  • Page 1 AC2100 Dual Band Gigabit WiFi Router User Guide...
  • Page 2 Tenda does not assume any liability that may occur due to the use or application of the product described herein. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information and recommendations in this document do not constitute the warranty of any kind, express or implied.
  • Page 3 Thank you for choosing Tenda! Please read this user guide before you start. Conventions This user guide is applicable to the following routers. AC23 is used for illustration in this guide unless it is specified. The contained images and UI screenshots are subject to the actual products.
  • Page 4 If you need more help, contact us by any of the following means. We will be glad to assist you as soon as possible. Global: (86) 755-27657180 (China Time Zone) United States: 1-800-570-5892 (Toll Free: 7 x 24 hours) support@tenda.cn Hotline Email Canada: 1-888-998-8966 (Toll Free: Mon - Fri 9 am - 6 pm PST) Hong Kong: 00852-81931998...

  • Page 5: Table Of Contents

    Content Get to know your device......................1 1.1 Introduction........................1 1.2 LED indicator ........................1 1.3 Ports and buttons ......................3 1.4 Label ..........................5 Web UI ............................. 6 2.1 Log in to the web UI ......................6 2.2 Log out of the web UI ......................7 2.3 Web UI layout ........................
  • Page 6 5.1.4 Hide the WiFi network ..................32 5.1.5 Connect to a hidden WiFi network ................ 33 5.2 WiFi schedule ........................35 5.2.1 Overview....................... 35 5.2.2 An example of configuring WiFi schedule .............. 35 5.3 Wireless repeating ......................37 5.3.1 Overview....................... 37 5.3.2 Extend the existing WiFi network ................
  • Page 7 9.2 Access USB resources on a computer within the LAN ............85 9.3 Access USB resources on a computer from the internet ........... 87 9.4 Access USB resources with the Tenda WiFi App ............... 90 10 IPv6 ............................92 10.1 IPv6 WAN settings......................92 10.1.1 Connect to the IPv6 network of ISPs ..............
  • Page 8 12.8.2 Restore previous configurations of the router ........... 166 12.9 Remote management ....................168 12.9.1 Overview ......................168 12.9.2 Enable Tenda techical support to acces and manage the web UI ....... 169 12.10 System status ......................171 12.10.1 Basic information .................... 171 12.10.2 WAN status .....................
  • Page 9 Appendix ............................. 178 A.1 Configuring the computer to obtain an IPv4 address automatically ....... 178 A.1.1 Windows 10 ......................178 A.1.2 Windows 8 ......................181 A.1.3 Windows 7 ......................183 A.2 Default parameters......................185 A.3 Acronyms and Abbreviations ..................186 viii...

  • Page 10: Get To Know Your Device

    PPPoE user name and password migration for instance internet access, and IPv6 for smoother internet experience without network address translation (NAT). The wireless rate is illustrated with AC23 as the example. Please refer to package for the actual wireless rate for each model.
  • Page 11 LED indicator Status Description The router is starting. ⚫ If the indicator still lights solid on after the router completes ⚫ Solid on startup, it indicates that the router is connected to the internet successfully. Blinking The router works properly. The system is faulty.

  • Page 12: Ports And Buttons

    Ports and buttons Port/Button Description Power jack. POWER It is used to connect to the included power adapter. It is used to start the WPS negotiation process, or to reset the router. WPS: Press the button of the router for 1 to 3 seconds. Within 2 minutes, enable ⚫...
  • Page 13 It is gigabit auto-negotiation Ethernet port, used to connect this router to the internet, such as a LAN port from the modem or the Ethernet jack provided by your ISP. 1/2 (AC21 & AC23) They are gigabit auto-negotiation LAN ports, used to connect to the wired devices such as computers or switches.

  • Page 14: Label

    The bottom label shows the login IP address, MAC address of the router, serial number, SSID and Pin No. See the following figure. Here AC23 is used for illustration. IP Address: It specifies the default address used to log in to the web UI of the router.

  • Page 15: Web Ui

    Connect your smartphone to the WiFi network, or connect your computer to a LAN port (1, 2 and IPTV/3 for AC23 and AC21, and 1, 2, 3 and IPTV/4 for AC19) of the router (AC23 is used for illustration here).

  • Page 16: Log Out Of The Web Ui

    Ensure that the router is powered on properly. ⚫ Ensure that the computer is connected to a LAN port (1, 2 and IPTV/3 for AC23 and AC21, and 1, 2, ⚫ 3 and IPTV/4 for AC19) of the router, and Configuring the computer to obtain an IP address automatically.

  • Page 17: Web Ui Layout

    Web UI layout The web UI of the router consists of two sections, including the navigation bar and the configuration area. See the following figure. Name Description It is used to display the function menu of the router. Users can select Navigation ❶...

  • Page 18: Internet Status

    Internet status Log in to the web UI of the router and choose Internet Status to enter the page. On this page, you can find the following information. Internet status − Wireless information − System information − Online devices information −...
  • Page 19 When a red cross and “Connection failed.” are shown between the Internet and the Router, it indicates that the internet connection is abnormal. Please click Connection failed. to navigate to the Internet Settings page and follow the instructions to solve the problem. When “Please ensure that the cable between the Internet port of the router and the modem is properly...
  • Page 20 When “The user name and password are incorrect.” is shown on the page, it indicates that the user name and password you entered are incorrect. Please re-enter the user name and password. Please consider the following tips when entering the user name and password: Pay attention to case sensitivity, such as “Z”...
  • Page 21 Modify the MAC address of WAN port by referring to Change the MAC address of the − port. Use another device to configure the router again. − Ensure that your internet service does not expire. − If the problem persists, contact Tenda technical support.

  • Page 22: Wireless Information

    Wireless information To view or configure the wireless information: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in to the web UI of the router. Step 2 Choose Internet Status. Step 3 Click ---End...

  • Page 23: System Information

    System information To view the wireless information: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in to the web UI of the router. Step 2 Choose Internet Status. Step 3 Click ---End For detailed description of parameters on this page, refer to...

  • Page 24: Wan Status

    3.3.2 WAN status In this part, you can view the information of the WAN port, including connection type, connection status and connection duration, etc. 3.3.3 LAN status In this part, you can view the LAN information such as LAN IPv4 address, subnet mask and MAC address.

  • Page 25: Wifi Status

    3.3.4 WiFi status In this part, you can view the information of 2.4 GHz and 5 GHz WiFi network, including the status, visibility, hotspot name and encryption mode, etc.

