S T
O
MODEL 1321
Owners Manual
SOLID FUEL WARM AIR FURNACE
ASSEMBLY
INSTALLATION
OPERATION
REPAIR PARTS
CAUTION
IMPROPER INSTALLATION
READ ALL INSTRUCTIONS CAREFULLY
MAY VOID YOUR WARRANTY
BEFORE STARTING THE INSTALLATION
SAVE THIS MANUAL FOR
OR OPERATING THE FURNACE
FUTURE REFERENCE
FOR PARALLEL INSTALLATION WITH EXISTING AIR, GAS OR OIL FIRED FURNACE
OR FOR INSTALLATION AS A CENTRAL FURNACE
DO NOT USE THIS FURNACE IN A MOBILE HOME OR TRAILER
UNITED STATES STOVE COMPANY
WARNOCK HERSEY
S
C
227 Industrial Park Rd., P.O.Box 151
U
S
South Pittsburg, TN 37380
R
(423) 837-2100
851153A 10/96
