- Page 1 S1680S-001-02...
-
Page 2: Table Of Contents
3.4 Installation/Removal of Pentium II Passive Processors ................... 19 4. T roubleShooting ..............22 4.1 Troubleshooting Procedures ........22 4.2 Technical Support Procedures ........ 24 4.3 Returning Merchandise for Service......24 5. Declaration of Conformity..........25 6. BIOS Speaker beep codes..........26 S1680S-001-02 http://www.tyan.com... -
Page 3: Introduction
233MHz to 300MHz. The S1680S will also support the Intel Pentium Pro Processors with a Tyan Riser Card (M2020). The 440FX PCIset also supports up to 1GB (1024MB) of system memory utilizing either EDO, FPM or Parity with ECC. -
Page 4: Hardware Specifications
• EDO (Extended Data Out) DRAMs • FPM (Fast Page Mode) DRAMs • ECC (Error Correcting Code) or Parity checking Expansion • Five 32-bit PCI Bus Master slots • Four 16-bit ISA Bus (one shared/eight usable slots) slots S1680S-001-02 http://www.tyan.com... -
Page 5: Software Specifications
Deep Green and Energy Star compliant. Operating System Operates with MS-DOS, Windows 3.x, Windows for Workgroups, Windows 95, OS/2, and SCO Unix. Tyan is also certified with Solaris. 1.4. Manual Organization Chapter 1: "Introduction" describes the features and performance of the S1680S motherboard. -
Page 6: Manual Conventions
CMOS errors. Both AMI and Award BIOS Setup documents are also available in the Adobe Acrobat format. Please refer to theWeb Page located at ftp:// ftp.tyan.com/manual/s1680sa.pdf for AMI and ftp://ftp.tyan.com/manual/ s1680sb.pdf for Award BIOS information. 1.5. Manual Conventions... - Page 7 Pentium II Boxed (Active) CPU Shown with Power Connector for Fan Pentium II (Passive) CPU Shown with Heat-sink S1680S-001-02...
-
Page 8: Board Installation
2.2 Installation of the motherboard You are now ready to install your motherboard. The mounting hole pattern of the board matches the Baby-AT system board specifications. Please install the board in the chassis designed for a standard Baby-AT system. S1680S-001-02 http://www.tyan.com... -
Page 9: S1680S Board Layout & Jumper Locations
• • • • • • • • • • • • • • • • • • • • • • • • • • • See Page 11 for J45 Pin Definition (For more information about this motherboard, please visit our W eb Page and Clickable motherboards at http://www.tyan.com /html/faq.html.) S1680S Motherboard Layout S1680S-001-02... - Page 10 12V CPU Fan (Pin 2 is "+"--positive) Keyboard/Lock CON 6 LPT1 CON5 & 1 CON5: COM1, CON1:COM2 CON4 CON2 & 3 CON2: Primary IDE, CON3: Secondary IDE CON7 Reserved J28-30, J34, J46, J48, J49 Block J45 Pin Assignments S1680S-001-02 http://www.tyan.com...
- Page 11 CPU Speed Settings for Pentium II and Pentium Pro Processors: *266 (*Default: 266) DRAM Voltage Select 3.3V (*5V-default) Bus Speed HOST speed PCI speed 60MHz 30MHz 66MHz 33MHz Flash BIOS V oltage Select: J33(--Do not Change!) *5V : Pin 1 and Pin 2 (Closed) (Default) 12V: Pin 2 and Pin 3 (Closed) 5V Default CMOS Reset: (J36)
-
Page 12: Cmos Rtc
CMOS Chipset Default Reg- ister for the system. Normally, the life span of a RTC internal battery is more than 10 years. This RTC chip cannot be field upgraded and can only be changed at a Tyan repairing facility. S1680S-001-02 http://www.tyan.com... -
Page 13: Installing Cables And Connectors
2.5 Installing Cables and Connectors 2.5.1 Speaker Connector Installation (J45) Your S1680S board provides a 4-pin header to connect the speaker. The speaker is connected to pins 24-27 of J45. (Refer to Page 10 and Page 11 for detailed information.) 2.5.2 Hardware Reset Switch Connector Installation (J45) The RESET switch on your case's display panel provides you with the HARDWARE RESET function which is the same as power on/off. - Page 14 However, we do not recommend that you flash the onboard BIOS. This procedure should only be done by a qualified technician or a Tyan technical support engineer. J33 determines which type of Flash EPROM is used. This jumper has been set to match the onboard BIOS chip.
