HEAT PUMP AIR CONDITIONERS
TECHNICAL & SERVICE MANUAL
Indoor unit
[Model Name]
PLFY-WP32VBM-E
PLFY-WP40VBM-E
PLFY-WP50VBM-E
Model name
indication
INDOOR UNIT
[Service Ref.]
PLFY-WP32VBM-E.UK
PLFY-WP40VBM-E.UK
PLFY-WP50VBM-E.UK
Notes:
• This manual describes ser-
vice data of the indoor units
only.
• RoHS compliant products
have <G> mark on the spec
name plate.
CONTENTS
1. SAFETY PRECAUTION .......................... 2
2. PARTS NAMES AND FUNCTIONS ........ 2
3. SPECIFICATIONS ................................... 7
4. 4-WAY AIR FLOW SYSTEM ................. 10
5. OUTLINES AND DIMENSIONS ............ 13
6. WIRING DIAGRAM ............................... 15
7. REFRIGERANT SYSTEM DIAGRAM ...... 16
8. TROUBLESHOOTING .......................... 17
9. SPECIAL FUNCTION ........................... 24
10. DISASSEMBLY PROCEDURE ............. 31
PARTS CATALOG (OCB586)
April 2015
No. OCH586
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric PLFY-WP32VBM-E
Summary of Contents for Mitsubishi Electric PLFY-WP32VBM-E
-
Page 1: Table Of Contents
HEAT PUMP AIR CONDITIONERS April 2015 No. OCH586 TECHNICAL & SERVICE MANUAL Indoor unit [Model Name] [Service Ref.] Notes: PLFY-WP32VBM-E.UK • This manual describes ser- PLFY-WP32VBM-E vice data of the indoor units only. PLFY-WP40VBM-E.UK • RoHS compliant products PLFY-WP40VBM-E have <G> mark on the spec name plate. -
