The green LED indicates if the 10 or 100Mbps STP/UTP has
been link or not. When the LED radiate, it indicates the adapter
connect to the network at 10/100Mbps speed. Otherwise, it
indicates connection is not available. When the LED glitter, it
means the STP/UTP port is receiving or transmitting data.
Chapter 2 Installation Guide
2.1 Hardware Installation
To install the adapter, follow these steps listed below:
1. Turn off your computer and unplug the power cord and all
cables.
2. Remove your computer's case cover. See your computer's
user guide for information about removing the cover.
3. Locate an available PCI slot. PCI slot are usually white.
4. Remove the screw that secures the backplate (the small
piece of metal that covers the opening for PCI card on the
back panel of your computer), then remove the backplate.
5. Carefully insert the adapter into the PCI slot. Do not touch
the metal connector on the adapter.
6. Secure the adapter to the case using the screw you
removed from the backplate.
7. Reinstall your computer's case cover.
8. Plug in the power cord and other cables, and then turn on
your computer.
2.2 Driver Installation
Use the drivers supplied by the diskette included in the product.
For detail description, please refer to "readme.txt" according to
the corresponding
OS.
2