-
Page 15: Dram Installation
2.6 DRAM Installation The S1680S uses a 64-bit data path from memory to the CPU which will accommodate up to 1GB of RAM. The motherboard supports FPM (Fast Page Mode), EDO (Extended Data Out), ECC (Error Correcting Code), and Parity 72-pin SIMMs. The following table shows some of the avail- able memory configurations. -
Page 16: L2 Cache Memory/Sram Memory
PCI-Bus slots will support either a Master or a Slave device. 2.10 Connecting the power supply The system is configured for a standard AT power supply. The AT connectors can only be plugged in one way and should install easily. S1680S-001-02 http://www.tyan.com... -
Page 17: Cpu Installation And Removal
Chapter 3: CPU Installation and Removal Pentium II (233 through 300 MHz) and Pentium Pro Processors (150 through 200 MHz) can be used on the S1680S board. (Please refer to section 2.3 for the correct CPU jumper settings for your board.) The S1680S board provides a slot for the Pentium II Processor. -
Page 18: Installing The Cooling Fan
CPU until you hear a click. A clicking sound indicates that the CPU is unlocked. 2. When the CPU is unlocked, gently pull the CPU out from the Pentium II Slot and the Retention Module. S1680S-001-02 http://www.tyan.com... -
Page 19: Installation/Removal Of Pentium Ii Passive Processors
3.4 Installation and Removal of the Pentium II Passive Processor Pentium II Passive CPU Module (Unlike Active Processors, Passive Processors are not equipped with cooling fans. Passive Processors are equipped with heat sinks instead.) Each CPU package should also contain the following: CPU Retention Module (x1) Heat-sink Retention Bracket with mounting locks (x1) Mounting Attach-mounts (x 2) Heat-sink Lock (x1) - Page 20 CPU, the motherboard, and/or the CPU socket. 2. Slowly press down on the CPU module until the CPU locks into place. A click will be heard when the CPU is locked securely into the module. S1680S-001-02 http://www.tyan.com...
- Page 21 3.4.4: Installation of the Heat-sink Heat-sink Lock Lock The Heat-sink lock has 4 notches which will correspond to the 4 pins on the Heat-sink mounting bracket. Gently slide the lock between the Heat-sink onto the Heat-sink mounting bracket until both sides of the lock are firmly secured. A clicking sound will be heard when the lock is securely fastened to the Heat-sink mounting bracket.
-
Page 22: T Roubleshooting
3. Determine if different speeds of SIMMs have been installed in the same or different banks, and the BIOS setup is configured for the slowest speed of RAM used. It is recommended to use the same RAM speed for SIMMs in different banks. S1680S-001-02 http://www.tyan.com... - Page 23 4. Check for bad SIMM modules and chips. Troubleshooting Flowchart S1680S-001-02...
-
Page 24: Technical Support Procedures
4.2 T echnical Support Procedures Be sure to go through the "Troubleshooting Procedures" section in this chapter, and visit our Web site before calling Technical Support. (Tyan's Web site address is: http://www.tyan.com.) Before you call, have the following information ready: 1. -
Page 25: Declaration Of Conformity
Chapter 5: Compliance Compliance Information Statement ( Declaration of Conformity Procedure-DOC) Notice for the USA FCC Part 15: This Device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received including interference that may cause undesired operation. -
Page 26: Bios Speaker Beep Codes
Chapter 6: Speaker Beep codes All Tyan motherboards come with a BIOS feature called "beep codes". What these do is inform you (the user) about potential problems in your configu- ration. These errors can occur during POST (Power On Self Test), which is performed every time the system is powered on.
