- Page 1 Revision 1.0 TYAN S1471 Pentium Class 75 thru 200MHz 430VX PCI-ISA System Board User's Manual...
-
Page 2: Table Of Contents
Table Of Contents 1. Introduction... 3 1.1 Overview...3 1.2 Hardware Specifications...4 1.3 Software Specifications... 5 1.4 Environment... 5 2. Board Installation... 6 2.1 Unpacking... 6 2.2 Installation... 6 3. S1471 On Board Resource Settings... 7 3.1 S1471 Board Layout & Jumper Locations... 7 3.2 Quick Reference for Jumpers... -
Page 3: Introduction
1. Introduction 1.1 Overview The S1471 is a quality, high performance mainboard designed forl Intel Pentium microprocessors. This mainboard utilizes the Intel 430VX chipset and can support CPU speeds of 75MHz through 200MHz. S1470 will also support the CyrixM1/6x86 CPU's and the Intel multimedia Pentium P55C which utilizes MMX commands. -
Page 4: Hardware Specifications
1.2 Hardware Specifications/Features wCPU Intel Pentium 75 MHz thru 200 MHz (Socket 7) Intel Pentium P55C Cyrix/IBM/SGS M1/6x86 P120, P150 & P166 wSpeed 50/60/66 MHz system bus 25/30/33 MHz PCI bus 7.5/8.33 MHz ISA bus speed wDRAM 2 banks of 72 pin SIMM and 2 DIMM Banks Supports 5V or 3.3V memory Supports EDO(Exended Data Out) DRAMs Supports SDRAM(Synchronous DRAM) -
Page 5: Software Specifications
wMouse On-board PS/2 mouse connector. 1.3 Software Specifications wBIOS Award or AMI BIOS AT CMOS setup, BIOS/CHIPSET setup, and hard disk utility included. Support for easy BIOS upgrades with flash EPROM chip. wO.S. Operates with MS-DOS, Windows 3.x, Windows for Work Group 3.x, Windows 95, Windows NT OS/2, Novell Netware, and SCO Unix. -
Page 6: Board Installation
2. Board Installation 2.1 Unpacking The mainboard package should contain the following: wS1471 Mainboard wOne IDE 40 pin cables wTwo serial cables w w One parallel cable wOne 34 pin floppy cable wUser's Manual The mainboard contains sensitive electric components which can be easily damaged by static electricity, so the mainboard should be left in its original packaging until it is ready to be installed. -
Page 7: S1471 On Board Resource Settings
3. On Board Resource Setting Figure 3.1 S1471 Board Layout KB CTR J 3 6 J 3 2 82371SB Voltage Regulator J 4 9 J 4 8 J 4 2 J 4 7 pin 1 J 4 3 J 4 0J 3 9 J 3 5 S1471-001-01 http://www.tyan.com PS/2... -
Page 8: Quick Reference For Jumpers
3.2 Jumper Settings CPU Speed Settings for Pentium P54C and P55C: 1-2, 3-4 Off CPU Speed Settings for Cyrix/SGS/IBM 6x86/M1: 1-2, 3-4 On CPU Voltage Regulator Settings: Pentium MMX requires two voltage sources, J20, J21, & J22 are settings for one source. - Page 9 Memory Voltage SIMMs: Some EDO memory uses 3.3V. Damage to system can result if these are set incorrectly! Volts Default 5V 3.3V Off Memory Voltage DIMMs: Default is 5V. Volts JP1 Default 5V 3.3V CPU Multiplier: J40 and J39 Host Bus Setting: J15 1-2,3-4 50MHz S1471-001-01 http://www.tyan.com Multiplier...
- Page 10 Reset Connector: J41 Turbo LED Connector: J48 Flash EPROM: J50 This jumper should be left at the factory default. Keylock Connector: J47 CMOS Resest/Password Reset: J45(Default off) If you at anytime need to reset the CMOS because you have forgotten your password do the following.
- Page 11 I/O Port Setting: J13 and J14 Default For Serial Port 1-2 Speaker Connector: J42 Turbo Switch: J49 Non-Turbo mode not supported by chipset. HDD LED: J43 Infra Red Interface: Con9 and Con10 S1471-001-01 http://www.tyan.com For IR Port Pinout Assignments Speaker out Ground + 5V Open for Turbo...
