X‑TERRA 705 Keypad
Power
Patterns: Scrolls through the Discrimination
Patterns (Coin & Treasure Mode only).
Mode: This button has three functions.
Toggles between Detect Modes:
Coin & Treasure Mode
Prospecting Mode
Activates Target ID Stabiliser.
Selects the automatic option for Ground Balance
and Noise Cancel.
All Metal: Toggles between the selected
discrimination pattern and the All Metal pattern.
Minus: Adjusts settings, reduces Iron Mask and
scrolls to the left through the discrimination
segments.
Menu/Select: Enters the Menu.
Accesses and scrolls through the detecting
settings.
LCD Display Area
Pinpoint/Detect: This button has two functions.
Pinpoint assists in locating the exact
position of a target prior to recovery.
Detect exits menu settings and returns to
detection.
Plus: Adjusts settings, increases Iron Mask and
scrolls to the right through the discrimination
segments.
Accept/Reject: Accepts or rejects certain metals
by turning on/off individual discrimination
segments (Coin & Treasure Mode only).
Tracking: Toggles between manual/auto Ground
Balance and Tracking Ground Balance.
Ground Balance: Activates the Ground Balance
adjustment to compensate for different types
of soil.
Backlight ON/OFF
