Wolf CSO Series Manual

Convection steam oven controls
Hide thumbs

Advertisement

Quick Links

Download this manual
General Controls
GENERAL CONTROLS
FIRST-TIME USE
Selecting a cooking mode the first time causes the unit to
prompt the user to the set the language and clock. See also:
Set the language
1
2
Set the clock
CONTROL PANEL
The CSO controls operate by touch. The control panel has
icons on it that allow movement through the menu options and
selection.
CONTROL PANEL ICONS
Symbol
Action
Cooking modes under Quick Start.
Programmed recipes.
Move left on the menu.
Select the underlined option.
Move right on the menu.
Other recipes and cooking modes.
Customer-saved recipes.
Turn the light on or off.
User functions.
Program, turn on, and turn off the timer.
Open and close the water tank door.
Turn the unit on and off.
03/2019
Convection Steam Oven Controls
1
service.subzero.com
