Chapters
Table of Contents
Related Manuals for JVC DLA-VS2200ZG
Summary of Contents for JVC DLA-VS2200ZG
- Page 1 ENGLISH FRANÇAIS ESPAÑOL/CASTELLANO INSTRUCTIONS D-ILA PROJECTOR DLA-VS2200ZG DLA-VS2200G For Customer use : Pour utilisation par le client : Instrucción para el cliente : Enter below the serial No. which is Entrerci-dessous le N°de série qui Introduzca a continuación el nº de located on the side of the cabinet.
- Page 2 LCT2727-001B...
-
Page 3: Safety Precautions
NOT EXPOSE THIS APPLIANCE TO RAIN OR FCC INFORMATION (U.S.A. only) MOISTURE. CAUTION: WARNING: Changes or modification not approved by JVC could THIS APPARATUS MUST BE EARTHED. void the user’s authority to operate the equipment. NOTE: CAUTION: This equipment has been tested and found to comply... - Page 4 IMPORTANT SAFEGUARDS Power source indicated on the label. If you are not sure of the type of power supply to your home, consult your Electrical energy can perform many useful functions. product dealer or local power company. This unit has been engineered and manufactured to This product is equipped with a three-wire plug.
- Page 5 For replacement, please consult your dealer, or the nearest authorized JVC service center. When fixing the unit to the ceiling, Please note that we do not take any responsibility, even during the warranty period,...
- Page 6 THIS APPARATUS MUST BE EARTHED. Dear Customer, This apparatus is in conformance with the valid European directives and standards regarding electromagnetic compatibility and electrical safety. European representative of JVC KENWOOD Corporation is: JVC Technical Services Europe GmbH Konrad-Adenauer-Allee 1-11 61118 Bad Vilbel...
- Page 7 ENGLISH Information for Users on Disposal of Old Equipment and Batteries [European Union only] These symbols indicate that equipment with these symbols should not be disposed of as general household waste. If you want to dispose of the product or battery, please consider the collection systems or facilities for appropriate recycling.
- Page 8 ITALIANO Informazioni per gli utenti sullo smaltimento delle apparecchiature e batterie obsolete [Solo per l’Unione Europea] Questi simboli indicano che le apparecchiature a cui sono relativi non devono essere smaltite tra i rifiuti domestici generici. Se si desidera smaltire questo prodotto o questa batteria, prendere in considerazione i sistem i o le strutture di raccolta appropriati per il riciclaggio corretto.
- Page 9 SVENSKA Information för användare gällande bortskaffning av gammal utrustning och batterier [Endast den Europeiska unionen] Dessa symboler indikerar att utrustning med dessa symboler inte ska hanteras som vanligt hushållsavfall. Om du vill bortsk affa produkten eller batteriet ska du använda uppsamlingssystem eller inrättningar för lämplig återvinning. Observera: Märkningen Pb under symbolen för batterier indikerar att detta batteri Batteri innehåller bly.
- Page 10 MAGYAR Felhasználói információ az elhasznált be rendezések és akkumulátorok elhelyezéséről [Csak az Európai Unióban] Ez a szimbólum azt jelzi, hogy a berendezés nem helyezhető az általános háztartási hulladék közé. Ha meg szeretne szabadulni a terméktől vagy az akkumulátortól, akkor legyen tekintettel az gyűjtő rendszerre vagy intézményekre a megfelelő...