  • Page 26: Ipv6 Status

    3.3.5 IPv6 status This part is only displayed when the IPv6 function is enabled. You can view the information of IPv6 connection, including connection type, IPv6 WAN address and IPv6 LAN address.

  • Page 27: Online Device Information

    Online device information On this page, you can view the information of devices connected to the router, including the upload speed, download speed and access type, etc. You can also add devices to the blacklist. To access the page: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in to the web UI of the router.

  • Page 28: Remove Devices From The Blacklist

    added to the blacklist. 3.4.2 Remove devices from the blacklist To remove devices from the blacklist as required: Step 1 Choose Blacklist, and target the device to be removed from the blacklist. Step 2 Click Remove. ---End...

  • Page 29: Usb Information

    USB information This page and function are only available in AC19, which has a USB port. On this page, you can view the information of the USB storage device connected to the router. When you connect a USB storage device to the USB port, the Internet Status page is shown as below.

  • Page 31: Internet Settings

    Access the internet with a PPPoE account If the ISP provides you with PPPoE user name and password, you can choose this connection type to access the internet. The application scenario is shown below (AC23 is used for illustration here).
  • Page 32 Configuring procedure: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in to the web UI of the router. Step 2 Choose Internet Settings. Step 3 Set Connection Type to PPPoE. Step 4 Enter the ISP User Name and ISP Password.
  • Page 33 If you fail to access the internet, try the following methods: “No response from the remote server. Please check whether your computer can − access the internet directly using your Modem. If no, contact your ISP for help.” is shown on the page, you are recommended to choose Dynamic IP Address to access the internet.

  • Page 34: Access The Internet Through Dynamic Ip Address

    Your ISP does not provide PPPoE user name and password, or any information including IP address, subnet mask, default gateway and DNS server. − You have a router with internet access and want to add an AC23 as the other one. The application scenario is shown below. Configuring procedure: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in...
  • Page 35 Wait a moment until “Connected. You can access the internet now.” is shown on the page, and you can access the internet. If you fail to access the internet, refer to refer to View the internet status to find a solution. Parameter description Parameter Description...

  • Page 36: Access The Internet With A Set Of Static Ip Address Information

    Access the internet with a set of static IP address information When your ISP provides you with information including IP address, subnet mask, default gateway and DNS server, you can choose this connection type to access the internet. Configuring procedure: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in to the web UI of the router.
  • Page 37 Wait a moment until “Connected. You can access the internet now.” is shown on the page, you can access the internet. If you fail to access the internet, refer to refer to View the internet status to find a solution. Parameter description Parameter Description...

  • Page 38: Wifi Settings

    WiFi settings WiFi name & password 5.1.1 Overview To access the configuration page, log in to the web UI of the router, and navigate to WiFi Settings > WiFi Name & Password. On this page, you can configure basic WiFi parameters, such as the WiFi name and password. Parameter description Parameter Description...

  • Page 39: Separate The 2.4 Ghz Wi-Fi Name From 5 Ghz Wi-Fi Name

    Parameter Description You can enable or disable the 2.4 GHz network and 5 GHz network separately when the Unify 2.4 GHz & 5 GHz function is disabled. 2.4 GHz Network If the wireless devices such as mobile phones are far away from the router, or ⚫...

  • Page 40: Change The Wifi Name And Wifi Password

    The router supports both 2.4 GHz and 5 GHz WiFi networks. Assume that you want to change the 2.4 GHz WiFi name and password to John_Doe_2.4GHz and Tenda+Wireless24, and the 5 GHz WiFi name and password to John_Doe_5GHz and Tenda+Wireless5. Both networks adopt WPA/WPA2-PSK (recommended) as the encryption type.

  • Page 41: Hide The Wifi Network

    Choose an Encryption Mode, which is WPA/WPA2-PSK (recommended) in this example. Change the WiFi Password of the 2.4 GHz network, which is Tenda+Wireless24 in this example. Step 5 Change the parameters of the 5 GHz network. Change the WiFi Name of the 5 GHz network, which is John_Doe_5GHz in this example.

  • Page 42: Connect To A Hidden Wifi Network

    − Encryption type: WPA/WPA2-PSK (recommended) − WiFi password: Tenda+Wireless245 − If you do not remember the wireless parameters of the Wi-Fi network, log in to the web UI of the router and navigate to Wi-Fi Settings > Wi-Fi Name & Password to find it.
  • Page 43 Step 3 Scroll the WiFi list to the bottom, and tap Other…. Step 4 Enter the WiFi name and password, which are John_Doe and Tenda+Wireless245 in this example. Step 5 Set security to WPA2/WPA3 (If WPA2/WPA3 is not available, choose WPA2).

  • Page 44: Wifi Schedule

    WiFi schedule 5.2.1 Overview This WiFi Schedule function allows you to disable the WiFi networks of the router at specified period of time. By default, this function is disabled. To access the configuration page, log in to the web UI of the router, and choose WiFi Settings > WiFi Schedule.
  • Page 45 Step 2 Choose WiFi Settings > WiFi Schedule. Step 3 Enable WiFi Schedule. Step 4 Set a period for the WiFi networks to be disabled, which is 22:00~07:00 in this example. Step 5 Set the days when the functions works, which is Every Day in this example. Step 6 Click Save.

  • Page 46: Wireless Repeating

    Wireless repeating 5.3.1 Overview By configuring the wireless repeating function, you can extend the coverage of an existing network. To access the configuration page, log in to the web UI of the router, and choose WiFi Settings > Wireless Repeating. This function is disabled by default.

