A–Width (Ring Diameter) – in. (mm)
B–Length – in. (mm)
C–Height (Handle) – in. (mm)
D–Height (Switch Box) – in. (mm)
Number of Blades
Path Width – in. (mm)
Sound Pressure (Weighted) – dBA
1. Sound pressure is "A" weighted . Measured at the
operators ear position while the walk-behind trowel is
operating at full throttle on concrete in a manner most
often experienced in "normal " circumstances. Sound
pressure may vary depending upon the condition of the
concrete. Hearing protection is always recommended.
J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 13
TROWEL SPECIFICATIONS/DIMENSIONS
C D
Figure 1. Dimensions
Table 1. Trowel Specifications
36.5 (927)
70.5 (1,790)
37.5 (953)
36 (914)
4
34.5 (876)
2
TOP VIEW
B
SIDE VIEW
Sound Pressure (Guaranteed) – dBA
Vibration (Hand/Arm) – ft/s
Electric Motor – H.P.
Rotor – RPM (Dry Concrete)
Operating Weight – lbs. (kg.)
Shipping Weight – lbs. (kg.)
2. The vibration level indicated is the maximum RMS
(Root Mean Square) value obtained at the handle
grip while operating the ride-on trowel on curing
concrete in a manner most often experienced in
"normal " circumstances. Values were obtained from
all three axes of motion. The values shown represent
the maximum RMS value from these measurements.
2
(m/s
)
2
2
1
2.0 (1.5 kW)
30-160
166 (75
191 (86)
