INSTALLER / CONSUMER
SAFETY INFORMATION
PLEASE READ THIS MANUAL BE-
FORE INSTALLING AND USING
APPLIANCE.
WARNING!
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED EX-
ACTLY, A FIRE OR EXPLOSION MAY
RESULT CAUSING PROPERTY
DAMAGE, PERSONAL INJURY OR
LOSS OF LIFE.
— Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance.
— WHAT TO DO IF YOU SMELL
GAS:
•
Do not try to light any appliance.
•
Do not touch any electric switch; do
not use any phone in your building.
•
Immediately call your gas supplier
from your neighbor's phone. Follow
the gas supplier's instructions.
•
If you cannot reach your gas supplier,
call the fire department.
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
This appliance may be installed in an after
market permanently located manufactured
(mobile) home where not prohibited by
local codes.
This appliance is only for use with the type
of gas indicated on the rating plate.
This appliance is not convertible for use
with other gases unless a certified kit is
used.
INSTALLER: DO NOT DISCARD THIS MANUAL -LEAVE FOR HOMEOWNER
Radiance
Natural Vent Gas
Heater
Model RNVOD: 3340 thru 3349,
3355, 3356
Homeowner's Installation
and Operating Manual
CFM Specialty Home Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
www.majesticproducts.com • www.vermontcastings.com
4409
C E RT I F I E D
20004409 12/04 Rev. 10
Advertisement
Table of Contents
Related Manuals for Vermont Castings 3349
Summary of Contents for Vermont Castings 3349
-
Page 1: Safety Information
INSTALLER: DO NOT DISCARD THIS MANUAL -LEAVE FOR HOMEOWNER Radiance Natural Vent Gas Heater Model RNVOD: 3340 thru 3349, 3355, 3356 Homeowner’s Installation and Operating Manual CFM Specialty Home Products 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777 www.majesticproducts.com •... -
Page 2: Table Of Contents
Radiance Natural Vent Gas Heater PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING APPLIANCE. Thank you and congratulations on your purchase of a Vermont Castings stove. IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. -
Page 3: Installation & Operating Instructions
Installation & Operating Instructions The Radiance Natural Vent Room Heater, Model Nos. 3340 thru 3349, 3355, 3356 is a vented gas appliance listed to the ANSI Standard Z21.88b-2001 and CSA-2.33b-2001 for Vented Room Heaters, and CSA 2.17-M91, Gas-Fired Appliances For Use at High Altitudes. -
Page 4: Stove Dimensions
Radiance Natural Vent Gas Heater 4 " (114mm) Fig. 1 Radiance dimensions. Stove Dimensions 4" Inner Dia. 14 " (100mm) (378mm) 29 " (756mm) (711mm) 31" (787mm) See Page 5 for Flue Collar Centerline Dimensions. R A D I A N C E 28"... -
Page 5: Clearance Requirements
Clearance Requirements Minimum Clearances to Combustible Materials Measure side clearances as shown in Figures 2 through 5 from the outer edge of the cast iron stove top. Measure rear clearances from the rear sheet metal shroud. The Radiance heater is approved for installation into an alcove constructed of combustible materials to the dimensions and clearances shown on this page. -
Page 6: Gas Specifications
Radiance Natural Vent Gas Heater Gas Specifications Model Fuel Gas Control RNVODRN Millivolt RNVODRP Prop Millivolt Weight: Fully assembled 350 lbs. Gas Inlet and Manifold Pressures Natural Inlet Minimum 5.5” w.c. Inlet Maximum 14” w.c. Manifold Pressure 3.5” w.c. Radiance Natural Vent Certified to: ANSI Z21.88b-2001 / CSA Z2.33b-2001 Vented Gas Fireplace Heaters... -
Page 7: Passing Through A Combustible Wall Or Ceiling
Passing Through a Combustible Wall or Ceiling An approved pass-through device is always required when a vent passes through a combustible wall or ceiling. Check with the maker of the vent system for the correct listed devices that are available. A listed pass-through device is required whether or not the installation includes decorative pipe around the Type B venting system. -
Page 8: Assembly Procedures
Radiance Natural Vent Gas Heater Tools Required • Phillips screwdriver (stub) • power drill • utility knife • reciprocating saw • metal drill bit: size 28 (.140"/3.5mm) Unpack and Set Up the Stove The Radiance is shipped on its back. Cut the shipping straps and set stove upright. - Page 9 1. The fan kit includes a Blower Assembly and a Rheostat Assembly, connected by a cable. (Fig. 10) The Blower Assembly mounts to the bottom rear of the stove, and the Rheostat mounts to the left side of the valve. The assembly includes a 'snapstat' which automatically turns the fan On (or Off) above (or below) approximately 109˚F.
-
Page 10: Install The Optional Fan (Starting With Serial #1457 (Rnvodrn), #1944 (Rnvodrp)
Radiance Natural Vent Gas Heater Fig. 13 Attach rear shroud cover plate to the rear shroud. Rheostat Rheostat Retaining Collar Rheostat Knob Fig. 14 Attach the fan rheostat. Install the Optional Fan These instructions are for stoves with serial numbers starting at #1457 (RNVODRN), #1944 (RNVODRP). - Page 11 Snapstat Bracket Snapstat Module Fig. 17 Remove the snapstat and grommet from the bracket and insert the grommet into the inner shroud. Slot Outer Shroud Inner Shroud ST194 Fig. 18 Position the fan to engage the inner shroud with the fan bracket slots and secure with sheet metals screws.