  • Page 47: Extend The Existing Wifi Network

    When there is already a router with internet access in your home, you can refer to the configurations in this part to extend the WiFi network coverage. AC23 is used for illustration here. Assume that your existing WiFi name and password are: WiFi name: Home_WiFi −...
  • Page 48 WiFi network of your new router, or connect a computer to a LAN port of the router (1, 2, IPTV/3 for AC21 and AC23; 1, 2, 3, IPTV/4 for AC19). Do not connect any device to the WAN port of the new router.
  • Page 49 Do not set login and WiFi password now by ticking Not Required, and click Next. Click Ignore. Step 2 Set the new router to WISP mode. Choose WiFi Settings > Wireless Repeating. Enable Wireless Repeating, and choose WISP. Click Select to select an existing WiFi network, which is Home_WiFi in this example.
  • Page 50 Step 3 Enter the Upstream WiFi Password, which is Tenda+245 in this example. Step 4 Click Save. Step 5 Click OK, and wait for the router to reboot.
  • Page 51 To access the internet, connect your computer to a LAN port of the new router (1, 2, IPTV/3 for AC21 and AC23; 1, 2, 3, IPTV/4 for AC19), or connect your smart phone to the WiFi network of the new router.
  • Page 52 WiFi network of your new router, or connect a computer to a LAN port of the router (1, 2, IPTV/3 for AC21 and AC23; 1, 2, 3, IPTV/4 for AC19). Do not connect any device to the WAN port of the new router.
  • Page 53 Click Start. Click Skip.
  • Page 54 Do not set login and WiFi password now by ticking Not Required, and click Next. Click Ignore. Step 2 Set the new router to Client+AP mode. Choose WiFi Settings > Wireless Repeating. Enable Wireless Repeating, and choose Client+AP. Click Select to select the existing WiFi network, which is Home_WiFi in this example.
  • Page 55 Step 3 Enter the Upstream WiFi Password, which is Tenda+245 in this example. Step 4 Click Save. Step 5 Click OK, and wait for the router to reboot. Step 6 Log in to the web UI of the router again, navigate to Internet Status to check if the wireless repeating succeeds.
  • Page 56 To access the internet, connect your computer to a LAN port of the new router (1, 2, IPTV/3 for AC21 and AC23; 1, 2, 3, IPTV/4 for AC19), or connect your smart phone to the WiFi network of the new router.
  • Page 57 If you cannot access the internet, try the following solutions: Ensure that the existing router is connected to the internet successfully. ⚫ Ensure that your wireless devices are connected to the correct WiFi network of the new router. ⚫ If the computer connected to the router cannot access the internet, ensure that the computer is ⚫...

  • Page 58: Channel & Bandwidth

    Channel & bandwidth In this section, you are allowed to change network mode, wireless channel, and wireless bandwidth of 2.4 GHz and 5 GHz WiFi networks. To access the configuration page, log in to the web UI of the router, and choose WiFi Settings > Channel &...
  • Page 59 Parameter Description IEEE 802.11b or IEEE 802.11g protocol, or work at 2.4 GHz with IEEE 802.11n protocol, therefore enjoying a maximum transmission rate of 300 Mbps. 5 GHz WiFi network supports 11ac, 11a/n/ac mixed modes. 11ac: It indicates that devices complaint with IEEE 802.11ac protocol can connect to the router, ⚫...

  • Page 60: Transmit Power

    Transmit power In this module, you can adjust the wall-penetration capability and wireless coverage of the router by setting the transmit power. To access the configuration page, log in to the web UI of the router, and choose WiFi Settings > Transmit Power.

  • Page 61: Wps

    5.6.1 Overview The WPS function enables wireless devices, such as smartphones, to connect to WiFi networks of the router quickly and easily. To access the configuration page, log in to the web UI of the router, and choose WiFi Settings > WPS.
  • Page 62 Choose WPS connection. ---End Wait a moment until the WPS negotiation is completed, and the phone is connected to the WiFi network.

  • Page 63: Connect Devices To The Wifi Network Through The Web Ui Of The Router

    5.6.3 Connect devices to the WiFi network through the web UI of the router Configuring procedure: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in to the web UI of the router. Step 2 Choose WiFi Settings >...
  • Page 64 ---End Wait a moment until the WPS negotiation is completed, and the phone is connected to the WiFi network.

  • Page 65: Connect Devices To The Wifi Network Using The Pin Code Of The Router

    5.6.4 Connect devices to the WiFi network using the PIN code of the router The router only supports WPS connection by entering the PIN code on wireless devices, which is usually used on WiFi network adapters. Please refer to the user guide of the WiFi network adapter for configuration details.

  • Page 66: Beamforming

    Beamforming+ Beamforming+ is a radio wave technology written into IEEE 802.11ac standard. Traditionally, the router broadcasts the data in all directions when broadcasting a WiFi signal. With beamforming, the router transmits radio signal in the direction of the client, thus creating a stronger, faster and more reliable wireless communication.
  • Page 67 The following figure shows the wireless transmission when Beamforming+ is disabled.

  • Page 68: Ap Mode

    Power on the router. Connect a computer to a LAN port (1, 2 and IPTV/3 for AC23 and AC21, and 1, 2, 3 and IPTV/4 for AC19) of the router (AC23 is used for illustration here), or connect your smart phone to the WiFi network of the router.
  • Page 69 Click Start. Click Skip.
  • Page 70 Do not set login and WiFi password now by ticking No Password, and click Next. Click Ignore. Step 3 Set the router to AP mode. Navigate to WiFi Settings > AP Mode. Enable AP Mode.
  • Page 71 Click Save. Step 4 Click OK, and wait for the router to reboot. Step 5 Connect the upstream device, such as a gateway, to any port of the router. ---End...
  • Page 72 Log in to the web UI of the router again, and navigate to Internet Status to check if the AP mode is configured successfully. If there is another network device with the same login domain name (tendawifi.com) with the router, log in to the upstream router and find the IP address obtained by the new router in the client list.
  • Page 73 If you cannot access the internet, try the following solutions: Ensure that the existing router is connected to the internet successfully. ⚫ Ensure that your wireless devices are connected to the correct WiFi network of the new router. ⚫ If the computer connected to the router cannot access the internet, ensure that the computer is ⚫...

  • Page 74: Anti-Interference

    Anti-interference The router supports anti-interference function. When you are experiencing unsatisfactory internet access, you can try to change the anti-interference settings to improve it. To access the configuration page, log in to the web UI of the router, and choose WiFi Settings > Anti-interference.

  • Page 75: Guest Network

    Guest network Overview In this module, you can enable/disable the guest network function and change the WiFi name and password of the guest network. A guest network can be set up with a shared bandwidth limit for visitors to access the internet, and isolated from the main network.
  • Page 76 Parameter Description Guest Network It specifies the password for the router’s two guest networks. Password It specifies the validity of the guest networks. The guest network function will be disabled Validity automatically out of the validity period. Shared It allows you to specify the maximum upload and download speed for all devices Bandwidth for connected to the guest networks.

  • Page 77: An Example Of Configuring The Guest Network

    Assume that the parameters you are going to set for the guest WiFi network: WiFi names for 2.4 GHz and 5 GHz networks: John_Doe and John_Doe_5G. − WiFi password for 2.4 GHz and 5 GHz networks: Tenda+245. − The shared bandwidth for guests: 2 Mbps.
  • Page 78 ---End During the 8 hours after the configuration, guests can connect their wireless devices, such as smartphones, to John_Doe or John_Doe_5G to access the internet and enjoy the shared bandwidth of 2 Mbps.

