- Page 1 CR-AS24 YZ(S) SERVICE MANUAL RADIO RECEIVER • This Service Manual is the “Revision Publishing” and replaces “Simple Manual” of CR-AS24 <YZ(S)>, (S/M Code No. 09-023-457-5T1). S/M Code No. 09-024-457-5R1...
-
Page 2: Specifications
SPECIFICATIONS Frequency range: FM: 87.5 - 108 MHz AM: 530 - 1,605 kHz Ω) Maximum output: 160 mW (EIAJ 4 Power source: DC 3 V using two R6 (size AA) batteries Ω Speaker: Diameter 57 mm, 4 Maximum dimensions: 67.6 (W) x 114.7 (H) x 28.6 (D) mm (excluding projecting parts and controls) Weight: Approx. -
Page 3: Electrical Parts List
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers. UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL CR-AS24 YZBSC MAIN 0001 87-012-188-080 CHIP C CAP 47PF 50V +/-10% (1 MAIN... - Page 4 CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor Dimensions (mm) Wattage Type Tolerance Symbol Resistor Code Form 1/16W 1005 0.35 1/16W 1608 0.45 1/10W 2125 1.25 0.45 1/8W 3216 0.55 – 4 –...
- Page 5 WIRING (MAIN) <1 / 2> MAIN C.B (COMPONENT SIDE) NOTE : PVC1 PVC1 TUNE 1 2 3 R6 CF2 – 5 –...
- Page 6 WIRING (MAIN) <2 / 2> MAIN C.B (CONDUCTOR SIDE) (AM BAR ANTENNA) <WHT> NOTE : <BLK> LEDX <GRN> FM ROD ANT <RED> LED1 LED1 TUNING INDICATOR 25 28 <YEL> SPEAKER 4 ohms <BRN> – 6 –...
- Page 7 SCHEMATIC DIAGRAM PVC1 MAIN C.B PVC AM/FM FC-22125-4N000-0 TC1 - 4 VC10, 1A, 1B, 1C FM ROD ANT TUNE (AM BAR ANTENNA) TC4 VC10 C7 22p TC1 R8 1.5K VC1C 0.01 0.022 R11 1K 10/10 VC1A VC1B ROTARY VOL C8 27p R121S-10-1.5F-A50K FM SPRING COIL L5 AM OSC COIL...
-
Page 8: Ic Block Diagram
IC BLOCK DIAGRAM – 8 –... - Page 9 ADJUSTMENT MAIN C.B (COMPONENT SIDE) PVC1 1. AM IF Adjustment 4. FM Frequency Range Adjustment Settings : Test point IC1(KA22426D) pin 23 Settings : Test point IC1(KA22426D) pin 23 Adjustment Location : T1 Adjustment Location : L2, TC2 T1 ............... 450kHz L2 ...............
-
Page 10: Mechanical Exploded View
MECHANICAL EXPLODED VIEW – 10 –... -
