4. DESCRIPTION

4.01 The splice module requires a 7-inch (17.8 cm) mounting space within the frame. Major
components of the splice module are shown in
paragraphs. Specifications for the module are listed in
Figure 3. 7-Inch FDS Splice Module Components and Dimensions
Figure 3
17.0 IN.
and are described in the following
Table 1.
PIGTAIL
CABLE ACCESS
OSP/IFC
CABLE ACCESS