  • Page 79: Parental Control

    Parental control Overview On the parental control page, you can view the information of online devices and configure their internet access options. To access the configuration page, log in to the web UI of the router, and navigate to the Parental Control page.

  • Page 80: Configure The Parental Control Rule

    Configure the parental control rule Click or +New to edit or add a parental control rule. +New is used for illustration here. Parameter Description Device Name It specifies the name of the device that the parental control rule applies to. MAC Address It specifies the MAC address of the device that the parental control rule applies to.

  • Page 81: An Example Of Adding Parental Control Rules

    Parameter Description Blocked Websites It specifies the websites that the device is blocked from accessing or allowed to access during the specified period. Unblocked Websites An example of adding parental control rules Scenario: The final exam for your daughter is approaching and you want to configure her internet access through the router.
  • Page 82 Step 8 Set Blocked Websites, which is facebook,twitter,youtube,instagram. Step 9 Click Save. ---End After the configuration is completed, your daughter can access any websites except for facebook, twitter, youtube and instagram from 8:00 to 22:00 on weekends, and she cannot access the internet at all between 22:00 to 8:00.

  • Page 83: Vpn

    A VPN (Virtual Private Network) is a private network built on a public network (usually the Internet). This private network exists only logically and has no actual physical lines. VPN technology is widely used in corporate networks to share resources between corporate branches and headquarters, while ensuring that these resources are not exposed to other users on the internet.

  • Page 84: Enable Internet Users To Access Resources Of The Lan

    Parameter Description It is used to enable or disabled the PPTP server. PPTP Server When it is enabled, the router functions as a PPTP server, which can accept the connections from PPTP clients. It specifies the range of IP address range within which the PPTP server can assign to IP Address Pool PPTP clients.
  • Page 85 Configuring procedure: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in to the web UI of the router. Step 2 Choose VPN > PPTP Server. Step 3 Enable the PPTP Server. Step 4 Enable the MPPE Encryption, which means that the encryption digit remains the default value “128”.
  • Page 86 Step 2 Choose VPN on the left side, and click Add a VPN connection. Step 3 Configure the VPN parameters. Enter a connection name, such as VPN connection. Enter the server address, which is 113.88.112.220 in this example. Select a VPN type, which is Point to Point Tunneling Protocol (PPTP) in this example. Select a type of sign-in info, which is User name and password in this example.
  • Page 87 Step 4 Target the VPN connection added, and click Connect. Step 5 Click the icon on the desktop, and enter the address in the address bar to access the FTP server, which is ftp://192.168.0.136:21 in this example.
  • Page 88 Step 6 Enter the user name and password for logging in to the FTP server, which are both JohnDoe in this example, and click Log On. ---End By performing the steps above, you can access the resources on the FTP server.

  • Page 89: Online Pptp Users

    Online PPTP users When the PPTP server function is enabled, you can view the detailed information of VPN clients that establish connections with the PPTP server. To access the configuration page, log in to the web UI of the router, and choose VPN > Online PPTP Users.

  • Page 90: Pptp/L2Tp Client

    PPTP/L2TP client 8.3.1 Overview This series of router can function as a PPTP/L2TP client and connect to PPTP/L2TP servers. The PPTP/L2TP client function is disabled by default. When it is enabled, the page is show as below. Parameter description Parameter Description PPTP/L2TP Client It is used to enable or disable the PPTP/L2TP client function.

  • Page 91: Access Vpn Resources With The Router

    8.3.2 Access VPN resources with the router Scenario: You have subscribed the PPTP VPN service when purchasing the broadband service from your ISP. Goal: Access the VPN resources of your ISP. Solution: You can configure the PPTP/L2TP client function to reach the goal. Assume that: The IP address of the PPTP server is 113.88.112.220.

  • Page 92: Usb App

    The USB storage device connected can function as a FTP or Samba server for file sharing and be accessed with a computer or the Tenda WiFi App. You can also manage the resources on the USB storage device with a computer and through the Tenda WiFi App.
  • Page 93 Parameter description Parameter Description It specifies the encoding type for the text content on the FTP server. Unicode (utf-8): It is an encoding type for international use, which is ⚫ compatible for most languages in the world. It is recommended when there are more English texts.

  • Page 94: Access Usb Resources On A Computer Within The Lan

    Access USB resources on a computer within the If you have a USB storage device which stores resources to be shared, AC19 allows you to share the resources through the router to personal computer (PC) users within the LAN of the router. The following steps are performed on a Windows PC by visiting the FTP server.
  • Page 95 To access the USB resources: Step 1 Click the icon on the desktop of any computer connected to the router in a wireless or wired manner. Enter the ftp://192.168.0.1:21 in the address field and press Enter. Step 2 Enter the user name and password recorded, which are both admin in this example, and click Log On.

  • Page 96: Access Usb Resources On A Computer From The Internet

    Access USB resources on a computer from the internet If you want to access the resources in the USB storage device when you are out of the LAN of the router, or allow internet users to access the resources, AC19 also allows you to share the USB resources through the internet.
  • Page 97 Step 5 Record the address for internet access generated automatically according to the WAN IP address of the router, which is ftp://102.33.66.88:21 in this example, and any pair of user name and password. Please ensure that the WAN IP address of the router is a public IP address. Otherwise the access to the USB resources could fail.
  • Page 98 To access the USB resources: Step 1 Click the icon on the desktop of any computer with internet access. Enter the ftp://102.33.66.88:21 in the address field and press Enter. Step 2 Enter the user name and password recorded previously, which are both admin in this example, and click Log On.

  • Page 99: Access Usb Resources With The Tenda Wifi App

    Access USB resources with the Tenda WiFi App With Tenda WiFi App installed on your phone, you are enabled to access the resources on the USB storage device on the App within the LAN or through the internet. To access the page on the Tenda WiFi App, refer to...
  • Page 100 View and download files with the App ◼ Tap the desired files to view and perform further operations. Only files of the types supported by the smart phone can be opened and further operated, and the ⚫ supported file types differ with smart phones. The operation of files may require third party Apps on the phone.

