Summary of Contents for Bowers & Wilkins PX7

  • Page 1 PX7 Manual...

  • Page 2: Carton Contents

    1. Carton Contents Please ensure the following items are included in carton: Headphones USB-C Charging Cable 3.5mm Audio Cable Literature Pack...
  • Page 3 2. Getting to Know Your Headphones...

  • Page 4: Headphone Controls

    2.1 Switch Headphones On/Off Switching On Slide the Power Switch up to the middle position. An audible cue will be presented & the headphone indicator will light in a color (green, amber, red) displaying the current charge level. Switching Off Slide the Power Switch to the bottom position.
  • Page 5 Toggle Mute While on a call, press the Multi-function button three times 2.3 Noise Cancellation & Ambient Listening PX7 headphones features our next generation adaptive noise cancellation technology. The Noise Cancellation button on the left ear piece control this feature.
  • Page 6 2 seconds 2.5 Wear Sensors PX7 also incorporates proximity sensors in both left and right ear pieces, allowing the headphones to sense if it is worn on the head. This will enable the headphones to intelligently conserve battery by disconnecting Bluetooth and enter stand by ten minutes after taking off, and wake when placed back on your head.

  • Page 7: Battery Charging

    3. Battery Charging Your Bowers & Wilkins headphones ships with the battery partially charged & may be used immediately. For best practice we recommend to fully charge the headphones before first use. Please allow up to 3 hours for full charge. The headphones can be used while charging. To charge: 1.

  • Page 8: Status Indicator

    3.1 Status Indicator The status indicator is located on the right ear piece next to the USB-C socket. Illumination Indication White (after power on) Battery charge > 50% Amber (after power on) Battery charge > 30% Red (after power on) Battery charge <...

  • Page 9: Wearing Your Headphones

    4. Wearing Your Headphones Wearing your headphones correctly will help ensure the best possible experience. 1. Identify the left and right ear pieces by finding the identification legends located on either side of headband. 2. Place the headphones on your head with the headband adjusted so that the headband & earpieces sit comfortably.

  • Page 10: Bluetooth Connectivity

    5. Bluetooth Connectivity 5.1 Pairing Your Bowers & Wilkins PX 7 headphones are designed to stream music wirelessly from Bluetooth audio devices, such as smartphones, tablets, or computers. To do so, the headphones & device must first be paired. 1. The first time you switch on your headphones, Bluetooth pairing mode will be enabled, the indicator will blink blue.

  • Page 11: Switching Between Two Connected Devices

    Note: Your headphones will automatically exit Bluetooth pairing mode if no device is paired within 5 minutes. If pairing fails, the indicator will rapid flash blue, please try pairing again 5.2 Switching Between Two Connected Devices...
  • Page 12 Your headphones can connect up to two devices at the same time. However, you can only play audio or take calls from one device at a time. To switch between two devices: 1. Pause audio on the first device, or use the headphone’s play/pause button. 2.

  • Page 13: Wired Connectivity

    6. Wired Connectivity In addition to Bluetooth, your Bowers & Wilkins headphones can also connect to audio sources using the supplied 3.5mm audio or USB cables. 6.1 Connecting with the 3.5mm audio cable The 3.5mm audio cable enables your headphones to be used with a device supporting analog sound output such as a smartphone or tablet 3.5mm headphone socket, a traditional hi-fi system, or on board an aircraft.
  • Page 14 7. Headphone Reset Your headphones can be reset to factory settings. When powered on, simultaneously hold down the Volume + and Noise Cancellation Button for 10 seconds until the indicator light turns off, let go when the indicator lights up again.
  • Page 15 8. Caring For Your Headphones Your headphones can be cleaned by a damp cloth and gently dabbing until clean. Do not rub the cloth on the fabric or leather. Do not use cleaning detergents or leather polish, doing so may damage your headphones.

  • Page 16: Specifications

    9. Specifications Technical Features Adaptive Noise Cancellation Intelligent Auto Noise Cancellation Voice Pass-Through Smart Wear Sensor Bluetooth 5.0 with AptX-Adaptive technology USB-C charging & audio interface 3.5mm auxliary audio interface Bluetooth Codec AptX-Adaptive AptX-Classic AptX-HD Bluetooth Profiles A2DP v1.3.1 AVRCP v1.6.1 HFP v1.7.1 HSP v1.2 BLE GATT (Generic Attribute Profile)
