Stepping The Mast - Hobie MAX RACE Assembly Manual

CAUTION - DANGER - ALUMINIUM
Then, with one person on the trampoline, the second person lifts the mast
by the top and moves down the mast until the person on the trampoline
can take the mast on their shoulder. Then this person pushes his feet
the picture above.
5
Once the mast is secured, remove the pin from
MAST - STAY AWAY OF
ELECTRICAL WIRES
1
Place the mast foot on the mast base
and place the pin in it. This prevents
the mast from leaving its base when
lifted. Check that the wires are not
tangled.
against the rear crossbar and pushes the mast forward with the weight of his body.
3
The second person
goes in front of the boat
and right the mast in
pulling on the trapeze
wires. Once the mast is
upright, link the rigid
forestay and the two
bridles to the stay
adjuster that is at the
end of the forestay as
shown on the picture.
the base of the
mast which can

Stepping the mast

2
4
Link the bottom of the rigid forestay to the
spi pole. Fix the
spectra bridles
as shown on
now turn freely.
Fix the cunningham
blocks on each side of the base of the mast.
The first time you raise the mast, it is advisable to have
6