-
Page 12: Cmos Rtc
3.3 CMOS RTC CMOS RTC includes an internal battery and Real Time Clock circuit. It provides the date and the time for the system. Normally the life span of a RTC internal battery is 10 years. When replacing, you should use the same model. -
Page 13: Reset Connector
3.7 Hardware Reset Switch Connector Installation The RESET switch on your cases' display panel provides users with the HARDWARE RESET functinon which is the same as power on/off. The system will do a cold start after the RESET switch is pushed by the user. The RESET switch is a 2 pin connector and should be installed on jumper J41. -
Page 14: Dram Installation
3.9DRAM Installation The S1471 uses a 64-bit data path from memory to CPU and can accommodate up to 128 MB of RAM. The mainboard supports Fast Page Mode, and EDO (Extended Data Out) 72 pin SIMMs. SDRAM(Synchronous) are also supported in the DIMM slots. DIMM's must be of the unbuffered variety. -
Page 15: Cpu Installation
3.10 CPU Installation Several types of CPUs (75 thru 200MHz) can be used on S1471. Please refer to section 3.2 for the correct CPU jumper settings for your board. w The CPU is a sensitive electronic component and it can be easily damaged by static electricity. -
Page 16: Cache Upgrade
3.11 Upgrading Cache Memory The S1471 has either 256Kb or 512kb of on-board pipelined burst SRAM. Since the SRAM is surfaced mounted onto the board, the L2 Cache cannot be field upgraded. 3.12 Peripheral Device Installation After all the jumpers on the mainboard have been set, then it can be mounted into the case. -
Page 17: Connecting The Power Supply
3.13 Connecting the Power Supply The system power supply connectors on the mainboard is for a 5 volt power supply. Incorrect installation of the power supply could result in serious damage to the system board and connected peripherals. To connect the leads from either voltage power supply, you should first make sure the power supply is unplugged. - Page 18 Align the plastic guide pins on the lead cables to their receptacles on the mainboard. You may need to hold the lead at an angle to line it up.Once you have the guide pins aligned, press the lead connector so that the plastic clips on the lead snap into place and secure the lead to the connec- tor.
-
Page 19: Bios Configuration
4. BIOS Configuration Award's BIOS has a built in setup program that allows the user to modify the basic system configuration. This type of information is stored in the battery-backed CMOS SRAM. Entering incorrect information or forget- ting your password can lock you out of your system.(refer to 3.9 for resetting of CMOS) 4.1. -
Page 20: Control Keys
4.2. Control Keys PgUp key Increases the numeric value or make changes PgDn key Decreases the numeric value or make changes F1 key General help, only for Status Page Setup menu and Option Page Setup Menu F2 key Change color from a total of 16 colors F3 key Calendar, only for Status Page Setup Menu F4 key... -
Page 21: Getting Help
4.3. Getting Help 4.3.1. Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. 4.3.2. Setup Page menu/Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted items. - Page 22 w w Standard CMOS setup This setup page includes all the items in a standard compatible BIOS. w w BIOS features setup This setup page includes all of the enhanced features of Award's BIOS. w w Chipset features setup This setup page includes all the items of the 430HX chipset features. w Power Management setup Change, set, or disable system power management options w w PNP/PCI Configuration...
-
Page 23: Standard Cmos Setup Menu
4.5. Standard CMOS Setup Menu The items in Standard CMOS Setup Menu (Figure 4.2) are divided into 9 categories. Each category includes one or more setup items. Use the arrows to highlight the item and use the <PgUp> or <PgDn> keys to select the value you want for each item. - Page 24 w w Primary/Secondary Drive type This category identifies the types of hard disk drives that have been in- stalled in the computer. There are 46 predefined types and a user definable type. Press PgUp or PgDn to select a numbered hard disk type or type a number and press <Enter>.
- Page 25 w w Video This category detects the type of graphics adapter used for the primary display system. It must match your video display card and monitor. Al- though secondary monitors are supported, you do not have to select that type in setup. EGA/VGA Enhanced Graphics Adapter/Video Graphics Array.
-
Page 26: Bios Features Setup
Expanded Memory Expanded Memory (EMS) defines a 64Kb page frame in the area between 640K and 1Mb containing four 16K pages that are windows into the EMS memory. Programs issue requests to the EMS manager to switch the page to any part of EMS memory. - Page 27 w w Virus warning This category flashes on screen. During and after the system boot up, any attempt to write to the boot sector or the partition table of the hard disk drive will halt the system and the following error message will appear.
- Page 28 w w Boot Up Floppy Seek During POST, the BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360K type is 40 tracks while 720K, 1.2M and 1.44M are all 80 tracks. Default value is Enabled Enabled BIOS searches for floppy disk drive to determind if it is 40 or 80 tracks.