  • Page 101: Ipv6

    IPv6 This router supports IPv4 and IPv6 dual stack protocols. In the IPv6 part, you can: Connect to the IPv6 network of ISPs − Configure the IPv6 tunnel and achieve communications between IPv6 islands − Change IPv6 LAN settings − 10.1 IPv6 WAN settings 10.1.1...
  • Page 102 Configuring procedure: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in to the web UI of the router. Step 2 Choose IPv6. Step 3 Enable the IPv6 function. Step 4 Set the connection type to DHCPv6.
  • Page 103 test-ipv6.com. The website will test your IPv6 connection status. When “You have IPv6” is shown on the page, it indicates that the configuration succeeds and you can access IPv6 services. If the IPv6 network test fails, try the following solutions: Navigate to the System Settings >...
  • Page 104 PPPoEv6 Overview If your ISP provides you with the PPPoE user name and password with IPv6 service, you can choose PPPoEv6 to access the internet. Log in to the web UI of the router, and navigate to the IPv6. When the connection type is set to PPPoEv6, the page is shown as below.
  • Page 105 Access the internet through PPPoEv6 If the PPPoE account provided by your ISP includes IPv6 service, you can choose PPPoEv6 to access the IPv6 service. The application scenario is shown as below. Configuring procedure: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in to the web UI of the router.
  • Page 106 IPv6 network test: Start a web browser on a phone or a computer that is connected to the router, and visit test-ipv6.com. The website will test your IPv6 connection status. When “You have IPv6” is shown on the page, it indicates that the configurations succeed and you can access IPv6 services.
  • Page 107 Static IPv6 Address Overview When your ISP provides you with information including IPv6 address, subnet mask, default gateway and DNS server, you can choose this connection type to access the internet with IPv6. Log in to the web UI of the router, and navigate to the IPv6. When the connection type is set to Static IPv6 Address, the page is shown as below.
  • Page 108 Step 7 Click Save. ---End IPv6 network test: Start a web browser on a phone or a computer that is connected to the router, and visit test-ipv6.com. The website will test your IPv6 connection status. When “You have IPv6” is shown on the page, it indicates that the configurations succeed and you can access IPv6 services.
  • Page 109 Ensure that devices connected to router obtain their IPv6 address through DHCPv6. − Consult your ISP for help. −...

  • Page 110: Ipv6 Tunnel

    10.1.2 IPv6 tunnel Overview IPv6 transition mechanism Before the IPv6 network is widely deployed, IPv6 stations are like isolated islands. Therefore, the dual stack and tunneling technologies are developed to achieve the communications between IPv6 islands. Dual stack technology ◼ With the dual stack technology, nodes within the network support both IPv4 and IPv6 protocol stack.
  • Page 111 Manual and automatic tunnels Generally, a tunnel consists of three parts: the tunnel start node, which encapsulates IPv6 packets; the tunnel end point, which decapsulates IPv6 packets; the tunnel, which is actually an IPv4 path, starts the encapsulated IPv6 packets from the tunnel The node is transported to the end of the tunnel.
  • Page 112 6to4 tunnel 6to4 is an automatic tunneling technology that enables communication between isolated IPv6 islands and between sites within the IPv6 backbone and IPv6 backbone networks without the network operator providing IPv6 interconnection services. The 6to4 tunnel technology is used to establish a tunnel between border routers at an IPv6 site. The border router at the source site is the start node of the tunnel, and the border router at the destination site is the end point of the tunnel.
  • Page 113 Configure IPv6 tunnel Devices at both ends of the tunnel must support the dual stack protocol. ⚫ The WAN IPv4 address of the routers must be a public IP address. ⚫ 6in4 tunnel Log in to the web UI of the router, and navigate to IPv6. Set the connection type to 6in4 Tunnel, enter required parameters and save the configurations.
  • Page 114 Parameter description Parameter Description It specifies the WAN IPv4 address of the dual stack router or 6rd BR at the peer side. Remote IPv4 Address It specifies the subnet mask of the IPv4 network. The IPv4 network at both sides Subnet Mask should be at the same network segment.
  • Page 115 Examples of IPv6 tunnel configuration 6in4 tunnel As shown below, the two routers support dual stack protocol. To achieve the communication between the two hosts, you can configure the 6in4 tunnel. Assume that the two routers are connected to IPv4 network and obtain public IPv4 addresses. IPv4 6in4 Router 1...
  • Page 116 Step 2 Configure the Router 2. Start a web browser on a device connected to the router 2 and visit tendawifi.com to log in to the web UI of the router. Choose IPv6. Enable the IPv6 function. Set the connection type to 6in4 Tunnel. Enter the WAN IPv4 address of the device at the peer side, which is 1.1.1.1 in this example.
  • Page 117 ---End Verification To verify whether the 6in4 tunnel is established successfully, you can ping each other on the two computers. Now, ping computer 2 (IPv6 address: 2001:2::1036:66d1:a340:aac6) on computer 1. Step 1 Use Windows + R shortcut to open the Run dialog window. Step 2 Enter cmd, and click OK.
  • Page 118 Step 3 Enter the ping command, which is ping 2001:2::1036:66d1:a340:aac6 in the example, and press Enter. ---End Wait a moment. The 6in4 tunnel configuration succeeds when the result is shown as below.
  • Page 119 6to4 tunnel As shown below, the two routers support dual stack protocol. To achieve the communication between the two hosts, you can configure the 6to4 tunnel. Assume that the two routers are connected to IPv4 network and obtain public IPv4 addresses. IPv4 6to4 Router 1...
  • Page 120 Verification To verify whether the 6to4 tunnel is established successfully, you can ping each other on the two computers. Now, ping computer 2 (IPv6 address: 2002:101:201:1:1036:66d1:a340:aac6) on computer 1. Step 1 Use Windows + R shortcut to open the Run dialog window. Step 2 Enter cmd, and click OK.
  • Page 121 Wait a moment. The 6to4 tunnel configuration succeeds when the result is shown as below. 6rd tunnel As shown below, the two routers support dual stack protocol. To achieve the communication between the two hosts, you can configure the 6rd tunnel. Assume that the two routers are connected to IPv4 network and obtain public IPv4 addresses.
  • Page 122 Choose IPv6. Enable the IPv6 function. Set the connection type to 6rd Tunnel. Enter the WAN IPv4 address of the device at the peer side in Remote IPv4 Address, which is 1.1.2.1 in this example. Enter the Subnet Mask of the IPv4 network. 240.0.0.0 is recommended. Customize the IPv6 Prefix (the default is recommended).
  • Page 123 ---End Verification To verify whether the 6rd tunnel is established successfully, you can ping each other on the two computers. Now, ping computer 2 (IPv6 address: 2001:db8:c84c:1:1036:66d1:a340:aac6) on computer 1. Step 1 Use Windows + R shortcut to open the Run dialog window. Step 2 Enter cmd, and click OK.
  • Page 124 ---End Wait a moment. The 6rd tunnel configuration succeeds when the result is shown as below.

