Teile und Zubehör - Einbauanleitung
F 39 0060 M
BMW Parts and Accessories – Installation Instruction
BMW GSM network mobile phone for the BMW 5 Series (E 39/2) touring
(cars without SA 640 telephone preparation)
Best.-Nr. 01 29 9 416 691 XI/98 Printed in Germany

Advertisement

Table of Contents
loading

Related Manuals for BMW SA640

Summary of Contents for BMW SA640

  • Page 1 F 39 0060 M BMW Parts and Accessories – Installation Instruction BMW GSM network mobile phone for the BMW 5 Series (E 39/2) touring (cars without SA 640 telephone preparation) Best.-Nr. 01 29 9 416 691 XI/98 Printed in Germany...
  • Page 2 Contents Page Important information ....... . Installation ........Installation instructions .

  • Page 3: Important Information

    These installation instructions are only for cars without SA 640 (telephone preparation). Target group The target group for these installation instructions is staff who have been trained on BMW cars. Work All servicing, repair, installation and adjustment work on cars is completed at your own risk.
  • Page 4 10 A fuse The parts marked * may have to be ordered separately depending on the equipment in the car. Parts are not included in the installation kit and must be ordered separately for cars without a BMW Professional DSP hi-fi system.
  • Page 6 F 39 84 156 M 1-17...

  • Page 7: Installation

    Installation Notes Refer to the safety instructions in section 1. The installation work is based on the general workshop information. Any work which differs from this is described in detail in sections 2 and 3. Preparatory work ........... See section 3. 1 Fold out folded page 17 .
  • Page 8 15 MID (26) ..............Replace the MID or IRIS with an MID with a telephone key. On cars without an on-board monitor radio and with a "C32 Reverse RDS" radio, the radio must be replaced and the additional wiring harness for the MID retrofit installed.The corresponding MID with a telephone key must be ordered separately.
  • Page 9 F 39 84 157 M F 39 0114 M F 39 84 166 M F 39 84 165 M F 39 84 164 M...
  • Page 10 F 39 0115 M F 39 84 159 M F 39 84 160 M F 39 84 161 M F 39 84 163 M F 39 84 162 M F 39 0118 M 2-17...

  • Page 11: Table Of Contents

    Installation instructions Contents Page 3. 1 Preparatory work ........................Connection overview of connection cable/power supply wiring harness ......... Connection overview of microphone wiring harness/speaker wiring harness ......3-22 Connection overview of switch module ................... 3-32 To lay and connect additional wiring harnesses ..............3-44 3.5.

  • Page 12: Preparatory Work

    Remove the grab handles on the driver's side. Remove the A pillar trim on the driver's side (cars without a BMW Professional DSP hi-fi system only). Remove the bottom instrument trim on the driver's side (cars without a BMW Professional DSP hi-fi system only).
  • Page 13 3.2 Connection overview of connection cable/microphone wiring harness/speaker wiring harness Fold out folded page 19. Item Description Signal Cable colour Connection location in the car Cross-section – – Connection cable 3-pin socket casing X2759 – – Branch III/1 from microphone III in the boot, left-hand side 54-pin socket casing X4038 –...
  • Page 14 II/1 II/3 II/2 II/4 II/5 II/6 F 39 84 168 M 3-19...

  • Page 15: Connection Overview Of Microphone Wiring Harness/Speaker Wiring Harness

    III/1 3-pin socket casing – – Microphone B400 at interior light, front III/2 Cars without a BMW Professional DSP hi-fi system Speaker wiring harness and without prepared speaker cabling only Socket contact TELNF+ black/white White 12-pin socket casing X322 in the boot, IV/1 (0.75 mm...
  • Page 16 III/1 III/2 IV/1 IV/4 IV/5 IV/2 IV/3 IV/6 F 39 0116 M 3-29...

