Installation Instructions
BMW Motorola V50 / V3690 (dual band) hands-free retrofit kit
BMW 5 Series touring (E 39/2)
The installation time is approx. 7 hours but this may vary depending on the condition of the car and the
equipment in it.
Retrofit kit No.
Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193
Installation Instructions No. 01 29 0 143 743
84 63 0 143 192
84 63 0 143 193
Issue date: 03.2002
039 0130 Z
Advertisement
Table of Contents
Related Manuals for BMW 84 63 0 143 192
Summary of Contents for BMW 84 63 0 143 192
- Page 1 Retrofit kit No. 84 63 0 143 192 84 63 0 143 193 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002...
-
Page 2: Table Of Contents
10. Circuit diagram ............... 19 EN/2 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743... -
Page 3: Important Information
If the specified PIN chambers are occupied, bridges, double crimps or twin-lead terminals must be used. Target group The target group for these installation instructions is specialist personnel trained on BMW cars with the appropriate specialist knowledge. All work must be completed using the latest BMW repair manuals, circuit diagrams, servicing manuals and work instructions in a rational order using the prescribed tools (special tools) and observing current health and safety regulations. -
Page 4: Preparations
Oddments box 51 16 200 Radio (cars with SA 661 only) 65 11 030 EN/4 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002... -
Page 5: Retrofit Wiring Harness Connection Diagram
To hands-free control module adapter X4038 branch B1 Fakra plug contact To standard aerial cable X13323 EN/5 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002... - Page 6 SW 18-pin plug To multi wiring harness branch A1 SW 18-pin plug To interface X4545 EN/6 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002...
-
Page 7: Installation And Cabling Diagram
Radio plug X18126 (with SA 602, 609, 663 only) Plug X325 Fuse holder Earth post X498 EN/7 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002... -
Page 8: To Install And Connect The Retrofit Wiring Harness
Connect branch C5 to the fuse joint connector X498 . X498 039 0223 Z EN/8 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002... - Page 9 Connect branch C6 to plug X325 PIN 2. Connect the socket casing (1) and plug casing (2). X325 039 0247 Z EN/9 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002...
- Page 10 - WS/BR cable in PIN 10 - WS/GN cable in PIN 11 039 0253 Z EN/10 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002...
- Page 11 Lay branches A3 and A4 to plug X18126. Disconnect plug X18126 from the radio (1). A3-A4 X18126 039 0228 Z EN/11 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002...
- Page 12 Connect branch A3 to plug X18126. X18126 Reconnect plug X18126 to the radio receiver. 053 0205 Z EN/12 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002...
-
Page 13: To Install And Connect The Hands-Free Control Module
Connect branch B2 to the hands-free control module (1). 039 0241 Z Connect branch A11 to branch B1. 039 0242 Z EN/13 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002... -
Page 14: To Install The Aerial Resistor
Connect the aerial resistor (1) between branch A12 and the standard aerial cable (2). 039 0229 Z EN/14 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002... -
Page 15: To Install And Connect The Eject Box
Connect the black 12-pin plug (1) for the eject box to the interface (2). Insert the interface (2) into the holder (3). 039 0058 Z EN/15 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002... - Page 16 Connect the eject box adapter D between the black 18-pin plug (1) on the interface and branch A1. 039 0255 Z EN/16 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002...
-
Page 17: To Install The Hands-Free Microphone
Clip the hands-free microphone (1) and tilt and slide sunroof switch (2) into the trim (3). 039 0235 Z EN/17 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002... -
Page 18: Concluding Work
- Conduct a brief test with DIS/MoDiC III. - Conduct a function test - Re-assemble the car EN/18 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002... -
Page 19: 10. Circuit Diagram
The circuit diagrams for the retrofit telephone system are available if required on the installation instructions CD entitled “Circuit diagrams for retrofit telephones UNI II”. EN/19 Retrofit kit No. 84 63 0 143 192 / 84 63 0 143 193 Installation Instructions No. 01 29 0 143 743 Issue date: 03.2002...
