- Page 1 SETUP INSTRUCTIONS 2012 990 Super Duke FR 990 Super Duke R EU 990 Super Duke R FR 990 Super Duke R AUS/UK Art. no. 3211887en...
- Page 3 KTM accepts no liability for delivery options, deviations from illustrations and descriptions, as well as misprints and other errors.
-
Page 4: Means Of Representation
MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips. - Page 5 SETUP Unpacking and setting up the vehicle – Remove the carton. – Remove the adhesive tape in the upper area of the motorcycle. 101252-10 – Roll down the film at the sides. Info To avoid damaging the motorcycle during unpacking, leave the other films on the vehicle until you have finished work on the vehicle.
- Page 6 SETUP – Position the hand brake cylinder. Tighten the screws. Guideline Remaining chassis screws 10 Nm (7.4 lbf ft) – Position the throttle grip. Tighten the screws. Guideline Remaining chassis screws 5 Nm (3.7 lbf ft) – Mount and tighten the right handlebar weight. Guideline Remaining chassis screws 10 Nm (7.4 lbf ft)
- Page 7 Install the front spoiler. ( p. 9) – Refuel. ( p. 10) – Print out the current PDI form found on KTM DEALER.NET and perform the delivery inspection. – Set kilometers or miles. ( p. 11) – Set the clock. (...
- Page 8 WORK Removing the seat – Insert the ignition key in the seat lock and turn it clockwise. – Raise the rear of the seat, push it towards the rear, and remove it upwards. B00165-10 Mounting the seat – Hook the tabs of the seat onto the fuel tank, lower the rear and push forward.
-
Page 9: Installing The Battery
– Do not discard batteries with the household trash. Dispose of a defective battery in an environmentally compatible manner. Give the battery to your KTM dealer or to a recycling center that accepts used batteries. Warning Environmental hazard Hazardous substances cause environmental damage. - Page 10 WORK Info Even when there is no load on the battery, it discharges steadily. The charge state and the type of charge are very important for the service life of the battery. Rapid recharging with a high charging current shortens the battery's service life. If the charging current, charging voltage and charging time are exceeded, electrolyte escapes through the safety valves.
- Page 11 WORK Installing the front spoiler – Position the front spoiler. 0 0 0 1 – Mount and tighten screws with the washer. Guideline Screw, front spoiler 10 Nm Loctite ® 243™ (7.4 lbf ft) – Fully tighten screws B00245-10 Opening the filler cap Danger Fire hazard Fuel is highly flammable.
- Page 12 WORK Closing the filler cap Warning Fire hazard Fuel is highly flammable, poisonous and harmful to your health. – When closing the filler cap, ensure that it is closed correctly. Change clothing that came into contact with fuel. Immediately clean skin that came into contact with fuel using soap and water.
-
Page 13: Setting The Clock
WORK – Press the SET button for two seconds. The low fuel warning lamp goes out. TRIP F is set to 0.0 and the display returns to the previous display mode. Info If the SET button is not pressed, the value is automatically reset after approx. -
Page 14: Technical Data - Tightening Torques For Chassis
TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS ® Screw, side stand switch 2 Nm (1.5 lbf ft) Loctite 243™ – Remaining chassis screws 5 Nm (3.7 lbf ft) – Screw, chain sliding guard 5 Nm (3.7 lbf ft) – Screw, fuel level indicator 3 Nm (2.2 lbf ft) –... - Page 15 TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS – Screw connection, engine mounting 45 Nm (33.2 lbf ft) bracket – Screw, fuel tank holder 15 Nm (11.1 lbf ft) – Screw, handlebar support (Super Duke) M10 20 Nm (14.8 lbf ft) –...
- Page 16 SUBSTANCES Super unleaded (ROZ 95/RON 95/PON 91) According to – DIN EN 228 (ROZ 95/RON 95/PON 91) Guideline – Only use unleaded super fuel that matches or is equivalent to the specified fuel grade. – Fuel with an ethanol content of up to 10 % (E10 fuel) is safe to use. Info Do not use fuel containing methanol (e.
- Page 17 *3211887en* 3211887en 07/2012 KTM-Sportmotorcycle AG 5230 Mattighofen/Austria Photo: Mitterbauer/KTM http://www.ktm.com...
