Grizzly T28941 Instructions

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
Introduction
The Model T28941 Work Stop Measuring System
is designed to work with the T30399 Infeed/
Outfeed Roller Set to produce fast, repetitive, and
accurate cuts.
Inventory
Description
A. Carriage Rail .............................................. 1
B. Measuring Tape .......................................... 1
C. Adjustable Push Bar ................................... 1
D. Rail Extension ............................................ 1
E. Extension Bracket ...................................... 1
F. Workpiece Stop .......................................... 1
G. Carriage ...................................................... 1
H. Cap Screws M6-1 x 12 ............................... 4
I.
Cap Screw M8-1.25 x 10 ............................ 1
J.
Cap Screws M8-1.25 x 55 .......................... 4
K. Flat Washers 8mm ..................................... 4
L. Spacers 11ID x 17OD x 38 ......................... 4
M. Hex Bolts M6-1 x 16 ................................... 2
N. Lock Handle ............................................... 1
O. Steel Ball 10mm ......................................... 1
P.
Workpiece Guide ........................................ 1
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
COPYRIGHT © SEPTEMBER, 2019 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 6/19) #CS20519 PRINTED IN TAIWAN
MODEL T28941
MEASURING SYSTEM
A
B
C
D
Qty
E
Figure 1. Model T28941 inventory.
G
H
I
J
Figure 2. Carriage and hardware.

Needed for Setup

Description
A. G0613/G0614 Metal Bandsaw .................... 1
B. Assembled/Mounted T30399 Roller Set .... 1
C. Hex Wrenches 5, 6mm .........................1 Ea.
D. Wrench or Socket 6mm .............................. 1
WORK STOP
INSTRUCTIONS
F
K
L
M
N
O
P
Qty
V1.09.19
