Symantec S500 Network
Interface Card Options
and Installation
Guide Revision: 4/28/2017

Advertisement

Table of Contents
loading

Summary of Contents for Symantec S500

  • Page 1 Symantec S500 Network Interface Card Options and Installation Guide Revision: 4/28/2017...
  • Page 3 Copyright © 2017 Symantec Corp. All rights reserved. Symantec, the Symantec Logo, the Checkmark Logo, Blue Coat, and the Blue Coat logo are trademarks or registered trademarks of Symantec Corp. or its affiliates in the U.S. and other countries. Other names may be trademarks of their respective owners. This document is provided for informational pur- poses only and is not intended as advertising.
  • Page 4: Table Of Contents

    Install an option card into Slot 5 or 6 Install an option card into Slot 7 Open the S500 Series Center Cover Remove the S500 Series Rear Cover Remove the S500 Series PCIe Expansion Module Install the S500 Series PCIe Expansion Module...
  • Page 5: Safety Warnings And Cautions

    Safety Warnings and Cautions Caution: This product is designed to work with power systems having a grounded neutral. To reduce the risk of electric shock, do not plug this product into any other type of power system. Contact a qualified elec- trician if you are not sure what type of power is supplied to your building.
  • Page 6: Caution

    Do not access the inside of the power supply. There are no serviceable parts in the power supply. Return to manufacturer for servicing. Power down the server and disconnect all power cords before adding or replacing any non hot-plug component. When replacing a hot-plug power supply, unplug the power cord to the power supply being replaced before removing the power supply from the server.
  • Page 7: Network Interface Card Options

    Network Interface Card Options The following lists the option cards that are available for the S500-based appliances. The low-profile option cards can be installed into any of the PCIe slots, including the on-board PCIe slots and the PCIe expansion module slots. Full-height cards, with a system maximum of 2, can only be installed in the PCIe expansion module, slots 3 and 4.
  • Page 8 Supported Appli- Description Expansion Slot Installation Card ances Usage ProxySG 2-port 10GBASE-T Non- I'd like to install the option card NIC-S500- All expansion slots bypass 2x10G Malware Analysis (click for details) Slot 1 or 2 Slot 7 Slot 3 or 4...
  • Page 9 The 10 Gigabit Ethernet bypass NIC cards [NIC-S500-2x10G_PT / NIC-S400-2x10G_PT] are PCIe x8 network adapters containing two copper 10 Gigabit interfaces. Key Features Technical Specifications WDT Interval (Software Programmable): Interface Standard: PCI-Express Base Specification Revision 2.1 (5GT/s) 3,276,800 mSec (3,276.8 Sec): Board Size: 167.65mm X 68.91mm (6.60”X 2.713”)
  • Page 10 The quad port Gigabit Ethernet bypass NIC cards [NIC-S500-4xGigE-PT-Fiber / NIC-S400-4xGigE-PT-Fiber] are PCIe x4 network adapters containing four fiber Gigabit interfaces, based on a single chip, non-bridged GBE controller. Key Features Technical Specifications Fiber Gigabit Ethernet 1000Base-SX:: Interface Standard: PCI-Express Base Specification Revision 2.1 (5GT/s)
  • Page 11 The quad port Gigabit Ethernet bypass NIC cards [NIC-S500-4xGigE-PT / NIC-S400-4xGigE-PT] are PCIe x4 network adapters containing four copper Gigabit interfaces, based on a single chip, non-bridged GBE controller. Key Features Technical Specifications Copper Gigabit Ethernet 1000Base-T: Interface Standard: PCI-Express Base Specification Revision 2.1...
  • Page 12 Key Features Technical Specifications Full duplex / Simplex : Support both Simplex & Full duplex operation in all operating speeds Auto negotiation: Auto-negotiation between Full duplex and simplex operations and between 10Mb/s 100Mb/s speeds and duplex 1000Mb/s. Data Transfer Rate: 1000 Mb/s, 100 Mb/s and 10 Mb/sec in simplex mode per port.
  • Page 13 The 10 Gigabit Ethernet PCIe non-bypass NIC cards [NIC-S500-2x10G / NIC-S400-2x10G] contain two copper 10 Gigabit interfaces. Key Features Technical Specifications IEEE Standard / Network topology: Interface Standard: PCI-Express Base Specification Revision 2.1 (5GT/s) Copper 10Gigabit Ethernet, Board Size: 251.4mm X 68.91mm (6.0”X 2.713”) 10GBASE-T, IEEE 802.3an...
  • Page 14 The dual port fiber 10 Gigabit Ethernet bypass NIC cards [NIC-S500-2x10G_PT_SR_fbr / NIC-S400-2x10G_ PT_SR_fbr] are PCIe x8 network adapters containing two fiber (SR) 10 Gigabit interfaces. Key Features Technical Specifications 10 Gigabit Fiber Ethernet port supports Interface Standard: PCI-Express Base Specification Revision 2.0...
  • Page 15 Key Features Technical Specifications Optical Output Power : LEDs : (2) LED per port Normal Mode (Bypass Off): Link: Turns on Blue on 10G link. Typical: -3.1dBm (TX –Switch ACT: Blinks on activity (green). Normal – Fiber – LC/LC) Bi-color LED per Bypass pair: Minimum: -7.3 dBm BYPASS: Turns on Green on Bypass Disconnect : Turns on Yellow on Disconnect...
  • Page 16 The dual port fiber 10 Gigabit Ethernet bypass NIC cards [NIC-S500-2x10G_PT_LR_fbr / NIC-S400-2x10G_ PT_LR_fbr] are PCIe x8 network adapters containing two fiber (LR) 10 Gigabit interfaces. Key Features Technical Specifications 10 Gigabit Fiber Ethernet port supports Interface Standard: PCI-Express Base Specification Revision 2.0...
  • Page 17 The quad port Gigabit Ethernet bypass NIC cards [NIC-S400-4xGigE-LX-Fiber / NIC-S200-4xGigE-LX-Fiber] are PCIe x4 network adapters containing four fiber Gigabit interfaces, based on a single chip, non-bridged GBE controller. Key Features Technical Specifications Fiber Gigabit Ethernet 1000Base-SX:: Interface Standard: PCI-Express Base Specification Revision 2.1 (5GT/s) Independently Fiber Gigabit Ethernet channel/s Board Size: 167.65mm X 111.15mm (6.60”X 4.376”)
  • Page 18: Install An Option Card Into Slot 1 Or 2

