Instructions - Parts List
GTP10 Pump
For pumping gasoline, diesel fuel, and kerosene. Do not use to pump other fluids including
water.
Models 260000 through 260017, 260019, 260024, 260580, and 260581
10 gpm (38 lpm), 12 VDC (CSA C/US listed motor)
Models 260020 and 260021, 10 gpm (38 lpm), 24 VDC
Models 260022 and 260023, 12 gpm (45 lpm), 230 VAC
Models 260025 through 260028
12 gpm (45 lpm), 115 VAC (CSA C/US listed motor)
10 psi (0.07 MPa, 0.7 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
311304H
CSA mark applies only to 12 VDC
and 115 VAC motors for Class I, Div
I, Group D Hazardous Locations
EN
Advertisement
Table of Contents
Related Manuals for Graco GTP10 Series
Summary of Contents for Graco GTP10 Series
- Page 1 Instructions - Parts List GTP10 Pump 311304H For pumping gasoline, diesel fuel, and kerosene. Do not use to pump other fluids including water. Models 260000 through 260017, 260019, 260024, 260580, and 260581 10 gpm (38 lpm), 12 VDC (CSA C/US listed motor) Models 260020 and 260021, 10 gpm (38 lpm), 24 VDC Models 260022 and 260023, 12 gpm (45 lpm), 230 VAC Models 260025 through 260028...
- Page 2 Models Models Part No. Hose Nozzle 12 VDC, 10 gpm (38 lpm), 12.5 amps 260000 260069 - 12 ft (3.66 m) grounded 260079 - manual, leaded/diesel 260001 260069 - 12 ft (3.66 m) grounded 260082 - automatic, regular/diesel 260002 260069 - 12 ft (3.66 m) grounded 260078 - manual, unleaded 260003 260069 - 12 ft (3.66 m) grounded...
- Page 3 Models 311304H...
- Page 4 Warnings Warnings The following general warnings are for the setup, use, grounding, maintenance, and repair of this equipment. Addi- tional, more specific warnings may be found throughout the body of this manual where applicable. Symbols appear- ing in the body of the manual refer to these general warnings. When these symbols appear throughout the manual, refer back to these pages for a description of the specific hazard.
- Page 5 Read fluid and solvent manufacturer’s warnings. For complete information about your material, request MSDS forms from distributor or retailer. • Check equipment daily. Repair or replace worn or damaged parts immediately with genuine Graco replacement parts only. •...
-
Page 6: Installation
1 in. (25 mm) pipe with 1 in. npt threads on one end. Suction tubes longer than 60 in. (1.52 m) require a foot valve (Graco Part No. 260217) at the bottom of the tube to prevent loss of prime. -
Page 7: Mounting Hose And Nozzle
1. Apply thread tape provided with pump to both ends 4. Insert gasket (7f) into union nut (1k). If using Graco of hose assembly. Screw ¾” NPT end of 90° union supplied PVC suction tube it is not necessary to swivel (15) to one end of hose (see fig. -
Page 8: Electrical Installation
Installation Electrical Installation Electrical Installation 12 VDC and 24 VDC 115 VAC and 230 VAC If you are installing models 260580 or 260581 skip this section. These pumps have been factory wired On 115 VAC and 230 VAC pumps, electrical con- To install wiring for a negative ground system: nections must be made by a licensed electrician per requirements of local, state, and national codes... -
Page 9: Priming Pump
(1.52 m) will have difficulty in holding prime. It is recom- CAUTION mended that check valve (Graco part no. 260217) be added to the bottom of the suction tube to help maintain Do not operate pump dry. Do not run pump for more prime. -
Page 10: Troubleshooting
Troubleshooting Troubleshooting Problem Cause Solution Motor runs but pump will not prime. Motor rotation wrong. (12 VDC and Check wiring instructions for possible 24 VDC units only.) problems. Missing relief valve o-ring seal Remove gear cover (1b) inspect seal (4c/7a). (4c/7a), replace if missing or damaged. - Page 11 Troubleshooting Problem Cause Solution Motor stalls when nozzle is closed. Bypass relief valve (4a) stuck. Inspect relief valve, making sure poppet is free. Replace if damaged. Low supply voltage. Check supply voltage. Gears (1c/10a) damaged and Inspect gears. Gears should turn binding.
-
Page 12: Parts Drawing
Parts Drawing Parts Drawing Models 260000 through 260017, 260019, 260024, 260580, and 260581, 12 VDC 260456 Models 260020 and 260021, 24 VDC 3d/7e Models 260022 and 260023, 230 VAC Models 260025 through 260028, 115 VAC Packing Kit 260434 includes items 7a-7f 260458 which are also included in other kits. -
Page 13: Parts List
Parts List Parts List Models 260000 through 260017, 260019, 260024, 260580, and 260581, 12 VDC Models 260020 and 260021, 24 VDC Models 260022 and 260023, 230 VAC Models 260025 through 260028, 115 VAC Ref. No. Description Ref. No. Description 260456 KIT, filter, universal 260458 KIT, pump with swivel, blue... - Page 14 Parts List (continued) Parts List (continued) Models 260000 through 260017, 260019, and 260024, 12 VDC Models 260020 and 260021, 24 VDC Models 260022 and 260023, 230 VAC Models 260025 through 260028, 115 VAC Ref. No. Description 260433 KIT, switch, blue (includes items 8a-8g) 253718 KIT, switch, black...
-
Page 15: Technical Data
Technical Data Technical Data Working pressure 10 psi (0.07 MPa, 0.7 bar) Inlet size 1 in. npt Outlet size 3/4 in. npt Weight 20 lb (9 kg) Power cable 18 ft (5.5 m), 14 AWG (12 VDC and 24 VDC models only) Current draw 12 VDC models: 12.5 amps 24 VDC models: 7 amps... -
Page 16: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