  • Page 125: Ipv6 Lan Settings

    10.2 IPv6 LAN settings To access the page, log in to the web UI of the router and choose IPv6. You can change the IPv6 LAN settings here. Parameter description Parameter Description It specifies two types of IPv6 LAN address assignment. Auto: The router generates the IPv6 address according to its LAN IP address.
  • Page 126 Parameter Description The configuration is required when the DHCPv6 address assignment method is set to Start ID stateful. It specifies the range of the last segment of the IPv6 address that the DHCPv6 server End ID assigns to the devices. Range: 1-ffff. It specifies the LAN IPv6 DNS configuration method.

  • Page 127: Advanced Settings

    Advanced settings 11.1 Bandwidth control 11.1.1 Overview By configuring this function, you can limit the upload and download speed of devices connected to the router and allocate the bandwidth reasonably. To access the configuration page, log in to the web UI of the router and choose Advanced Settings >...
  • Page 128 Step 2 Choose Advanced Settings > Bandwidth Control. Step 3 Target the devices to be controlled, and set the Download Limit to 4.0 Mbps (For HD Video). Step 4 Click Save. ---End After the configuration, the highest speed for the device is 4 Mbps (or 512 KB/s) and satisfies the requirement of 720p videos.

  • Page 129: Iptv

    11.2 IPTV 11.2.1 Overview IPTV is the technology integrating internet, multimedia, telecommunication and many other technologies, providing interactive services, including digital TV, to family users by internet broadband lines. You can set the multicast and STB functions here. Multicast: If you want to watch multicast videos from the WAN side of the router on −...

  • Page 130: Watch Iptv Programs Through The Router

    ISP, but no VLAN information. Goal: Be able to watch IPTV programs through the router. Solution: You can configure the IPTV function to reach the goal (AC23 is used for illustration here). Configuring procedure: Step 1 Set you router.

  • Page 131: Watch Multicast Videos Through The Router

    Click Save. Step 2 Configure the set top box. Use the IPTV user name and password to dial up on the set top box. ---End When completing the configurations, you can watch IPTV programs on your TV. 11.2.3 Watch multicast videos through the router Scenario: You have the address of multicast videos.
  • Page 132 ---End When completing the configurations, you can watch multicast videos on your computer.

  • Page 133: Tenda Wifi App

    Go to the App store and search for the Tenda WiFi App. Download and install it on your phone. If you already have a Tenda WiFi App account or want to use the fast login approach, skip to Step 3 proceed with the settings.
  • Page 134 Tap Register at the top right corner, and register with an Email account. Check the Email sent to your Email account and follow the instruction to finish the Email account confirmation process.
  • Page 135 Step 3 Log in with the confirmed account. Follow the instructions on the home page of the Tenda WiFi App to add the router. You can also choose to log in with your google, facebook and twitter account without registering a Tenda WiFi App account.
  • Page 136 Enable Manage with Tenda WiFi App. Enter an account registered in the Tenda WiFi App in Cloud Account. Click Save. ---End When completing the configurations, you can manage your router with Tenda WiFi App on your phone anywhere and anytime through the internet.

  • Page 137: Sleeping Mode

    Sleeping Mode When the router is under sleeping mode and you want to use the WiFi network, use the Tenda WiFi App to wake up the router. Sleeping Time It specifies the period during which the router is under the sleeping mode.

  • Page 138: Led Control

    11.5 LED control With the LED control function, you can control the status of the LED indicators. To access the configuration page, log in to the web UI of the router, and choose Advanced Settings > LED Control. Parameter description Parameter Description Always on...

  • Page 139: Filter Mac Address

    11.6 Filter MAC address 11.6.1 Overview This function enables you to add devices to the whitelist or blacklist to enable or disable specified users to access the internet through the router. To access the configuration page, log in to the web UI of the router, and choose Advanced Settings >...
  • Page 140 Assume that: Device MAC address Status Your own phone 8C:EC:4B:B3:04:92 Connected Wife’s phone 94:C6:91:29:C2:12 Disconnected Daughter’s phone 98:9C:57:19:D0:1B Disconnected Configuring procedure: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in to the web UI of the router.
  • Page 141 ---End When configuration is completed, only the three devices added are able to access the internet through the router.

  • Page 142: Firewall

    11.7 Firewall The firewall function helps the router detect and defend ICMP flood attack, TCP flood attack and UDP flood attack, and ignore Ping packet from WAN port. It is recommended to keep the default settings. To access the configuration page, log in to the web UI of the router, and choose Advanced Settings >...

  • Page 143: Static Route

    11.8 Static route 11.8.1 Overview Routing is the act of choosing an optimal path to transfer data from a source address to a destination address. A static route is a special route that is manually configured and has the advantages of simplicity, efficiency, and reliability. Proper static routing can reduce routing problems and overload of routing data flow, and improve the forwarding speed of data packets.

  • Page 144: Add A Static Route Rule

    11.8.2 Add a static route rule Scenario: You have an AC23 and another two routers. Router1 is connected to the internet and its DHCP server is enabled. Router2 is connected to an intranet and its DHCP server is disabled. Goal: You are able to access both the internet and intranet at the same time.
  • Page 145 Enter the subnet mask of the destination network, which is 255.255.255.0 in this example. Enter the ingress IP address of the next hop route, which is 192.168.10.20 in this example. Click +New. ---End When completing the configurations, you can access both the internet and intranet through AC23 at the same time.

  • Page 146: Ddns

    11.9 DDNS 11.9.1 Overview DDNS normally interworks with virtual server, DMZ host and remote management, so that the internet users can be free from the influence of dynamic WAN IP address and access the internal server or the router’s web UI with a fixed domain name. To access the configuration page, log in to the web UI of the router, and choose Advanced Settings >...

  • Page 147: Enable Internet Users To Access Lan Resources Using A Domain Name

    11.9.2 Enable internet users to access LAN resources using a domain name Scenario: You have set up a FTP server within your LAN. Goal: Open the FTP server to internet users and enable family members who are not at home to access the resources of the FTP server from the internet with a domain name.
  • Page 148 Configuration procedure: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in to the web UI of the router. Step 2 Configure the DDNS function. Choose Advanced Settings > DDNS. Enabled the DDNS function. Choose a service provider, which is oray.com in this example.
  • Page 149 Enter the user name and password to access the resources on the FTP sever. After the configurations, if internet users still cannot access the FTP server, try the following methods: Ensure that the LAN port number configured in the virtual server function is the same as the ⚫...