-
Page 11: Table Of Contents
Contents Getting Started Picture Adjust ............ 28 Input Signal ............32 Safety Precautions ..........2 Installation ............34 Accessories/Optional Accessories ......11 Display Setup ............ 40 Check the Accessories ........11 Function ............. 41 Optional Accessories ......... 11 Information ............42 Controls and Features ........... -
Page 12: Accessories/Optional Accessories
Accessories/Optional Accessories Check the Accessories Power cord (for USA) (about. 2 m) ......... 1 piece Power cord (for EU) (about. 2 m) ..........1 piece Lamp attachment “UPPER 45-90 & REVERSE” (Use Area: B, Refer to p. 17) and Installation verification seal ........1 piece INSTRUCTIONS (this book), warranty card, and other printed material are also included. -
Page 13: Controls And Features
Controls and Features Main Unit - Front A Lens P D Indicator This is a projection lens. Do not look through the lens Refer to “Indicator Display on the Main Unit” (p. 62). while an image is projected. E Exhaust vent For O, the lens is sold separately. -
Page 14: Main Unit - Rear
Main Unit - Rear H Input terminals K Remote Sensor (rear) For details on the terminals. refer to “Main Unit - Input Please aim the remote control (sold separately) at this Terminals”p. 14. area when using it. * There is also a remote sensor at the front. I Lamp cover L Power input terminal When replacing the light source lamp, remove this... -
Page 15: Main Unit - Input Terminals
Main Unit - Input Terminals Enlarged View of Rear Face A [HDMI 1] input terminal D [RS-232C] terminal (D-sub 9-pin male) B [HDMI 2] input terminal The projector can be controlled by connecting a PC to For connecting to devices that support HDMI output. this terminal. -
Page 16: Remote Control (Sold Separately, Model No. Rm-Mh13G)
Remote control (sold separately, model no. RM-MH13G) A B [STAND BY] J [C.M.D.] For setting frame interpolation. Turns off the power. (p. 25) (p. 31) B C [ON] K [LIGHT] Turns on the power. (p. 24) Illuminates the buttons on the C [COMPONENT] remote control. -
Page 17: Loading Batteries Into The Remote Control (Sold Separately)
Loading Batteries into the Remote Control (Sold Separately) If the remote control has to be brought closer to the projector to operate, it means that the batteries are wearing out. Replace the batteries with new ones (AAA). Insert the batteries according to the t s marks. Be sure to insert the s end first. If an error occurs while using the remote control, remove the batteries and wait for five minutes. -
Page 18: Installing The Projector
Installing the Projector Precautions during Installation Please read the following carefully before installing this Using the projector unit. This unit uses a projection lamp, which will heat up when in use. Do not install at the following Please refrain from projecting in the following circumstances. - Page 19 Installing the screen Using the projector at a high altitude Install the unit and the screen such that they are When using this unit at a location that is higher than 900 perpendicular to each other. m above sea level (low air pressure), set the “High Altitude Mode”...
-
Page 20: Precautions During Mounting
Take the necessary actions to prevent the main unit from falling off such as during an earthquake. Regardless of the warranty period, JVC is not liable When this unit is to be mounted to a fixed position for for any product damage caused by mounting the unit use, install it horizontally. -
Page 21: Adjusting The Position
Adjusting the Position Adjusting the elevation angle of the projector Adjusting the position of the image The height and inclination of the unit (0 to 5 mm) can be By using the lens shift feature of this unit, you can shift adjusted by turning the feet. -
Page 22: Connecting The Projector
Connecting the Projector Do not turn on the power until connection is complete. The connection procedures differ according to the device used. For details, please refer to the instruction manual of the device to be connected. This projector is used for projecting images. To output the audio of connected devices, please connect a separate audio output device, such as an amplifier or speaker. -
Page 23: Connecting To The Lan Terminal
Connecting to the LAN Terminal This Unit To [LAN] Terminal Network Connection Cable (Sold Separately) Server Desktop PC, etc. The network is used to control this unit. It is not used for sending or receiving video signals. Please contact your network administrator for information concerning the network connection. For more information on control, please refer to “External Control”... -
Page 24: Connecting The Power Cord (Supplied Accessory)
Connecting the Power Cord (Supplied Accessory) A Connect the power cord supplied to the power input terminal on the main unit B Insert the supplied power plug into the wall outlet. Power Cord (Supplied) Precautions to prevent fire and electric shock The voltage capacity of this unit is large. -
Page 25: Viewing Videos
Viewing Videos MEMO LAMP WARNING STANDBY/ON When you are using this unit, be sure to remove the lens sheet. Connect the power cord, and ensure that the “STANDBY/ON” indicator lights up in red. Turn on the power Projector unit: press the A [STANDBY/ON] button Remote control (sold separately): press the C [ON] button The “STANDBY/ON”... - Page 26 Turn off the power Projector unit: press the A [STANDBY/ON] button Remote control (sold separately): press the B [STAND BY] button While the “Are you sure you want to turn off?” message is displayed, press the button again. The lamp turns off, and the “STANDBY/ON” indicator switches from a green light to a red blinking light. After the light goes off, the fan will run for about 120 seconds to cool down the lamp (Cool-down mode).
