Covers All 22xx and 23xx Series Remote Starter/Alarms
-The system must be placed into Service Mode before any service work is started on the vehicle. It is
the sole responsibility of the vehicle owner to ensure that this is done. The manufacturer accepts no
liability or responsibility for accidental starting of the vehicle.
- CARBON MONOXIDE - Never Start in an Enclosed Building (Garage, Carport etc...)
- The Hood Pin Safety Switch Must Always be Installed!
- Never Install Automatic Transmission Remote Starters into a Manual Transmission Vehicle!
Advertisement
Table of Contents
Related Manuals for Ultra Start 22xx
Summary of Contents for Ultra Start 22xx
- Page 1 Covers All 22xx and 23xx Series Remote Starter/Alarms -The system must be placed into Service Mode before any service work is started on the vehicle. It is the sole responsibility of the vehicle owner to ensure that this is done. The manufacturer accepts no liability or responsibility for accidental starting of the vehicle.
-
Page 2: Table Of Contents
OWNER’S GUIDE Page 2 Table Of Contents Table Of Contents Welcome Feature List About Ultra Start FCC Notice Remote Starter Functions Remote Starting Extended Runtime Remote Stop Idle Mode Turbo Timer Mode Reservation Mode (Manual Transmissions Vehicles) Alarm Functions & Optional Features... -
Page 3: Welcome
Our limited lifetime warranty provides one of the best protection plans in the industry, giving both the consumer and the retailer confidence when they invest in an Ultra Start product. FCC Notice This device complies with Part 15 of the FCC rules. -
Page 4: Remote Starter Functions
OWNER’S GUIDE Page 4 Remote Sta r ter Functions Remote Star ting 1.Press and release the 2.The park lights will flash and the siren will chirp one time. 3.The vehicle will then remote start. The park lights will flash four times then remain on while the vehicle is running.* Never remote start if the vehicle is parked in a garage or attached carport! Operate in a well ventilated area only. -
Page 5: Reservation Mode (Manual Transmissions Vehicles)
REMOTE VEHICLE STARTER Manual transmission remote starters must be set into Reservation Mode before the remote starter will activate. There are two different ways to place the system into Reservation Mode. The activation type of Reservation Mode is determined when the system is installed. The default setting is Auto Reservation Mode. Auto Reservation Mode Step 1 - While the vehicle is running with the key, place the transmission into neutral and apply the park brake. -
Page 6: Alarm Functions/Optional Features
OWNER’S GUIDE Page 6 Alarm Functions/Optional Features* Arm the Alarm (Lock Doors)* 1.Press and release the LOCK button on the remote transmitter. 2.The park lights will flash and the siren will chirp one time. 3.The system will ARM and the doors will lock (optional). 4.The LEDs on the antenna will start flashing within five seconds. -
Page 7: Car Finder
REMOTE VEHICLE STARTER Button 4(#) - Optional operations(Dealer programmable feature) Car Finder (Default Setting) 1. Press and hold the # button for 3 seconds. 2.The park lights will flash and the horn(optional) will honk 5 times. Note: This feature can be used to locate the vehicle in a crowded parking lot. Trunk Release on the # button. -
Page 8: Cold Start/ Temperature Start Mode
OWNER’S GUIDE Page 8 Cold Start/Timer Mode Cold Start/Timer Mode will start the vehicle at a user selectable start interval or temperature setting. The vehicle can be set to start once every 1, 2, 3 or 4 hours in Timer Mode or 0,-5,-15 or -25 Celsius in Temperature Mode (LT Models Only) for a maximum 12 starts. -
Page 9: Service Mode
System Service Mode (Valet Mode) System Service Mode will disable the remote starter. This will only effect the remote start portion of the system. The optional lock, unlock and trunk release features will still be operational. When the vehicle is to have any under hood or service work done, the system must be placed into Service Mode. -
Page 10: Diagnostics
OWNER’S GUIDE Page 10 Diagnostics/ Diagnostics Chart If the remote starter does not activate when the start button is pressed the park lights will flash a diagnostic to indicate what shutdown input has been triggered. Example when the start button is pressed the park lights flash 3 times slowly. Looking at the chart below this would indicate that the system is in Service Mode. -
Page 11: 2Nd Car Operations
REMOTE VEHICLE STARTER 2nd Car Operation This feature will allow the operation of two Ultra Start remote car starters with one remote transmitter. This feature requires special programming from the dealer. To control 2nd car functions, press the # button at the same time as the command for the second vehicle. -
Page 12: Product Warranty
OWNER’S GUIDE Page 12 Limited Lifetime Warranty The manufacturer warrants to the original purchaser of their remote starters and alarms, that the product shall be free from defects in material and workmanship. However, should this product be proven to be defective, within a two year period from the original date of purchase, the manufacturer will, without charge to the purchaser (excluding any charges incurred to have the product delivered to the manufacturer), repair or replace any part of the remote starter and/or alarm which the manufacturer agrees...
