8.1.7. Remote controller address manual set-
ting [No.15]
Notes
• In the case of automatic address settings, do not
change the remote controller address for the indoor
unit, and keep it at the initial setting of 0. Addresses
will be automatically set when initially starting up
this product.
• Only set addresses manually when using different
numbers for addresses. A remote controller address
for the indoor unit needs to be set. Set the remote
controller addresses for the indoor units which are
connected using the same remote controller cable
with a range from 1 to 9 and from A (10) to F(15),
without any duplicates. (Do not use "0" for confi gu-
ration).) For how to confi gure the remote controller
addresses for the indoor unit, refer to its installation
manual.
• The address for this product can be set from 1 to 32.
However, do not set the same number as that for the
remote controller address of an indoor unit, remote
controller, or other unit connected using the same
remote controller cable.
• Setting is refl ected after the power is turned on
again.
(1) Select the "15" in F1 settings. Then touch [
(2) You can check current allocation of 2-wire remote
controller address (system number and unit number).
Set the unit number with [
number cannot be changed.
(2)
(1)
Address automatically
allocated
(3) Touch [
] button to return to the F1 settings
selection screen.
8.1.8. LCD backlight settings [No.30]
Notes
• Set the backlight enable/disable setting and lighting
time.
• If there is no button operation within the set time,
the backlight switches off.
• Even if this setting is set, if there is no button opera-
tion for more than 6 seconds while the unit is not in
operation, the back light switches off.
] button.
] or [
] button. System
System number
Unit number
(1) Select the "30" in F1 settings. Then touch [
ton.
(2) Select "1: Valid" with [
[
] button. (Select "0: Invalid", and touch [
ton to return to the F1 settings selection screen.)
(1)
(2)
0 : Invalid
1 : Valid
(3) Select the "30: 30 seconds" or the "60: 60 seconds"
with [
] or [
] button.
30 : 30 seconds
60 : 60 seconds
(4) Touch [
] button to return to the F1 settings selec-
tion screen.
8.1.9. Wireless remote controller signal input
setting [No.32]
• This product can receive the wireless remote controller
signals. Use this setting to enable/disable the signal
reception.
• The indoor unit custom code can be changed.
Select the appropriate custom code.(Note that the indoor
unit cannot receive a signal if the indoor unit has not
been set for the appropriate custom code.)
(1) Select the "32" in F1 settings. Then touch [
ton.
(2) Select the following custom item with [
button.
Setting item
Signal reception disabled
Signal reception enabled, Custom code A
Signal reception enabled, Custom code B
Signal reception enabled, Custom code C
Signal reception enabled, Custom code D
] but-
] or [
] button, and touch
] but-
] but-
] or [
]
◆
(
... Factory setting)
S e t t i n g
value
–
A ( ◆ )
b
C
d
En-9