  • Page 150: Virtual Server

    11.10 Virtual server 11.10.1 Overview By default, internet users cannot actively access the LAN of the router. The virtual server function opens a port of the router, and binds the LAN server to the port using the server’s IP address and intranet service port. All access requests to the WAN port of the router will be directed to the server.
  • Page 151 access the resources of the FTP server from the internet. Solution: You can configure the virtual server function to reach the goal. Assume that the information of the FTP server includes: IP address: 192.168.0.136 − MAC address: D4:61:DA:1B:CD:89 − Service port: 21 −...
  • Page 152 Choose a protocol, which is TCP&UDP in this example. Click +New. Step 3 Assign a fixed IP address to the host where the server locates. Choose System Settings > DHCP Reservation. Specifies a Device Name for the host of the server, which is FTP server in this example. Enter the MAC Address of the host of the server, which is D4:61:DA:1B:CD:89 in this example.
  • Page 153 Enter the user name and password to access the resources on the FTP server. If you want to access the server within a LAN using a domain name, refer to the solution DDNS + Virtual server. After the configurations, if internet users still cannot access the FTP server, try the following methods: Ensure that the LAN port number configured in the virtual server function is the same as the ⚫...

  • Page 154: Dmz Host

    11.11 DMZ host 11.11.1 Overview A DMZ host on a LAN is free from restrictions in communicating with the internet. It is useful for getting better and smoother experience in video conferences and online games. You can also set the host of a server within the LAN as a DMZ host when in need of accessing the server from the internet.
  • Page 155 Assume that the information of the FTP server includes: IP address: 192.168.0.136 − MAC address: D4:61:DA:1B:CD:89 − Service port: 21 − The WAN IP address of the router: 102.33.66.88. − Please ensure that router obtains an IP address from the public network. This function may not work on a host with an IP address of a private network or an intranet IP address assigned by ISPs that start with 100.
  • Page 156 Step 3 Assign a fixed IP address to the host where the server locates. Choose System Settings > DHCP Reservation. Specifies a Device Name for the server host, which is FTP server in this example. Enter the MAC Address of the host of the server, which is D4:61:DA:1B:CD:89 in this example.
  • Page 157 Enter the user name and password to access the resources on the FTP server. If you want to access the server within a LAN using a domain name, refer to the solution DDNS. After the configurations, if internet users still cannot access the FTP server, try the following methods: Ensure that the LAN port number configured in the virtual server function is the same as the ⚫...

  • Page 158: Upnp

    11.12 UPnP UPnP is short for Universal Plug and Play. This function enables the router open port automatically for UPnP-based programs. It is generally used for P2P programs, such as BitComet and AnyChat, and helps increase the download speed. To access the configuration page, log in to the web UI of the router, and choose Advanced Settings >...

  • Page 159: System Settings

    System settings 12.1 LAN settings To access the configuration page, log in to the web UI of the router, and choose System Settings > LAN Settings. On this page, you can: Change the LAN IP address and subnet mask of the router. ◼...
  • Page 160 Parameter Description IP Address It specifies the range of IP addresses that can be assigned to devices connected Range to the router. The default range is 192.168.0.100 to 192.168.0.200. It specifies the valid duration of the IP address that is assigned to a client. DHCP When the lease time reaches half, the client will send a DHCP Request to the Server...

  • Page 161: Dhcp Reservation

    12.2 DHCP reservation 12.2.1 Overview Through the DHCP reservation function, specified clients can always obtain the same IP address when connecting to the router, ensuring that the router's "Virtual server", "DDNS", "DMZ host" and other functions can function normally. This function takes effect only when the DHCP server function of the router is enabled.
  • Page 162 Configuring procedure: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in to the web UI of the router. Step 2 Choose System Settings > DHCP Reservation. Step 3 (Optional) Enter the device name for the host. Step 4 Enter the MAC address of the host, which is D4:61:DA:1B:CD:89 in this example.

  • Page 163: Wan Settings

    12.3 WAN settings In the WAN Parameters module, you can check and modify MTU value, WAN speed, duplex mode, MAC address, service name and server name. 12.3.1 Change MTU value MTU (Maximum Transmission Unit) is the largest data packet transmitted by a network device. When the connection type is PPPoE, the default MTU value is 1480.

  • Page 164: Change The Wan Speed And Duplex Mode

    Application 1468 It is used for DHCP connections. 1436 It is used for VPN or PPTP connections. 12.3.2 Change the WAN speed and duplex mode To access the configuration page, log in to the web UI of the router, and choose System Settings > WAN Settings.

  • Page 165: Change The Mac Address Of The Wan Port

    12.3.3 Change the MAC address of the WAN port If you still cannot access the internet after completing Internet Settings, it could be the result of the ISP’s configuration to bind the internet account information with a fixed MAC address. In this case, you can clone and change the MAC address of the router to solve the problem.

  • Page 166: Change The Service Name And Server Name

    12.3.4 Change the service name and server name To access the configuration page, log in to the web UI of the router, and choose System Settings > WAN Settings. Only when the connection type is PPPoE, you may need to change the service name and server name of the broadband service.

  • Page 167: Time Settings

    12.4 Time settings To access the configuration page, log in to the web UI of the router, and choose System Settings > Time Settings. You can change the time settings on this page. The functioning of functions based on time requires an accurate system time.

  • Page 168: Login Password

    12.5 Login password To ensure network security, a login password is recommended. A login password consisting of more types of characters, such as uppercase letters and lowercase letters, brings higher security. To access the login password configuration page, log in to the web UI and choose System Settings >...

  • Page 169: Reboot And Reset

    12.6 Reboot and reset 12.6.1 Reboot the router If any parameter fails to take effect or the router does not work properly, you can try rebooting the router. Rebooting the router will disconnect all connections to the router. Reboot the router during leisure times.
  • Page 170 Reset the router on the web UI Start a web browser and log in to the web UI of the router. Choose System Settings > Reboot and Reset, and click Reset. Wait for a moment until the ongoing process finishes.

  • Page 171: Upgrade Firmware

    12.7 Upgrade firmware This function enables the router to obtain the latest functions and more stable performance. The router supports online firmware upgrade and local firmware upgrade. 12.7.1 Online upgrade When the router is connected to the internet, it auto-detects whether there is a new firmware and displays the detected information on the page.

