Fujitsu UTY-RCRYZ1 Installation Manual page 7

Setting Items
F1 settings mode: Initial settings
Item No.
05
8.1.1. Temperature unit setting
06
8.1.2. Remote controller master/slave setting
07
8.1.3. Remote controller sensor setting
12
8.1.4. Master indoor unit setting
13
8.1.5. Function setting
14
8.1.6. Remote controller address reset
8.1.7. Remote controller address manual set-
15
ting
30
8.1.8. LCD backlight settings
8.1.9. Wireless remote controller signal input
32
settings
F2 settings mode: Maintenance settings
Item No.
02
8.2.1. Error details
03
8.2.2. Version
09
8.2.3. Test run
10
8.2.4. Indoor unit address verifi cation
11
8.2.5. Check the indoor unit position
16
8.2.6. Initialization
• Touch [ ] button to end or to suspend settings.
(5) Touch and hold [
], [
at least 2 seconds at the same time to return to the
"Monitor Mode" screen.
Note
Selectable items differ according to settings when
equipment is set up. Operation does not proceed to
items that cannot be selected.
8.1. F1 settings mode: Initial settings
8.1.1. Temperature unit setting [No.05]
(1) Select the "05" in F1 settings. Then touch [
ton.
(2) Select the "0: °C" or the "1: °F" with [
ton.
(1) (2)
(3) Touch [ ] button to return to the F1 settings selec-
tion screen.
Setting Item
Setting Item
], and [ ] button for
] but-
] or [ ] but-
0: °C
1: °F
8.1.2. Remote controller master/slave setting
[No.06]
Notes
• Make only one of the remote controller of the group
the "Master".
• When remote controllers are set to "Slave", setting
items will be restricted.
(1) Select the "06" in F1 settings. Then touch [
ton.
(2) Select the "0: Master" or the "1: Slave" with [
[ ] button.
(1)
(2)
0: Master
1: Slave
(3) Touch [ ] button.
If there is no problem, return
to F1 settings selection
screen.
• If "0" is displayed, "Master unit" is not connected.
• If "Master" is 0, and you wish to set this product to "Mas-
ter", repeat the settings after touching [
• To suspend the settings part way through, touch [
button. Return to the F1 settings selection screen.
8.1.3. Remote controller sensor setting
[No.07]
(1) Select the "07" in F1 settings. Then touch [
ton.
(2) Select the "0: Disable (Not used)" or the "1: Enable
(Used)" with [ ] or [
0 (Disable): The indoor unit room temperature sensor
is used.
The room temperature is not displayed.
1 (Enable): This product room temperature sensor is
used.
The room temperature is displayed.
(1)
(2)
0: Disable
1: Enable
(3) Touch [ ] button to return to the F1 settings selec-
tion screen.
] but-
] or
Number of Master units
] button.
]
] but-
] button.
En-7