    Install an option card into Slot 1 or 2 The S500 Series expansion slots 1 and 2 supports low-profile cards which can be accessed without the removal of the PCIe expansion module. ALWAYS observe proper electrostatic discharge (ESD) conventions. Attach an ESD protective wrist strap to your wrist and to the chassis.
  • Page 19 7. Lock the securing latch. Verify that it is fully closed and that the option card is secured. 8. Reinstall the appliance’s center and rear panels. 9. Reconnect the network cabling as necessary for your deployment. 10. Reconnect the power cords. 11.
  • Page 20: Install An Option Card Into Slot 3 Or 4

    Install an option card into Slot 3 or 4 The S500 Series is equipped with a PCIe expansion module that houses four PCIe cards - two full-height and two low-pro- file cards. Slots 3 and 4 are the only available slots which can accept a full-length card.
  • Page 21 7. Insert the option card by holding the edges of the card and gently inserting into the slot. It might be necessary to lightly rock the option card into position. Verify that the PCIe card notch mates with the raised tab on the chassis and secure into place.
  • Page 22 8. Lock the securing latches. Verify that it is fully closed and that the option card is secured.
  • Page 23 Reinstall the PCIe expansion module into the chassis. 10. Reinstall the appliance’s center and rear panels. 11. Reconnect the network cabling as necessary for your deployment. 12. Reconnect the power cords. 13. Verify that you have correctly installed the option card.
  • Page 24: Install An Option Card Into Slot 5 Or 6

    Install an option card into Slot 5 or 6 The S500 Series is equipped with a PCIe expansion module that houses four PCIe cards - two full-height and two low-pro- file cards. Slots can only accept low-profile cards. ALWAYS observe proper electrostatic discharge (ESD) conventions. Attach an ESD protective wrist strap to your wrist and to the chassis.
  • Page 25 7. Insert the option card by holding the edges of the card and gently inserting into the slot. It might be necessary to lightly rock the option card into position. Verify that the PCIe card notch mates with the raised tab on the chassis and secure into place.
  • Page 26 Reinstall the PCIe expansion module into the chassis. 10. Reinstall the appliance’s center and rear panels. 11. Reconnect the network cabling as necessary for your deployment. 12. Reconnect the power cords. 13. Verify that you have correctly installed the option card.
  • Page 27: Install An Option Card Into Slot 7

    Install an option card into Slot 7 The S500 Series is equipped with a PCIe expansion module that houses four PCIe cards - two full-height and two low-pro- file cards. The S500 Series also come with three low-profile expansion slots directly on the motherboard. These slots can be accessed without the removal of the PCIe expansion module.
  • Page 28 8. Reinstall the appliance’s center and rear panels. 9. Reconnect the network cabling as necessary for your deployment. 10. Reconnect the power cords. 11. Verify that you have correctly installed the option card.
  • Page 29: Open The S500 Series Center Cover

    Open the S500 Series Center Cover The S500 Series center cover protects and houses the system fan units and provides further access to the appliance com- ponents. ALWAYS observe proper electrostatic discharge (ESD) conventions. Attach an ESD protective wrist strap to your wrist and to the chassis. Ensure that the appliance is on an ESD-safe work sur- face or ground the unit appropriately.
  • Page 30: Remove The S500 Series Rear Cover

    Remove the S500 Series Rear Cover The S500 Series rear cover protects and provides access to the primary system components, such as the DIMMs, CPUs, option cards, etc. You must remove this panel to access the option cards as well as the SSD image storage devices. You...
  • Page 31: Remove The S500 Series Pcie Expansion Module

    Remove the S500 Series PCIe Expansion Module The S500 Series is equipped with a PCIe expansion module that houses four PCIe cards - two full-height and two low-pro- file cards. The S500 Series also comes with three low-profile expansion slots directly on the motherboard. These slots can be accessed without the removal of the PCIe expansion module.
  • Page 32: Install The S500 Series Pcie Expansion Module

    Install the S500 Series PCIe Expansion Module The S500 Series is equipped with a PCIe expansion module that houses four PCIe cards - two full-height and two low-pro- file cards. The S500 Series also come with three low-profile expansion slots directly on the motherboard. These slots can be accessed without the removal of the PCIe expansion module.