-
Page 27: Adjustments And Settings In The Menu
Adjustments and Settings in the Menu Pressing the [MENU] button displays the menu. Press the [JKH I] keys to select an item, followed by pressing the [OK] button to confirm the selection. List of Menu Items Picture Adjust Picture Mode ..............................p. 28 Contrast ................................ - Page 28 Display Setup Back Color ................................ p. 40 Menu Position ..............................p. 40 Menu Display ..............................p. 40 Line Display ..............................p. 40 Source Display ..............................p. 40 Logo .................................. p. 40 Function Off Timer ................................p. 41 High Altitude Mode ............................p. 41 Communication Terminal ..........................
-
Page 29: Picture Adjust
Picture Adjust Picture Mode You can adjust the image quality according to the type of video image you are viewing. Item Description Natural Image quality that focuses on natural color and gradation reproduction. Suitable for drama footage, etc. Dynamic This is the picture setting best suited for viewing the picture in a room that cannot be made completely dark. -
Page 30: Color Temp
Color Temp. For setting the color temperature of the video image. Preset Setting Description 5500K, 6500K, 9500K Increasing the value enhances the blue tone of the video image, while decreasing the value enhances the red tone. * Select only when “PictureMode” is set to “Natural”/“User1,2,3”. High Bright Color temperature that gives priority to brightness. -
Page 31: Advanced
Advanced For fine-tuning the image quality. Sharpness Setting Description Sharpness Emphasizes the outline of the video image. Setting range: 0 (blurry) to +50 (sharp) Detail Enhance Brings out details in the image, such as the hair or pattern of the clothes. Setting range: 0 (weak) to +50 (strong) Color Management Each of the colors is adjustable according to the user’s preference. -
Page 32: Clear Motion Drive
Clear Motion Drive For reducing the after-image, which occurs in a fast-moving scene. For some scenes, interpolation may cause distortion in the image. In this case, set to “Off”. Pressing the [C.M.D.] button each time switches the mode in the following sequence: “Off”"“Mode1”"“Mode2” "“Off”... -
Page 33: Input Signal
Input Signal HDMI Setting is enabled when the HDMI input terminal is selected. Input For setting the dynamic range (gradation) of the video input. If the dynamic range is not appropriate, the bright areas become overexposed, and the dark areas become underexposed. -
Page 34: Mask
Mask For hiding the peripheral area of the image with a mask (black strip). Setting Description Not masked. 2.5% Masks about 2.5% of the peripheral area of the image. Masks about 5.0% of the peripheral area of the image. Custom Masks about 0% to 5% of the four sides of the image. -
Page 35: Installation
Installation Lens Control P Focus / Zoom / Shift For adjusting the lens according to the projection position A Press the [LENS CONTROL] button, and use the [JKH I] keys to adjust Focus, Zoom (screen size), and Shift (screen position) Lens Control Focus Operate... -
Page 36: Image Pattern
Image Pattern Setting Description Displays the lens adjustment pattern. Displays external signals, and does not display the lens adjustment pattern. Lock Setting Description Locks the lens to prevent any erroneous operation on the adjustments. Operation of the lens control feature is disabled when “On” is selected. Does not lock the lens. -
Page 37: Installation Style
Adjust(Fine) When “Adjust Area” is set to “Whole”, adjustment can be made by moving in units of 1/16 pixel on the screen of the color selected in “Adjust Color”. Æ “Operation procedure for Whole Adjust (Fine)” （p. 38） When “Adjust Area” is set to “Zone”, the screen is divided into 11 vertical x 11 horizontal zones, and fine adjustment of each zone is possible. - Page 38 Operation procedure for Whole Adjust (Pixel) For making general adjustments to slight color fringing in the horizontal/vertical directions of the video image. A Set “Adjust Area” to “Whole” B Select “Adjust Color” and “Adjust Pattern Color” C Select “Adjust(Pixel)”, and press the [OK] button The selected adjustment pattern and Adjustment (Pixel) window are displayed.
- Page 39 Operation procedure for Whole Adjust (Fine) For making general adjustments on the misalignment of the entire screen using “Adjust(Pixel)”, followed by making fine adjustments. A Set “Adjust Area” to “Whole” B Select “Adjust Color” and “Adjust Pattern Color” C Select Adjust(Fine), and press the [OK] button The selected adjustment pattern and Fine window are displayed.
