Models 3600PB & 3800PB
OWNER'S MANUAL
CAST IRON
ROOM HEATER
SAFETY NOTICE:
If this solid fuel room heater is not properly installed, a house fire may result. For your safety
and to reduce the risk of fire, follow the installation directions. Contact local building, fire
officials, or the authority having jurisdiction about restrictions and installation inspection
requirements in your area. Kindly save these instructions for future reference.
VERY IMPORTANT
PLEASE READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE YOUR NEW ROOM
HEATER. FAILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE,
BODILY INJURY, OR EVEN DEATH. FAILURE TO READ AND FOLLOW THESE INSTRUCTIONS
BEFORE YOU PROCEED MAY RESULT IN DAMAGE, VOIDING YOUR WARRANTY!
HOT WHILE IN OPERATION. KEEP CHILDREN, CLOTHING, AND FURNITURE AWAY.
CONTACT MAY CAUSE SKIN BURNS.
UNITED STATES STOVE COMPANY
227 Industrial Park Road
S
C
P.O.Box 151
U
S
South Pittsburg, TN 37380
(423) 837-2100
www.USSTOVE.com
851795
Advertisement
Table of Contents
Related Manuals for USSC Nashua 3600PB
Summary of Contents for USSC Nashua 3600PB
- Page 1 Models 3600PB & 3800PB OWNER'S MANUAL CAST IRON ROOM HEATER SAFETY NOTICE: If this solid fuel room heater is not properly installed, a house fire may result. For your safety and to reduce the risk of fire, follow the installation directions. Contact local building, fire officials, or the authority having jurisdiction about restrictions and installation inspection requirements in your area.
-
Page 2: Table Of Contents
Fire Burns to Quickly ... 16 Fire Burns to Quickly ... 16 Warranty Policy & Procedures ���������������������������������������������������������������������������������������������������� 17 3600PB Parts Diagram & List ������������������������������������������������������������������������������������������������������ 18 3800PB Parts Diagram & List ������������������������������������������������������������������������������������������������������ 19 How to order repair parts ������������������������������������������������������������������������������������������������������������ 20 Table of Contents... -
Page 3: Stove Safety
Stove Safety IT IS YOUR OR THE INSTALLER’S RESPONSIBILITY TO READ ALL SAFETY PRECAUTIONS AND FOLLOW THE PRESCRIBED DIRECTIONS� When properly maintained and operated your stove should give you many years of service. How- ever there are important safety aspects of these products that you need to be aware of when oper- ating a wood stove. -
Page 4: Before Installing Your Stove
Specifications Maximum Model Output 37,000BTU or 3600PB 11KW 63,000BTU or 3800PB 18.5KW FOR PURPOSES OF THE TAX CREDIT, BOTH OF THESE STOVES EXCEED THE 75% MAN- DATE, AS THE TEST CRITERIA WAS BASED SOLELY ON THE “LOWER HEAT VALUE,”... -
Page 5: Installation
Installation Unpacking and preparing your stove for installation. 1. Remove your stove from the outer packaging and place on floor. Please inspect stove and check that it is not damaged in any way. Never attempt to use a stove that has been damaged. 2. -
Page 6: Installation Clearances
B – Chimney Connector to sidewall C – Chimney Connector to cornerwall D – Unit to backwall E – Unit to sidewall F – Unit to cornerwall 3600PB Single Wall Connector Pipe 15.5” (394 mm) 28” (711 mm) 15” (381 mm) 13”... -
Page 7: Installation Clearances
Installation Clearances Only materials and items approved for solid fuel stoves should be used for your stove. Under no circumstances should you use aluminum or galvanized steel pipes for your stove flue. Always fit pipes with the narrow side down, this allow any creosote to run down the inside of the pipe and not to come out and cause an unsightly mess and possible fire hazard. -
Page 8: Chimney
This prevents any amount of condensed or liquid creosote from running down the outside of the pipe or the stove top. All joints, including the flue collar connection must be secured with three sheet metal screws to ensure that the sections do not separate. For the best performance the chimney connector should be as short and direct as possible, with no more than two 90°... -
