Minelab X-Terra 705 Quick Start Manual

Vflex technology
Hide thumbs Also See for X-Terra 705:

Advertisement

Quick Links

Download this manual See also: Owner's Manual, Instruction Manual

Advertisement

loading

Related Manuals for Minelab X-Terra 705

Summary of Contents for Minelab X-Terra 705

  • Page 2 Contents: 1.X-Terra 705 Display Pod 2.Detecting & Prospecting modes 3.X-Terra 705 Menu 4.Discrimination Scale 5.Ground Balance & Pinpointing...
  • Page 4 XTERRA 705 DISPLAY POD...
  • Page 5 XTERRA 705 LCD DISPLAY...

  • Page 7: Prospecting Mode

    Detecting Modes The X-TERRA 705 has two detecting modes: •Coin & Treasure Mode •Prospecting Mode Toggles between Coin & Treasure Mode and Prospecting Mode. Coin & Treasure Mode Coin & Treasure Mode is used for detecting valuable objects including old and modern coins, jewellery and artefacts.
  • Page 8 Prospecting Mode Prospecting Mode is used to find metal such as gold nuggets and relics in highly i eralised, diffi ult areas. Targets are identified by audio only. The number on the display shows the Iron Mask value, as does the Discrimination Scale. In this mode, the detector becomes more sensitive to small target signals.
  • Page 10 XTERRA 705 MENU...
  • Page 11 Sensitivity Choose the highest sta le se siti ity setti g to e sure the dete tor s opti u performance. Do this by holding the coil stationary; increase the Sensitivity until the detector becomes unstable; then reduce the Sensitivity by one or two settings until it is stable.
  • Page 12 Volume The X-TERRA 705 has proportional target signal volume. The sound produced by a distant target starts softly. As you get closer, the volume level increases rapidly until it reaches the maximum level that has been set. Tones The number of Target ID Tones may be selected from the Tones menu.
  • Page 14 Discrimination Scale Targets are also represented as a particular segment on a linear scale at the bottom of the display. Each discrimination segment represents a level of conductivity and ferrous content.
  • Page 15 Pre Set Discrimination Patterns The X-TERRA 705 has: In Coin & - Four preset Treasure Mode Discrimination Patterns - All Metal Pattern - Iron Mask Pattern Patterns toggle between Pattern 1, Pattern 2, Pattern 3 and Pattern 4.
  • Page 16 Editing Discrimination Pattern Method 1 In detection, a discrimination segment will flash, indicating its position on the dis ri i atio s ale a d the target s ID u er ill appear o the LCD. Press Accept/Reject to reject that target ID. Editing Discrimination Pattern Method 2 In detection, use + and –...
  • Page 17 All Metal Shortcut The X-TERRA 705 has an All Metal shortcut available in both modes. Press All Metal to toggle between the selected Pattern and All Metal. Iron Mask Discrimination In Prospecting Mode use + and – to adjust the Iron Mask Discrimination scale.
  • Page 18 Depth Indicator 1 = 0– ” –5 cm) 2 = 2– ” –10 cm) 3 = 4– ” –15 cm) –20 cm) 4 = 6–8” 5 = 8– ” –25 cm) (only operates in Coin & Treasure Mode)
  • Page 20 X-TERRA 705 – Ground Balance The X-TERRA 705 is capable of operating in two different types of grounds, magnetic (e.g. inland parks) and conductive (wet areas of salt water beaches). The Ground Balance setting can be adjusted in three ways;...
  • Page 21 Activating Ground Balance (Beach) Press Ground Balance Press and hold Ground Balance for three seconds. The beach umbrella icon will appear to indicate that Ground Balance (Beach) is activated. Auto Ground Balance Hold the oil parallel a d 4” a ove the grou d. Sele t Grou d Balance, Press Mode to activate Automatic Ground Balance, and begin...
  • Page 22 Coin & Treasure Mode Hold the oil parallel a d ” a o e the grou d. Sele t Grou d Balance, Continuously lower and raise the coil and listen to the Ground Balance tone. If the tone is low, increase the Ground Balance setting using +, if the tone is high, decrease the setting using –.
  • Page 23 While Tracking Ground Balance is activated, the Tracking icon and current Ground Balance value will be displayed. Pinpointing Enabling pinpoint instructs the X-TERRA 705 to temporarily disengage discrimination and become a non-motion detector. Targets normally discriminated against will emit a signal when beneath the coil.