- Page 40 Operation procedure for Zone Adjust For fine-tuning misalignments on a part of the screen after adjusting the overall screen misalignment using “Adjust(Pixel)” and “Adjust(Fine)”. The screen can be divided vertically and horizontally into 10 sections for partial adjustments to be made. A Set “Adjust Area”...
-
Page 41: Display Setup
Display Setup Back Color For setting the color of the background to “Blue” or “Black” when there is no input signal. Menu Position For setting the display position of the menu. Menu Display Setting Description 15sec The menu display disappears if it is not operated for 15 seconds. Displays the menu at all times. -
Page 42: Function
Function Off Timer For setting the timing to power off the unit automatically (“1 Hour”, “2 Hours”, “3 Hours”, or “4 Hours”) when it is not operated for a period of time. High Altitude Mode Set to “On” when using the projector at a location of low atmospheric pressure (higher than 900 m above sea level). Communication Terminal For setting the external control terminal to be used to “RS-232C”... -
Page 43: Information
Glossary of Network Terminology DHCP : Abbreviation for Dynamic Host Configuration Protocol. This is a protocol for the network to assign an IP address automatically to the connected device. IP Address : Numeric characters for identifying the device that is connected to the network. Subnet Mask : Numeric characters that define the bit count used for the network address that is a segment of the IP address. -
Page 44: Replacing The Lamp
Replacing the Lamp The lamp is a consumable item. If the image appears dark or the lamp goes out, replace the lamp unit. When the lamp replacement time approaches, the user is notified with a message displayed on the screen and by the indicator. - Page 45 Install the new lamp unit MEMO Usable lamp life When the lamp is used with “Lamp Power” set to “Low” , the lamp life on this unit is approximately 4000 hours. This is the average usable time and not a guaranteed value.
-
Page 46: Replacing The Attachment
Replacing the Attachment Attachment and the placement area As default, an attachment for Area A (with “X” hole and stamp of “0°”) is Area B 90 ° attached on the lamp. Use the lamp as it is if you use with the angle in Area A. - Page 47 Lamp attachment removal procedure Bend the clasp coupling of the lamp attachment vertically (see Figure 2) If you remove it without bending it vertically, it will be difficult to install the next time. Bending Figure 2 Figure 1 Remove the clasp coupling of the lamp unit and the lamp attachment in the direction of the arrow Figure 3 Make sure that the clasp is removed from the lamp attachment...
- Page 48 Remove the clasp coupling of lamp attachment on the reverse side and the lamp unit Figure 5 Lamp attachment replacement procedures Insert the “a” section of the lamp attachment into the “A” section of the lamp unit. Hang the lamp attachment into the clasp-shaped part of the lamp unit Lamp unit Lamp attachment “b”...
- Page 49 Fit the “b” section of the lamp attachment (see Figure 1-2) into the clasp-shaped part of the lamp unit by pressing the former into the latter Figure 4 As shown in Figure 5, make sure that the lamp attachment is coupled with the clasp of the lamp unit “c”...
- Page 50 As shown in Figure 7, make sure that the lamp attachment is coupled with the clasp of the lamp unit Figure 7 When replacing the lamp, please do not forget to remove the lamp attachment. Attachment of the installation verification seal After replacing the lamp, attach the “installation verification seal”...
-
Page 51: Resetting The Lamp Time
Resetting the Lamp Time Resetting the lamp time from the menu Resetting the lamp time using the remote screen control Press the [MENU] button to display Insert the power plug into the power the menu outlet Select “Function”"“Lamp Reset” Make sure that you operate the remote control in the Standby mode from the menu (the power plug is inserted into the... -
Page 52: Cleaning And Replacing The Filter
Cleaning and Replacing the Filter Clean the filter regularly Otherwise, the air intake efficiency may deteriorate, and malfunction may occur. Reinstall the inner filter CAUTION Make sure that you pull out the power plug from the Check that the left outlet before cleaning or replacing the filter. -
Page 53: Troubleshooting
Troubleshooting Before sending the unit to your authorized dealer for repair, please check the following points. The following symptoms are not malfunctions. You do not need to worry about the following symptoms if there is no abnormality on the screen. A part of the top or front surface of the unit is hot. - Page 54 Remote control does not work Check Action Refer to Are the batteries correctly loaded? Match the polarities (t s) correctly when loading the p. 16 batteries. Are the batteries exhausted? Replace with new batteries. p. 16 Is there an obstructing object between Remove any obstructing object.