  • Page 172: Local Upgrade

    UI of the router. Step 3 Choose System Settings > Firmware Upgrade Step 4 Choose Local Upgrade. Step 5 Click Choose File. Step 6 Target the firmware file downloaded previously (extension: bin), and click Open (AC23 is used for illustration here).
  • Page 173 Step 7 Click Upgrade. ---End Wait for a moment until the ongoing process finishes. Log in to the web UI of the router again. Choose System Settings > System Status and check whether the upgrade is successful based on the Firmware Version For better performance of the new firmware, you are recommended to reset the router to factory default settings and re-configure the router when the upgrading is completed.

  • Page 174: Backup/Restore

    12.8 Backup/Restore In this module, you can back up the current configurations of the router to your computer. You are recommended to back up the configuration after the settings of the router are significantly changed, or the router works in a good condition. After you restore the router to factory settings or upgrade it, you can use this function to restore the configurations that have been backed up.

  • Page 175: Restore Previous Configurations Of The Router

    Step 4 Click OK in the pop-up window. ---End After the file is downloaded, you can name it RouterCfm.cfg. 12.8.2 Restore previous configurations of the router To restore the previous configurations of the router: Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in to the web UI of the router.
  • Page 176 Step 4 Choose the configuration file to be restored (extension: cfg), and click Open. ---End Wait for a moment until the ongoing process finishes, and the router restores previous settings.

  • Page 177: Remote Management

    12.9 Remote management 12.9.1 Overview Generally, the web UI of the router can only be accessed on devices that are connected to the router by a LAN port or wireless connection. When you encounter a network fault, you can ask for remote technical assistance, which improves efficiency and reduces costs and efforts.

  • Page 178: Enable Tenda Techical Support To Acces And Manage The Web Ui

    Scenario: You encounter a problem in configuring the router, and the router can access internet access. Goal: Ask the Tenda technical support to help you configure the router remotely. Solution: You can configure the remote management function to reach the goal.
  • Page 179 Step 5 Click Save. ---End When completing the configurations, the Tenda technical support can access and manage the web UI of the router by visiting “http://202.105.106.55:8888” on the computer.

  • Page 180: System Status

    12.10 System status On this page, you can find the basic information of the router, WAN status, LAN status, WiFi status and IPv6 status. To access the configuration page, log in to the web UI of the router, and choose System Settings > System Status.

  • Page 181: Wan Status

    12.10.2 WAN status In this part, you can view the information of the WAN port, including connection type, connection status and connection duration, etc. Parameter description Parameter Description Connection Type It specifies the internet IPv4 connection type of the WAN port. Connection Status It specifies internet connection status of the WAN port.

  • Page 182: Wifi Status

    Parameter description Parameter Description It specifies the LAN IP address of the router, and also the IP address for logging in to IP Address the web UI of the router, Subnet Mask It specifies the LAN subnet mask of the router. MAC Address It specifies the LAN MAC address of the router.

  • Page 183: Ipv6 Status

    Parameter description Parameter Description 2.4 GHz Network It specifies whether the corresponding WiFi network is enabled or disabled, and the visibility of the WiFi network. 5 GHz Network Hotspot Name It specifies the WiFi name of the respective WiFi network. Encryption Mode It specifies the encryption mode of the respective WiFi network.
  • Page 184 Parameter Description Secondary IPv6 DNS It specifies the LAN IPv6 address of the router. IPv6 LAN Address After the IPv6 function is configured, the LAN port of the router obtains a global unicast IPv6 address or a tunnel address, and a link local address.

  • Page 185: System Log

    12.11 System log To access the configuration page, log in to the web UI of the router, and choose System Settings > System Log. This function logs all key events that occur after the router is started. If you encounter a network fault, you can turn to system logs for fault rectification.

  • Page 186: Automatic Maintenance

    12.12 Automatic Maintenance Automatic maintenance enables you to make the router restart regularly. It helps improve the stability and service life of the router. To access the configuration page, log in to the web UI of the router, and choose System Settings > Automatic Maintenance.

  • Page 187: Appendix

    Appendix Configuring the computer to obtain an IPv4 address automatically Perform the configuration procedures corresponding to Windows Windows 8 Windows 7 as required. A computer installed with a wired network adapter is used as an example to describe the procedures. The procedures for configuring computers installed with a WiFi network adapter are similar.
  • Page 188 Step 3 Right click on the connection which is being connected, and then click Properties. Step 4 Double-click Internet Protocol Version 4 (TCP/IPv4).
  • Page 189 Step 5 Select Obtain an IP address automatically and Obtain DNS server address automatically, and click OK. Step 6 Click Close in the Ethernet Properties window. ---End...

  • Page 190: Windows 8

    A.1.2 Windows 8 Step 1 Right-click in the bottom right corner of the desktop and choose Open Network and Sharing Center. Step 2 Click Ethernet and then Properties. Step 3 Double-click Internet Protocol Version 4 (TCP/IPv4).
  • Page 191 Step 4 Select Obtain an IP address automatically and Obtain DNS server address automatically, and click OK. Step 5 Click OK in the Ethernet Properties window. ---End...

  • Page 192: Windows 7

    A.1.3 Windows 7 Step 1 Click in the bottom right corner of the desktop and choose Open Network and Sharing Center. Step 2 Click Local Area Connection and then Properties.
  • Page 193 Step 3 Double-click Internet Protocol Version 4 (TCP/IPv4). Step 4 Select Obtain an IP address automatically and Obtain DNS server address automatically, and click OK. Step 5 Click OK in the Local Area Connection Properties window. ---End...

  • Page 194: Default Parameters

    Default parameters Parameter AC23/AC21/AC19 IP address 192.168.0.1 Login Password None IP Address 192.168.0.1 Parameters Subnet Mask 255.255.255.0 DHCP Server Enabled Start IP Address 192.168.0.100 DHCP Server End IP Address 192.168.0.200 Preferred DNS Server 192.168.0.1 Operating Mode Router mode WiFi Name...

  • Page 195: Acronyms And Abbreviations

    Acronyms and Abbreviations Acronym or Abbreviation Full Spelling Advanced Encryption Standard Access Point Border Relay Customer Edge DDNS Dynamic Domain Name System DHCP Dynamic Host Configuration Protocol DHCPv6 Dynamic Host Configuration Protocol for IPv6 Demilitarized Zone Domain Name System Greenwich Mean Time Internet Protocol IPTV Internet Protocol Television...
  • Page 196 Acronym or Abbreviation Full Spelling WPA-PSK WPA-Preshared Key...

This manual is also suitable for:

Ac21Ac19

Table of Contents
