- Page 1 Lava-oggetti Serie UW6070D – UW6070DPS UW60132D - UW60132DPS Lave-utensils Série UW6070D - UW6070DPS - UW60132D - UW60132DPS Warewashers Range UW6070D UW6070DPS UW60132D UW60132DPS UW6070D UW6070DPS Universal-Spülmaschinen Serie UW60132D - UW60132DPS Lava-objetos Serie UW6070D UW6070DPS UW60132D UW60132DPS Котломойки Серии UW6070D UW6070DPS UW60132D UW60132DPS...
-
Page 3: Overall Dimensions
MISURE D'INGOMBRO DIMENSIONS OVERALL DIMENSIONS ABMESSUNGEN DIMENCIONES / ВНЕШНИЕ РАЗМЕРЫ UW6070D UW6070DPS D = SCARICO 1½", VIDANGE 1½", DRAIN 1½"; ABFLUSS 1½"; DESAGÜE 1½"; СЛИВ 1½" C = CARICAMENTO ACQUA ¾" GAS; CHARGEMENT EAU ¾" GAZ; WATER INLET ¾" GAS; ZUFLUSS ¾" GAS; CARGA AGUA ¾" GAS; НАБОР... - Page 4 MISURE D'INGOMBRO DIMENSIONS OVERALL DIMENSIONS ABMESSUNGEN DIMENCIONES / ВНЕШНИЕ РАЗМЕРЫ UW60132D UW60132DPS D = SCARICO 1½", VIDANGE 1½", DRAIN 1½"; ABFLUSS 1½"; DESAGÜE 1½"; СЛИВ 1½" C = CARICAMENTO ACQUA ¾" GAS; CHARGEMENT EAU ¾" GAZ; WATER INLET ¾" GAS; ZUFLUSS ¾" GAS; CARGA AGUA ¾" GAS; НАБОР...
- Page 5 CARATTERISTICHE TECNICHE / CARACTÉRISTIQUES TECHNIQUES / UW6070D UW60132D TECHNICAL FEATURES / TECHNISCHE DATEN / CARACTERISTICAS UW6070DPS UW60132DPS TECNICAS / ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ PRODUZIONE ORARIA (CESTI) / DÉBIT PANIERS-H / BASKETS PER HOUR / KÖRBE PRO STUNDE / RENDIMIENTO HORARIO / 30/15 30/15 ЧАСОВАЯ...
- Page 6 CARATTERISTICHE TECNICHE / CARACTÉRISTIQUES TECHNIQUES / UW6070D UW60132D TECHNICAL FEATURES / TECHNISCHE DATEN / CARACTERISTICAS UW6070DPS UW60132DPS TECNICAS / ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ PESO NETTO / POIDS NET / NET WEIGHT / NETTOGEWICHT / PESO NETO / 230 kg 315 kg ВЕС НЕТТО PESO LORDO / POIDS TOTAL / TOTAL WEIGHT / BRUTTOGEWICHT / PESO 275 kg 350 kg...
-
Page 7: Installation, Use And Maintenance
WARE WASHERS RANGE UW6070D – UW6070DPS - UW60132D - UW60132DPS INSTALLATION, USE AND MAINTENANCE... -
Page 8: Installation
WARNINGS The appliance is to be used for washing baking trays, ice cream basins, baking tins, saucepans and kitchen utensils. Read the instructions carefully before installation, use and maintenance of the appliance. The installation has to be performed by qualified personnel following the manufacturer's instructions given in the provided manual. -
Page 9: Preliminary Steps
The manufacturer's arrangement matches the first specification (that is: 400V, 3-phases, with neutral); the other can be achieved following the provided wiring diagram. In particular, as for the upper washing pump (1,5 kW) of the models UW6070D and UW6070DPS, in order to pass to 230 V three-phased, simply interpose the spacing block between the pump connector and the wiring connector. - Page 10 WATER FILLING AND HEATING Picture 1 Boiler thermometer Lamp “boiler heating” Tank thermometer Lamp “tank heating” Main switch Lamp “machine on” Selector short / long / continuous cycle Lamp “short cycle” Lamp “long cycle” Lamp “continuous cycle” M Start switch / switch “tank draining” Lamp “tank draining”...
-
Page 11: Washing Cycle
WASHING CYCLE Open the door of the appliance. Remove all the solid remainders from the kitchen utensils, empty pots and saucepans, and soften any encrustations with specific products. Then, place the kitchenware in the baskets. Place ice cream basins, pots, pans, buckets, saucepans and other kitchenware in the basket with their concave part downwards. -
Page 12: Safety Systems
have the dishwasher ready for new working cycles, put the overflow pipe back into its place, close the door, and switch on the machine through the main switch (E). The dishwasher fills water into the tank automatically up to the set level and it switches on the boiler and tank heating elements. -
Page 13: Draining And Cleaning
SHOWER (pre-set models only) To use the shower perform the following operations: Turn the tap in the position "open"; Take the shower from its place and turn it where necessary. When not in use, we highly recommend turning the tap in the position “close” in order to protect the shower membrane. - Page 14 Information for electrical and electronic devices used in EU countries According to EU directives, devices marked with the following symbol may not be disposed of together with normal household waste. To dispose of your used device, please use the locally available differentiated collection system or consult your retailer when you buy an equivalent product.