-
Page 12: Venting System Assembly
Radiance Natural Vent Gas Heater Venting System Assembly Adjust the leg levelers as needed. They should not extend any further from the leg than necessary. The venting collar is on the sheet metal draft hood/heat exchanger assembly, over the firebox. Use a B-vent adapter, from the same maker as the rest of the B-vent components, to join the first section of venting to the draft hood. -
Page 13: Connect The Gas Supply Line
Connect the Gas Supply Line Check the Rating Plate attached by a steel cable to the firebox, to confirm that you have the appropriate firebox for the type of fuel to be used. The Radiance may be converted from one gas to another using the appropri- ate Fuel Conversion Kit listed on Page 26. -
Page 14: Thermostat Connection
Radiance Natural Vent Gas Heater Fig. 26 Attach switch wires to valve. Thermostat Connection (optional) Use only a thermostat rated for 500 - 750 millivolts. Check the table below for the appropriate gauge thermostat wire to use for the length of lead required in your installation. - Page 15 Right Log Right Rear Log Left Rear Log Left Decorative Bracket Grate Fig. 28 Install the left and right rear logs and the right log. Log rests on Lava Rock decorative grate Fig. 29 Completed log installation. 20004409 Radiance Natural Vent Gas Heater Left Rear Log Decorative Grate...
-
Page 16: Operation
Radiance Natural Vent Gas Heater Operable Doors The Radiance is shipped with the operable door front. The stove may be operated with the doors either open or closed. To open the front doors, insert the handle into the door latch stub and turn it to the right and up. (Fig. -
Page 17: Lighting And Operating Instructions
Lighting and Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit manu- ally. -
Page 18: Troubleshooting
Radiance Natural Vent Gas Heater Troubleshooting / Honeywell #8420 Gas Control System NOTE: Before troubleshooting the gas control system, be sure the external gas shutoff is in the “ON” position. WARNING: REMOVE THE GLASS PANEL BEFORE PERFORMING ANY GAS CONTROL SERVICE WORK. SYMPTOM POSSIBLE CAUSES A. -
Page 19: Fuel Conversion Instructions
WARNING! This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instruc- tions is not followed exactly, a fire, explosion or production of carbon monoxide may result causing property damage, personal injury or loss of life. - Page 20 Radiance Natural Vent Gas Heater 12. Insert blue painted screw when converting to natural gas and red painted screw when converting to LP. 13. Tighten screw (do not over tighten), replace cap. 14. Locate pilot. (Fig. 38) 15. Replace pilot orifice. •...
-
Page 21: Maintenance
Your Radiance Gas Heater will provide years of service with minimal upkeep. The following procedures will help ensure that your stove continues to function properly. Annual System Inspection Have the entire heater and venting system inspected annually by a qualified gas technician. Replace any worn or broken parts. -
Page 22: Gasket Replacement
Radiance Natural Vent Gas Heater Fig. 45 Release the latches to remove the glass frame. Gasket Replacement The Radiance Gas Heater uses a ‘tadpole’ type gasket to seal between the glass panel and the frame. In time, this gasket can become brittle and compressed and should be replaced. -
Page 23: Wiring Diagrams
Wiring Diagrams On/Off Switch Wiring TP/TH Black Optional Thermostat Wiring TP/TH Black Fig. 48 On/off switch and optional thermostat circuit. NOTE: IF ANY OF THE ORIGINAL WIRE, AS SUP- PLIED WITH THE APPLIANCE, MUST BE RE- PLACED, IT MUST BE REPLACED WITH TYPE SF- 2, 200°C WIRE OR ITS EQUIVALENT. -
Page 24: Replacement Parts
CFM Specialty Home Products reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. Radiance Natural Vent Gas Heater (RNVOD) Models: 03340 thru 3349, 3355, 3356 9a,b 8a,b,c,d 18a,b... - Page 25 Radiance Natural Vent (RNVOD) Models: 3340 thru 3349, 3355, 3356 Ref. Description Log Set -RDVOD/RNVOD Right Rear Log RDNOD/RNVOD Left Rear Log RDVOD/RNVOD Right Log RDVOD/RNVOD Manifold Assembly Lava Rock - Burner Frame, Glass RDV40 Glass, Gasket Med. Knit - RDV40...
- Page 26 Radiance Natural Vent Gas Heater Radiance Natural Vent (RNVOD) Models: 3340 thru 3349, 3355, 3356 Ref. Description Bracket, Left Log Base Pan Inner Gasket Bracket, Back Log - RDVOD Grille, RVF Screen, RVF 33a. Vent Switch Wire Assembly - RNV40 Serial #’s up to #1456 (RNVODRN), #1943 (RNVODRP)
-
Page 27: Optional Accessories
Fan Kits FK26 Fan The FK26 fan kit helps distribute heated air from within the firebox out into the room. The fan is controlled by a snapstat that turns power on and off as the firebox temperature rises above and falls below a preset temperature. - Page 28 Radiance Natural Vent Gas Heater 20004409...
- Page 29 Radiance Natural Vent Gas Heater 20004409...
-
Page 30: Warranty
Radiance Natural Vent Gas Heater PRODUCT COVERED BY THIS WARRANTY All Vermont Castings gas stoves, gas inserts, and gas fireplaces, and all Majestic or Northern Flame brand gas fireplaces equipped with an Insta-Flame Ceramic Burner, or standard steel tube burner. BASIC WARRANTY CFM Specialty Home Products (hereinafter referred to collectively as the Company) warrants that your new Vermont Castings or Majestic... - Page 31 PRODUIT COUVERT PAR LA PRÉSENTE GARANTIE L’ensemble des cuisinières à gaz, des poêles encastrables et des foyers à gaz Vermont Castings, ainsi que l’ensemble des foyers à gaz de marque Majestic ou Northern Flame équipés d’un brûleur en céramique Insta-Flame ou d’un brûleur en acier standard.
- Page 32 CFM Specialty Home Products 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777 www.majesticproducts.com • www.vermontcastings.com...