Page 9: Factory Built Chimney
Factory Built Chimney When a metal prefabricated chimney is used, the manufacturer’s installation instructions must be followed. You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass-through and “T” section package, firestops (where needed), insulation shield, roof flashing, chimney cap, etc. -
Page 10: Masonry Chimney
Masonry Chimney Ensure that a masonry chimney meets the minimum standards of the National Fire Protection As- sociation (NFPA) by having it inspected by a professional. Make sure there are no cracks, loose mortar or other signs of deterioration and blockage. Have the chimney cleaned before the stove is installed and operated. -
Page 11: Combustible Wall Chimney Connector Pass-Throughs
Combustible Wall Chimney Connector Pass-Throughs NOTES: 1. Connectors to a masonry chimney, excepting method B, shall extend in one continuous section through the wall pass-through system and the chimney wall, to but not past the inner flue liner face. 2. A chimney connector shall not pass through an attic or roof space, closet or similar concealed space, or a floor, or ceiling. -
Page 12: Operating Your Stove
Operating Your Stove Do not use a grate, andiron or other fuel support method. Build fire directly on the hearth. Only open door to fuel/refuel the stove. Excess air can cause the stove to over fire. Do not over fire, if chimney or stove is glowing red you are over firing. Do not build the fire too close to the glass. -
Page 13: Refueling
Refueling Before refueling your stove, turn the air supply to high for a few moments until there is a good fire in the stove. This will ensure there is no build-up of harmful gases in the stove when the door is opened and will also get the new fuel burning quickly and not allow it to kill the fire. -
Page 14: Stove Maintenance
When you return to your stove, fully open both air controls until you have a good fire and then set to normal operating levels. Do not add fuel until the fire bed is hot and red. Then add a little for the first time and allow that to ignite before adding more. -
Page 15: Replacement Of Glass
Replacement of Glass 1. Remove the door from the stove and place on a flat surface. 2. Carefully remove all of the glass clips from the inside of the door. 3. Gently remove the glass panel and gasket. 4. Using a wire brush, remove all remaining debris from the glass area. 5. -
Page 16: Smoke In Room
Smoke in Room If the stove is properly installed it should not emit any smoke into your room. Should this happen, Check that your room is not air tight. This can easily be checked by opening a door or window. If the smoking stops you need to provide an additional air supply into the room. -
Page 17: Warranty Policy & Procedures
You may have other rights and obligations which vary from State to State. If you have a problem which proves difficult to resolve, feel free to contact United States Stove Company at 800.750.2723 and ask for Customer Service – Technical. -
Page 18: 3600Pb Parts Diagram & List
3600PB Parts Diagram & List PART # DESCRIPTION 40517 Hob (HF517U-1) 40518 Top Frame Casting (HF517U-2) 40519 Secondary Air Deflector Plate (HF517U-3) 891689 Small Cover Plate (HF517U-4) 40520 Top Baffle (HF517U-5) 40521 Front (HF517U-6) 40522 Left/Right Hand Side (HF517U-7) 40523... -
Page 19: 3800Pb Parts Diagram & List
3800PB Parts Diagram & List 38 39 33 34 31 32 PART # DESCRIPTION 40539 Hob (HF717U-1) 40540 Top Frame Casting (HF717U-2) 891716 Sealing Tape (HF717U-3) 891717 Slide Plate (HF717U-4) 891718 Slide Plate Holding Frame (HF717U-5) 40541 Back Slide Plate (HF717U-6) 40542 Front (HF717U-7) 40543... -
Page 20: How To Order Repair Parts
INFORMATION AS SHOWN IN THIS LIST: 1. THE PART NUMBER 2. THE PART DESCRIPTION 3. THE MODEL NUMBER: 3600PB 3800PB 4. THE SERIAL NUMBER:____________________ United States Stove Company 227 Industrial Park Road P.O. Box 151 South Pittsburg, TN 37380 (800) 750-2723 WWW.USSTOVE.COM...
