Product specifications

Processor
• AMD Ryzen 3 Mobile 3200U (dual-core 2.6GHz,up to 3.5GHz) for ZBOX CA621NANO
Onboard graphics
• AMD Radeon™ Vega 3 Graphics
• HDMI 2.0 (max resolution:4096x2160 @60Hz)
• DP 1.4 (max resolution:3840x2160 @60Hz)
Memory support
• 2 x DDR4-2400 SODIMM Slot
• Up to 32 GB of memory
USB ports
• Front 1 x USB3.0 port
• Rear 3 x USB3.0 ports
Storage support
• SATA Gen3 Data transfer rate up to 6.0 Gb/s
• Supports 1 x 2.5-inch SATA HDD/SSD
• Supports 1x M.2 2242 Key-M SATA SSD
Network support
• Dual 10/100/1000 Mbps Ethernet
• IEEE 802.3 compatible
Wi-Fi support
• 802.11ac Wi-Fi (dual-band)
• Bluetooth 4.2
Onboard Audio
• Stereo analog audio output and Microphone input
Operating System support
• Windows 10 64-bit
Product Dimensions
• 204mm x 129mm x 68mm