  • Page 17: Connection Overview Of Switch Module

    Description Signal Cable colour Connection location in car Cross-section Switch module Cars without a BMW Professional DSP hi-fi system only Socket contact Terminal 30 red/white Cars without on-board monitor radio: (1.5 mm - Radio connection plug X18126, slot No. 9 Cars with on-board monitor radio: - Enclosed 2-pin socket casing (28), slot No.
  • Page 18 VI/2 VI/1 VI/3 VI/4 F 39 84 192 M 3-39...

  • Page 19: To Lay And Connect Additional Wiring Harnesses

    The installation of the speaker wiring harness IV and the switch module V is not necessary on cars with a BMW Professional DSP hi-fi system.The installation of the power supply wiring harness II is not necessary on cars with a 12-pin white telephone SA plug X400. On cars with an existing speaker wiring harness on the socket casing of plug connector X322, there is no need to install the speaker wiring harness IV.

  • Page 20: Plug Connector Holder

    A (Speaker wiring harness IV) Cars without a BMW Professional DSP hi-fi system and without prepared speaker cabling only Remove the door plug (30) at the front left or at the front right on RHD versions, and disconnect the plug connector.
  • Page 21 D (Switch module V, cars without a BMW Professional DSP hi-fi system only): Cars without on-board monitor radio Lay branches V/1 and V/2, cable colour red/white and white/brown, to the installation site for the radio. Lay branches V/4 and V/5 to the door plug in the A pillar.
  • Page 22 F 39 84 157 M F 39 0114 M F 39 84 166 M F 39 84 165 M F 39 84 164 M...
  • Page 23 F 39 0115 M F 39 84 159 M F 39 84 160 M F 39 84 161 M F 39 84 163 M F 39 84 162 M F 39 0118 M 3-65...

  • Page 24: To Install And Connect The Microphone

    3.6 To install and connect the microphone Fold out folded page 75. Cars with sunroof The sunroof motor cover (15) must be ordered separately to match the trim colour (see ETK / MF for part number). Remove the cover of the sunroof motor. Press the microphone cover (11) and microphone (12) into the sunroof motor cover (15) (see directional arrow on the microphone - the arrow must point to the front of the car).
  • Page 25 III/2 F 39 84 182 M F 39 84 183 M III/2 F 39 84 184 M F 39 84 185 M F 39 84 186 M 3-75...

  • Page 26: To Install And Connect The Eject Box

    3.7 To install and connect the eject box Fold out folded page 85. The telephone centre armrest (49) must be ordered separately to match the trim colour (see ETK / MF for part number). Lay the connection cables (50 and 51) for the eject box through the recess (52) in the slide unit (48) and slide the slide unit forwards as shown.
  • Page 27 51 I/7 F 39 84 187 M F 39 84 188 M F 39 84 189 M F 39 84 190 M 3-85...

  • Page 28: Coding, Concluding Work

    3.8 Coding, concluding work This system is coding relevant. To ensure that the retrofit system: is fully functional does not suffer malfunctions and faults in conjunction with the other electrical systems in the vehicle, this system and, if necessary, other vehicle control units must be coded. In addition it is stored in the central code of the IKE.

  • Page 29: To Adjust The Multi-Information Display (Mid)

    3.9 To adjust the multi-information display (MID) (Cars with multi-functional steering wheel and low-combination instrument only) Fold out folded page 103. On cars with a multi-functional steering wheel and low-combination instrument (no display on the combination instrument), after installing the mobile telephone system and the telephone key on the multi-functional steering wheel and replacing the multi-information display (MID), the telephone display can be activated on the MID.
  • Page 30 AUDIO K U R Z W A H L N UMM E R N A M E N O T I Z N O T R U F AUDIO P E G E L G E B Ü H R D A U E R AUDIO HW :...

  • Page 31: Circuit Diagram

    X10018 Fuse strip IV, A49, in the boot, right-hand side Coding loop (cable colour blue): for cars with a BMW Professional DSP hi-fi system and navigation system Coding loop (cable colour white): for cars with a navigation system 3-pin plug casing for navigation system (special accessory) To radio or hi-fi system The plug connector is to be cut and connected to the telephone wiring harness.