-
Page 29: Chipset Features Setup
w w Security Option This category allows you to limit access to the system setup, or just setup. Default value is Setup System The system will not boot and access to Setup will be denied if the correct password is not entered at the prompt Setup The system will boot, but access to setup will be denied if the password is not entered at the prompt... -
Page 30: Power Management Setup
4.7.1 Power Management Setup ROM ISA BIOS POWER MANAGEMENT SETUP AWARD SOFTWARE, INC Power Management :Disabled PM Control By APM Video Off Method :Blank Screen Doze Mode :Disabled Standby Mode :Disabled Suspend Mode :Disabled HDD Power Down :Disabled IRQ3 (Wake-Up Event) :Off IRQ4 (Wake-Up Event) :Off... - Page 31 w w Doze Mode Defines the continous idle time before the system enters Doze mode. w w Standby Mode Defines the continous idle time before the system enters Standby mode. w w Power Down Activities Defines the the activities that can cause the PM timers to reload. (Break- ing out of PM Mode) S1471-001-01 http://www.tyan.com...
-
Page 32: Pci Slot Configuration
4.8 PCI Slot Configuration ROM ISA BIOS PCI SLOT CONFIGURATION AWARD SOFTWARE, INC. Resource Controlled by :Manual Reset Configuration :Disabled IRQ3 assigned to :legacy ISA IRQ4 assigned to :legacy ISA IRQ5 assigned to :PCI/PnP IRQ7 assigned to :legacy ISA IRQ9 assigned to :PCI/PnP IRQ10 assigned to :PCI/PnP... - Page 33 w w Resources Controlled By The Award Plug and Play BIOS can automatically configure all the boot and Plug and Play compatible devices. If you seelect Auto, all the interrupt request and DMA assignment fields disappear, as the BIOS automatically assigns them. w w IRQ n assigned to When resources are controlled manually, assign each system interrupt as one of the following types, depending on the type of device using...
-
Page 34: Integrated Peripherals
4.9 Integrated Peripherals Integrated Peripherals Award Software, Inc. IDE HDD Block Mode IDE Primary Master PIO IDE Primary Slave PIO IDE Secondary Master PIO IDE Secondary Slave PIO On-Chip Primary PCI-IDE On-Chip Secondary PCI-IDE :Enable PCI Slot IDE 2nd Channel On-Board FDC Controller On-Board Serial Port 1 On-Board Serial Port 2... -
Page 35: Load Setup Defaults
4.9. LOAD SETUP DEFAULTS ROM ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE INC. STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP Load Setup Defaults (Y/N)? N PCI SLOT configuration LOAD SETUP DEFAULTS ESC : Save & Exit Setup F10 : Quit Load SETUP Defaults except standard CMOS SETUP w w Load SETUP defaults To load SETUP default values to CMOS SRAM, enter "Y". - Page 36 ROM ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE, INC. STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP Enter Password PCI SLOT CONFIGURATION LOAD SETUP DEFAULTS ESC : Save & Exit Setup F10 : Quit Change/Set/Disable Password Type the password, up to eight characters, and press <Enter>. The password typed now will clear the previously entered password from CMOS memory.
-
Page 37: Ide Hdd Auto Detection
4.11. IDE HDD AUTO DETECTION ROM ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE, INC. Drive C: (202 Mb) Do you want to accept this as drive C (Y/N)? Type "Y" to accept the H.D.D parameter reported by BIOS. Type "N" to keep the old H.D.D parameter info. -
Page 38: Flash Writer Utility
5.0 Flash Writer Utility Warning: Do not flash the BIOS unless instructed by your dealer. You can upgrade the BIOS of your mainboard by using a "Flash Memory Writer"(FMW) utility. This utility can be downloaded from Tyan's BBS(Consult your system vendor for the phone #) or web site. The system BIOS is stored on a 'flash' EPROM ROM chip on the mainboard which can be erased and reprogrammed by the FMW. - Page 39 To reprogram the System BIOS, you must first do the following: 1. Check jumper J50.(Default pins 1-2) The S1471 uses a 5V Flash EPROM so jumper J50 should be left in the default postion on pins 1 and 2. This jumper should never be moved.
-
Page 40: The Flash Memory Writer Utility Screen
Once you have satisfied the two requirements mentioned above, you can run FMW. You can copy the contents of the “Flash” directory to your hard drive, or you can run the utility from a backup of the support floppy disk. Make sure the new BIOS file is in the same directory as the FMW utility. -
Page 41: System Resources
6.0 System Resource 6.1. TIMER & DMA CHANNEL MAP TIMER MAP: TIMER Channel-0 system timer interrupt TIMER Channel-1 DRAM REFRESH request TIMER Channel-2 SPEAKER tone generator DMA CHANNELS: DMA Channel-0 Available DMA Channel-1 Available DMA Channel-2 FLOPPY DISK adapter DMA Channel-3 Available DMA Channel-4 Cascade for DMA controller 1 DMA Channel-5 Available DMA Channel-6 Available...