-
Page 55: When The Following Messages Appear
Power is cut off suddenly Check Action Refer to Has “Off Timer” been configured? Set “Off Timer” to “Off”. p. 41 The internal cooling fan emits a loud noise Check Action Refer to Is the exhaust vent blocked? Check the condition of installation. p. -
Page 56: External Control
External Control It is possible to control this unit by connecting it to a PC using an RS-232C cross cable (D-sub 9-pin). The projector can be controlled by connecting it to a PC through the computer network with a LAN cable for control commands to be sent to the projector. -
Page 57: Command Format
Command Format The command between this unit and the computer consists of “Header”, “Unit ID”, “Command”, “Data” and “End”. Header (1 byte), Unit ID (2 bytes), Command (2 bytes), Data (n bytes), End (1 byte) Header This binary code indicates the start of communication. Binary Code Type Description... -
Page 58: Remote Control Code
Remote Control Code Binary code is sent during communication. The following applies to the case when the remote control code is “A”. In the case of “B”, add “36” to the beginning of the code. Remote Control Button Name Binary Code Remote Control Button Name Binary Code STAND BY... -
Page 59: Communications Example
Communications Example This section shows the communication examples of RS-232C. Operating command Type Command Description Connection check PC " This unit: 21 89 01 00 00 0A Connection check This unit " PC: 06 89 01 00 00 0A Power (On) PC "... -
Page 60: Specifications
Specifications Product Name D-ILA Projector Model Name DLA-VS2200ZG, DLA-VS2200G Display Panel/Size D-ILA device *1, 2 0.7" (1980 x 1080 pixels) x 3 (total no. of pixels: approx. 6.22 million) Projection Lens 2.0 x power zoom lens (1.4:1 to 2.8:1), motorized zoom and focus Light-source Lamp 230 W ultra-high pressure mercury lamp [model no.: PK-L2313U]... - Page 61 Design and specifications are subject to change without prior notice. This projector is designed for use in Japan only, and cannot be used in any other country due to the different power voltage. This projector is designed for use in Japan only and can not be used in any other country. Please note that some of the pictures and illustrations may have been abridged, enlarged or contextualized in order to aid comprehension.
- Page 62 When a 4:3 screen is used P Screen Size Projection Distance Diagonal (Model) Width (mm) Height (mm) Wide-end (m) Tele-end (m) 1219 2.22 4.49 1422 1067 2.60 5.24 1626 1219 2.98 6.00 1829 1372 3.36 6.75 2032 1524 3.74 7.51 2235 1676 4.11...
- Page 63 Types of Possible Input Signals Video Digital Video Signal 480p/60 Hz, 576p/50 Hz, 720p/50 Hz, 720p/60 Hz, 1080p/50 Hz, 1080p/60 Hz PC signal (HDMI) No. of Total No. Total No. No. of dot CLK Effective Designation Resolution fh [kHz] fv [Hz] of Dots of Lines Effective...
- Page 64 Warning display You can tell the details of a warning from the (repeated) displays of the “WARNING” and “LAMP” indicators. The “STANDBY/ON” indicator, which shows the operating mode of the unit, is displayed simultaneously as described above. The Warning mode is activated once the message is displayed. Projection is interrupted, and the cooling fan is turned on for about 120 seconds.
- Page 65 Dimensions (Unit: mm) Top Surface Bottom Surface Lens Lens Rear Surface Front 227.5 Lamp Cover Ø60 Lens Center The dimensions are identical for all the models.
-
Page 66: Index
Index Input terminals ............. 14 A Accessories ............11 Installation Method ..........17 Advanced Setting for Image Quality ..... 30 Projection Screen Adjustment ......34 L Lamp ..............11 Adjustment and Setting by the Menu ....26 Lamp Power ............31 Adjustment of the Image Quality ...... - Page 67 © 2013 JVCKENWOOD Corporation 0413SIB-SW-X...
