SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
TECHNICAL & SERVICE MANUAL
Series PLFY
Indoor unit
[Model names]
PLFY-P32VAM-E
PLFY-P40VAM-E
PLFY-P50VAM-E
PLFY-P63VAM-E
PLFY-P80VAM-E
PLFY-P100VAM-E
PLFY-P125VAM-E
INDOOR UNIT
Revision:
• " 10. PARTS LIST " has been modified.
• Please void OC313
Ceiling Cassettes
[Service Ref.]
PLFY-P32VAM-E.UK
PLFY-P40VAM-E.UK
PLFY-P50VAM-E.UK
PLFY-P63VAM-E.UK
PLFY-P80VAM-E.UK
PLFY-P100VAM-E.UK
PLFY-P125VAM-E.UK
REVISED EDITION-A
R410A
R407C
CONTENTS
1. SAFETY PRECAUTION··························2
2. PART NAMES AND FUNCTIONS ··········6
3. SPECIFICATIONS···································8
4. 4-WAY AIR FLOW SYSTEM ·················11
5. OUTLINES AND DIMENSIONS············14
6. WIRING DIAGRAM·······························15
7. REFRIGERANT SYSTEM DIAGRAM ·····16
8. TROUBLE SHOOTING·························17
9. DISASSEMBLY PROCEDURE·············24
10 . PARTS LIST··········································27
11. OPTIONAL PARTS················Back cover
No. OC313
R22
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric PLFY-P32VAM-E
Summary of Contents for Mitsubishi Electric PLFY-P32VAM-E
-
Page 1: Table Of Contents
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS No. OC313 REVISED EDITION-A TECHNICAL & SERVICE MANUAL Ceiling Cassettes Series PLFY R410A R407C Indoor unit [Model names] [Service Ref.] PLFY-P32VAM-E.UK PLFY-P32VAM-E PLFY-P40VAM-E.UK PLFY-P40VAM-E PLFY-P50VAM-E.UK PLFY-P50VAM-E PLFY-P63VAM-E.UK PLFY-P63VAM-E PLFY-P80VAM-E.UK PLFY-P80VAM-E PLFY-P100VAM-E.UK PLFY-P100VAM-E PLFY-P125VAM-E.UK PLFY-P125VAM-E CONTENTS 1. -
