- Page 1 CMN86 6.8” 2 DIN CAPACITIVE TOUCH SCREEN MULTIMEDIA MECHLESS RECEIVER AM-FM-RDS with Navigation USB Multimedia Player Front / Rear Camera Inputs INSTALLATION & OWNER’S MANUAL...
-
Page 2: Fcc Compliance
CMN86 INFORMATION FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 3: Safety Notice
The SAFETY NOTICE is reminder to drive responsibly and safely while using your mobile phone device, or any APP’s that are compatible with this unit. it is highly recommended that your JENSEN CMN86 is installed by a professional installer or an authorized dealer. -
Page 4: Installation
CMN86 INSTALLATION Preparation Please read and understand entire manual before installation. Consult a qualified technician for detailed instructions or installation assistance. Before You Start • Disconnect negative battery terminal. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. - Page 5 (1) 15 amp ATO blade-type fuse located on the back of the unit. Wiring Notes: Front / Rear camera inputs Up to two cameras (not included) can be used. We recommend optional Jensen Backup Camera part BUCAM200J for Front Camera and part BUCAM300AJ or BUCAM400AJ for the Rear Camera. 5V 1A...
- Page 6 CMN86 OPERATION Getting Started - First Time Setup Wizard The first time the unit is powered on, the Setup Wizard will guide you through the main system settings and connect to your Bluetooth device. STEP 1 STEP 2 Select Language...
- Page 7 CMN86 OPERATION Main Control Locations Power On/Off Press any button to turn the unit on. Press POWER and hold to turn the unit off. Volume Up Press VOLUME + to increase the volume level. Mute Press MUTE to silence the audio. Momentarily press again to return to the previously selected volume.
- Page 8 CMN86 OPERATION Source Menu Operation Home Source Menu 12 11 10 Quick Select Sources Press to quickly access your Top 3 Sources. Radio Press to access Radio. Media Player Press to access Media Player. Bluetooth Press to access Bluetooth. Full Screen Clock Press the clock to put the unit in Standby mode.
-
Page 9: Audio Settings
CMN86 OPERATION Audio Settings Audio Press AUDIO to display and adjust the following audio settings. Equalizer Adjust the EQ screen to select EQ settings for the current source. The unit had source tone memory, meaning that it will remember the selected EQ settings for each source. -
Page 10: Settings Menu
CMN86 OPERATION Settings Menu From the Main Menu, press the gear icon to access the Setup menu and adjust the following: General, Audio, Navigation, Radio and Bluetooth. General: • Language - Select English or Spanish. • Standby Time - Select the desired time for the unit to wait before entering standby mode, or select OFF to turn off standby mode. -
Page 11: Am/Fm Tuner Operation
CMN86 OPERATION AM/FM Tuner Operation Stereo Local Station Mono Distance Info Indicator Indicator Top 3 Sources Band Selector Press to select between two AM and three FM bands. Preset Stations Press any preset station stored in the current band to tune radio to saved frequency. -
Page 12: Media Player Operation
CMN86 OPERATION Media Player Operation Top 3 Sources Press desired option to select between audio sources Source Selector for the media player: Bluetooth Music, Music (USB), Video (USB) or Auxiliary Input. Press to display all files/folders on the device by File/Folder List Song Title, Artist, Album or Playlist. -
Page 13: Media Compatibility
CMN86 OPERATION Media Compatibility File Type FAT 12 File System FAT 16/FAT 32 .mp3/.MP3/.Mp3/.mP3 File Extension .rmp/.m4a MPEG 1 MPEG MPEG 2 Format MPEG 2.5 MPEG 1 32/44.1/48kHz Sampling MPEG 2 12/16/22.05/24kHz Frequency MPEG 2.5 8/11.025/12kHz... -
Page 14: Bluetooth - Handsfree Operation
Tips CMN86 OPERATION Bluetooth - Handsfree Operation Top 3 Sources 5V 1A USB CHARGE Nyne ADS15 Before you can use a Bluetooth device, it must be Preparation paired and connected. Make sure that Bluetooth is activated on your device before you begin the pairing process. - Page 15 CMN86 OPERATION Bluetooth - Handsfree Operation Voice Control Press to activate the voice control feature. Keypad Use the keypad to dial a number. Talk Press to connect a call to the number entered. Backspace Press to backspace when using the keypad.
-
Page 16: Steering Wheel Controls
CMN86 OPERATION Steering Wheel Controls A third-party adapter must be used in order for the CMN8620 to be compatible with any OEM steering wheel controls. The CMN8620 has a built-in 3.5mm SWC interface that compatible with many popular 3rd party SWC control modules, such as PAC, METRA, and others. - Page 17 CMN86 OPERATION Cameras & Auxiliary Input Rear Camera Connect an optional rear camera to the Rear Camera inputs (Yellow RCA connector for video and Black RCA connector for audio). Refer to the wiring diagram for details. Manual selection - Touch the REAR CAMERA icon from the Main Menu or from any operational mode (when enabled) to select camera mode.
-
Page 18: Troubleshooting
Please keep your original sales receipt and be prepared to provide this receipt in the event you require service, as your original receipt is considered the best proof of purchase and indicates the date you purchased your JENSEN product. Dealer Info Dealer Name:... -
Page 19: Limited One Year Warranty
CMN86 OPERATION Limited One Year Warranty This warranty gives you specific legal rights. You may also have other rights which vary from state to state. Namsung America Inc. warrants this product to the original purchaser to be free from defects in material and workmanship for a period of one year from the date of the original purchase. -
Page 20: Specifications
CMN86 OPERATION Specifications FM Tuner US Tuning Range: 87.5MHz-107.9MHz EU Tuning Range: 87.50MHz-108.00MHz Usable Sensitivity: 8.5dBf 50dB Quieting Sensitivity: 10dBf Stereo Separation@ 1kHz: 30dB Frequency Response: 30Hz-13kHz AM Tuner Tuning Range: 530kHz-1710kHz Usable Sensitivity: <42dBu Frequency Response: 30Hz-2.2kHz Bluetooth Version: 4.1 + EDR... - Page 21 OPERATION CMN86 Notes...
- Page 22 CMN86 INSTALLATION & OWNER’S MANUAL Customer Support 1-888-921-4088 (Monday-Friday, 9AM-5PM EST) Visit https://www.jensenmobile.com Designed and Engineered in USA All rights reserved. No part of this publication may be reproduced, distributed, or transmitted in any form or by any means, including photocopying, recording, or other electronic or mechanical methods, without the prior written permission of NAMSUNG AMERICA INC.
